Overset Grids in STAR-CCM+: Methodology, Applications and Future Developments Eberhard Schreck and Milovan Peri CD-adapco Advantages of Overset Grids Easier to perform and automate parametric studies: With a single set of grids, many


slide-1
SLIDE 1

Overset Grids in STAR-CCM+: Methodology, Applications and Future Developments

Eberhard Schreck and Milovan Perić CD-adapco

slide-2
SLIDE 2
  • Easier to perform and automate parametric studies:

– With a single set of grids, many different configurations can be computed; – Grid quality not affected by changing position/orientation of bodies; – Boundary conditions easier to set…

  • Easier to handle relative motion of bodies:

– Arbitrary motion can be handled; – Paths can cross; – Tangential motion at close proximity can be handled…

Advantages of Overset Grids

slide-3
SLIDE 3

 Control volumes are automatically labelled as:

 Active cells, or  Passive cells.

 In active cells, regular discretized equations are solved.  In passive cells, no equation is solved – they are

temporarily or permanently de-activated.

 Active cells along interface to passive cells refer to

donor cells at another grid instead of the passive neighbours on the same grid...

 The first layer of passive cells next to active cells are

called acceptor cells...

 The user can visualize the cell status as a scalar field…

Overset Grids Method in STAR-CCM+, I

slide-4
SLIDE 4

 Currently, triangular (2D) or tetrahedral (3D) interpolation

elements are used, with either distance-weighted or linear interpolation... Other (higher-order) interpolations will come…

Background grid Overset grid

N1, N2, N3 –

Neighbors from the same grid;

N4, N5, N6 –

Neighbors from the overlapping grid.

Overset Grids Method in STAR-CCM+, II

slide-5
SLIDE 5

Overset Grids Method in STAR-CCM+, III

 No explicit interpolation of solution is performed…  Solution is computed on all grids simultaneously – grids

are implicitly coupled through the linear equation system matrix...

slide-6
SLIDE 6

Convergence of Iterations

Residuals history for a laminar flow around an object… Implicit coupling of grids allows convergence to round-off level of residuals…

slide-7
SLIDE 7

 Overset grids usually involve:

 One background mesh, adapted to environment;  One or more overset grids attached to bodies, overlapping

the background mesh and/or each other.

 Each grid represents a separate Region in STAR-CCM+

terminology...

 Both background and overset mesh(es) can be generated

(or imported) in the usual way, region by region…

 Any grid type can be used for any region…  Almost all physics models can be applied…

Overset Grids Method in STAR-CCM+, IV

slide-8
SLIDE 8

 Each grid (background and overset) can move according

to one of the standard motion models available in STAR- CCM+…

 Each grid can also deform (e.g. in a coupled fluid-

structure interaction simulation) using any available morphing technique…

 Overset grids can fall out of solution domain (cut-out by

boundary surface).

 Overset grids can overlap each other.  Overset grids have boundary regions of type “overset”.

Overset Grids Method in STAR-CCM+, V

slide-9
SLIDE 9

 In the overlapping zone, cells should be of comparable

size in both meshes (recommendation):

 Interpolation errors in the coupling equation should be of

the same order as when computing convective and diffusive fluxes (interpolation over half a cell);

 The coarser of the two coupled meshes determines the

error level…

 Between two body walls, at least 4 cells on both

background and overset grid are needed to couple them (requirement).

 The overset grid should not move more than one cell per

time step in the overlapping zone (recommendation).

Tips and Tricks…

slide-10
SLIDE 10
  • Parametric studies (varying angle of attack)
  • Bodies moving relative to each other
  • Engineering problems that can be solved with overset

grids easier than otherwise…

Examples of Application

slide-11
SLIDE 11

Flow around a car model at different angles of attack A horizontal section through both grids (only active cells are shown). Total number of cells:

  • ca. 1 million

Vertical section through the two grids (only active cells are shown). Same grids and boundary conditions – many positions (easy to automate).

Application to Parametric Studies, I

slide-12
SLIDE 12

Velocity distribution in a section parallel to bottom wall for different angles of attack

30°

  • 30°
  • 15°

0° 15°

Application to Parametric Studies, II

slide-13
SLIDE 13

Residual history from the computation

  • f flow around a vehicle in a wind

tunnel at different angles of attack History of computed forces from the computation of flow around a vehicle in a wind tunnel at different angles

  • f attack

Application to Parametric Studies, III

slide-14
SLIDE 14

Simulation of motion of a container ship in Stokes waves propagating from right to left: initial vessel orientation 30° (upper) and -30° (lower) relative to the direction of wave propagation. Single set of grids, same boundary conditions, different vessel orientations – easy to automate…

Application to Parametric Studies, IV

slide-15
SLIDE 15

Motion of Windscreen Wipers

Overset grids allow simulation of wiper action on a windscreen (VoF, locally fine grid around wipers, intersecting paths, FSI…)

slide-16
SLIDE 16

Flow Around Moving Rudder

Overset grid attached to rudder is morphed by projecting vertices

  • f one wall boundary to a “guiding surface” (hull wall) in every time
  • step. This approach has also been applied to real windscreen

wipers…

slide-17
SLIDE 17

Injector Needle Motion, I

Overset grids allow easier simulation of processes in fuel injectors and similar devices (axial motion, vibration, deformation, VoF, cavitation…)

slide-18
SLIDE 18

Injector Needle Motion, II

Pressure Volume fraction

  • f liquid (three

phases involved: liquid, vapor, air), simulation of cavitation…

slide-19
SLIDE 19

Simulation of Pouring

  • Pouring optimization:

 Reduce misruns;  Increase yield (skull reduction);  Use STAR-CCM+ to find optimized pouring curve (CD-adapco/ Access);  Variation in rotational speed, pouring height and position …

slide-20
SLIDE 20

Simulation of Coating by Dipping

Demonstration by CD-adapco (upper) and grid motion from a real application in automotive industry (right)

Overset grids allow simulation of coating by dipping bodies into paint bath (arbitrary body motion, VoF, e-coating model for paint layer growth, forces on body parts, trapped air and liquid pockets…)…

slide-21
SLIDE 21

Simulation of Coating by Spray

Overset grids allow simulation of coating by moving spray heads (fast spinning nozzles with arbitrary translation and rotation, electrically charged spray droplets, liquid film on car surface…)

Demonstration by CD- adapco

slide-22
SLIDE 22
  • Rotating machinery (instead of sliding interfaces);
  • Internal combustion engines (moving piston and valves);
  • Gear pumps, screw pumps/extruders etc.;
  • Valves, opening/closing doors/windows etc.;
  • Relative motion of flying or floating bodies (ships passing

each other in a river or channel; car overtaking or passing by, missiles, torpedo etc.);

  • Mixers with moving parts of complex shape and

intersecting paths;

  • … and many others, involving parametric studies or part

motion…

Other Possible Applications

slide-23
SLIDE 23

Optimization of a Tidal Turbine

slide-24
SLIDE 24

Simulation of Lifeboat Launching

slide-25
SLIDE 25

 Dynamic overset-wall boundary condition:

Wall boundary is automatically converted to overset boundary when it comes into overlapping zone.

This simplifies simulations when overset grids slide partially along wall and partially inside another grid:

Current Developments – Overset Grids

slide-26
SLIDE 26

Dynamic Overset-Wall Boundary, I

slide-27
SLIDE 27

Dynamic Overset-Wall Boundary, II

slide-28
SLIDE 28

 The most important future developments include:

– Implementation of higher-order interpolation; – Optimization of parallel processing; – Modelling of contact (valves, impact…); – Automatic mesh adaptation to fulfil requirements of

  • verset grids (avoid failures due to inadequate grids in

the overlapping zone):

  • Minimum number of cell layers in gaps;
  • Similar cell size in overlapping zone;
  • Refining the background grid ahead and coarsening

behind a moving body.

Future Developments – Overset Grids

slide-29
SLIDE 29

Thank you for your attention!
