Operators Deep Dive Graham Hayes / HP Ron Rickard / eBay Inc. - PowerPoint PPT Presentation

Operators Deep Dive Graham Hayes / HP Ron Rickard / eBay Inc. Graham Hayes - HP Cloud Ron Rickard Sr. Cloud Engineer, eBay Inc. rrickard@ebaysf.com irc.freenode.net: rjrjr Agenda Designate Overview Designate REST API Designate and Neutron


  1. Operators Deep Dive Graham Hayes / HP Ron Rickard / eBay Inc.

  2. Graham Hayes - HP Cloud

  3. Ron Rickard Sr. Cloud Engineer, eBay Inc. rrickard@ebaysf.com irc.freenode.net: rjrjr

  4. Agenda Designate Overview Designate REST API Designate and Neutron Designate Central Designate Sink

  5. Designate Overview

  6. Designate Overview Designate is the DNS as-a-service component in OpenStack. ● Designate consists of: REST API, Central, and Sink. ● Internal and external Designate communication use the message queue. ● A designate client will allow you to manage servers, domains, and records. ● More functionality is available in the REST API. ○ Designate is the source of record for DNS records for the domains it manages. ● Domains are owned by tenants. ● Additional information: ● http://designate.readthedocs.org ○

  7. Designate Architecture Keystone Central Database API AMQP DNS Backend Server User

  8. Designate REST API

  9. Designate REST API Version 1 allows management of: ● Servers ○ Domains ○ Records ○ Experimental Version 2 adds: ● Zone import/export ○ Top-Level Domains (TLDs) ○ Zone blacklists ○ Managed Floating IP PTR Records ○ Additional information: ● http://designate.readthedocs.org/en/latest/rest.html ○

  10. Designate Client Provides a command-line interface (CLI) like Keystone and Nova CLIs. ● Functionality is a subset of entire Designate API: ● Servers ○ Domains ○ Records ○

  11. Zone Import/Export GET/POST - /v2/zones/<id> - Content-Type text/dns Use the API to: ● import zones in zonefile format ○ export zones in zonefile format ○ A zoneextractor.py tool assists with generating the zonefile format for ● imports

  12. Top-Level Domains (TLDs) GET/POST/PATCH - /v2/tlds/<id> Use the API to managed TLDs ● By default no TLDs exist and any domain name can be created ● Presence of TLDs causes domain creation checks: ● last label in domain name must be a TLD ○ the entire domain name cannot be a TLD ○

  13. Zone Blacklists GET/POST/PATCH - /v2/blacklists/<id> Use the API to manage blacklists ● Blacklist are regular expressions used to block domains from being created ● Example to prevent example.com. domain from being created: ○ ^example\\.com\\.$ ■ Example to prevent example.com. and subdomains of example.com. ○ from being created: ^([A-Za-z0-9_\-]+\\.)*example\\.com\\.$ ■

  14. Designate and Neutron Floating IP Reverse DNS

  15. Floating IP Pointers GET/PATCH - /v2/reverse/floatingips/<id> Manage reverse DNS (PTR records) for Neutron Floating IPs ● Allow Operators to delegate the *.in-addr.arpa zone to Designate ● Users can manage their own DNS, without support ○ Users can only set PTRs for IPs currently associated with their tenant ○

  16. Designate Central

  17. Designate Central Contains the core code for Designate. ● Uses pluggable storage driver for persisting data: ● SQLAlchemy ○ Uses pluggable backend driver for DNS operations: ● PowerDNS ○ NSD4 ○ FreeIPA ○ DynECT ○ BIND (needs work) ○

  18. Backend Drivers Currently, backend drivers need to implement functions for: ● Create, update, delete TSIG keys ○ Create, update, delete domains ○ Create, update, delete record set ○ Create, update, delete records ○ Coming is a mini-DNS in Designate. Mini-DNS will: ● Pushes data using zone transfers (AXFR/IXFR) ○ Simplify backend drivers ○ Additional Information: ● http://designate.readthedocs.org/en/latest/backends.html ○

  19. Backends - MiniDNS API Customer Facing Database Central MiniDNS DNS Server Backend / Manager

  20. Designate Sink Automatic Record Creation

  21. Designate Sink Designate Sink consumes events from Nova, Neutron, and other services and ● turns those events into DNS operations. What events and what DNS operations are performed are determined by ● custom notification handlers. Designate ships with sample notification handlers: ● Nova handler ○ Neutron handler ○

  22. Events compute.instance.create .start/.error/. end network.create compute.instance.delete.start /.end network.delete compute.instance.update network.port.create compute.instance.rebuild.start/.end network.port.delete orchestration.stack.create.start/.error/.end floatingip.update.end floatingip.delete.start orchestration.stack.update.start/.error/.end trove.instance.create orchestration.stack.delete.start/.error/.end trove.instance.delete

  23. Payload {"state_description": "", "availability_zone": null, "terminated_at": "", "ephemeral_gb": 0, "instance_type_id": 2, "message": "Success", "deleted_at": "", "reservation_id": "r-0fhyl6wq", "instance_id": "192c1697-bc90-483f-bffc-6f461dd793cc", "user_id": "7101d930ff084aab9136db2b359719e2", "fixed_ips": [{"floating_ips": [], "label": "private", "version": 4, "meta": {}, "address": "10.0.0.2" , "type": "fixed"}], "hostname": "rontest", "state": "active", "launched_at": "2014-02-24T23:16:43.058572", "metadata": [], "node": "frodo", "ramdisk_id": "", "access_ip_v6": null, "disk_gb": 1, "access_ip_v4": null, "kernel_id": "", "image_name": "cirros-0.3.0-x86_64-disk", "host": "frodo", "display_name": "rontest" , "image_ref_url": "http://192.168.56.35:9292/images/afd10e78-d2e2-41cf-b1f7-573d7c89ac18", "root_gb": 1, "tenant_id": "c8344a592b574589b531fe8956ef7ec1", "created_at": "2014-02-24T23:16:37.000000", "memory_mb": 512, "instance_type": "m1.tiny", "vcpus": 1, "image_meta": {"min_disk": "1", "container_format": "bare", "min_ram": "0", "disk_format": "qcow2", "base_image_ref": "afd10e78-d2e2-41cf-b1f7-573d7c89ac18"}, "architecture": null, "os_type": null, "instance_flavor_id": "1"}

  24. Notification Handler Code class NotificationHandler(ExtensionPlugin): … @abc.abstractmethod def get_exchange_topics(self): """ Returns a tuple of (exchange, list(topics)) this handler wishes to receive notifications from. """

  25. Notification Handler Code (continued) @abc.abstractmethod def get_event_types(self): """ Returns a list of event types this handler is capable of processing """ @abc.abstractmethod def process_notification(self, context, event_type, payload): """ Processes a given notification """ ...

  26. Designate Sink at eBay Inc. Evolving custom notification handler: Initial design: ○ Granular with a single forward and reverse zone per tenant ■ Context (user, tenant, token) taken from notification message ■ Final design: ○ VPC - Virtual Private Cloud (dev, prod, ext) ■ VPCs are implemented as special tenant (not seen by user): ■ admin_extcos ● admin_devcos ● admin_prodcos ● tenants grouped into VPCs ■ many forward and reverse zones associated with VPC tenants ■

  27. Designate Sink at eBay Inc. (continued) Final design (continued): ○ Nova instance metadata: ■ zone - forward zone for A record ● hostname - hostname portion of FQDN for A record ● VPC name ● VPC name is mapped to VPC tenant in designate.conf: ■ ● network_host_tenants = ext:admin_extcos,dev:admin_devcos,prod: admin_prodcos service account is member of VPC tenants and used to add A and PTR records to ■ Designate

  28. def process_notification (self, context, event_type, payload): domain_id = self.central_api.find_option(context, “default_domain”) recordset = self . central_api . create_recordset(context, domain_id, {'name': name, 'type': type, 'ttl': ttl,}) address = {'version': 4, 'address': payload['floatingip']['floating_ip_address']} record_values = {'data': address['address']} self . central_api . create_record(context, domain_id, recordset['id'], record_values)

  29. Workshop B314 @ 13:30 Make sure you have installed: VirtualBox (4.x) Vagrant (Latest)
