EML 4501: MECHANICAL ENGINEERING DESIGN 2 NOVOBIO A New 3D Bioprinting Solution Group 3: Changxiao Liang, Demany McKinnon, Hunter Hintenlang, Min Park, Nan Lin, Sam Kibble EML 4501: MECHANICAL ENGINEERING DESIGN 2 Design Hedgehog

  1. EML 4501: MECHANICAL ENGINEERING DESIGN 2 NOVOBIO A New 3D Bioprinting Solution Group 3: Changxiao Liang, Demany McKinnon, Hunter Hintenlang, Min Park, Nan Lin, Sam Kibble

  2. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Design Hedgehog Concept: Wide Cell type Compatibility Stepper motor Threaded syringe pump Quick switch tip

  3. DEPARTMENT OR UNIT NAME. DELETE FROM MASTER SLIDE IF N/A DEPARTMENT OR UNIT NAME. DELETE FROM MASTER SLIDE IF N/A Product Overview

  4. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Product Overview: Dispensing Mechanism Print tip rubber gasket ◼ Subsystem 1 rendering Print tip with threaded head

  5. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Product Overview: Printing Head Motion Stages

  6. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Product Overview: Support Structure and Attachment Mechanism Fastened to linear stage here Aluminum L- Bracket Fastened to Motion Platform Print tip presses into here

  7. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Product Overview: External Pump Mechanism SmoothieBoard Compatible Stepper Motor Rigid Connecting Shaft Elliptical Syringe Pump Effortless snap-in-place syringe mount

  8. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Product Overview: Remote Power Transmission Fastener Motor Mount Linear Flexible Stage Motor Stepper Shaft Motor

  9. EML 4501: MECHANICAL ENGINEERING DESIGN 2 DEPARTMENT OR UNIT NAME. DELETE FROM MASTER SLIDE IF N/A Customer Needs to Subsystems Synopsis and Cost Summary

  10. EML 4501: MECHANICAL ENGINEERING DESIGN 2

  11. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Cost Summary

  12. EML 4501: MECHANICAL ENGINEERING DESIGN 2 DEPARTMENT OR UNIT NAME. DELETE FROM MASTER SLIDE IF N/A Why our design?

  13. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Unique Features ◼ Elliptical Syringe Pump ◼ Guideless linear actuation eases manufacturing and prevents shear of biomaterial ◼ Fine threads in conjunction with fine stepping allow for optimal control through Smoothieboard 5X ◼ Iterative design allows for multiple channel flow if desired ◼ Accessible to different bio ink by changing pumps conveniently ◼ User Friendly Printing Tip ◼ Customizable printing head dimensions ◼ Printing tip rapidly made using SLA printer ◼ Quick replacing and installing to reduce handling and insertion time ◼ Flexible Motor Shaft ◼ Flexible motor position

  14. EML 4501: MECHANICAL ENGINEERING DESIGN 2 Why should our design be selected? ◼ Unique, above and beyond features ◼ Low production cost ◼ Lightweight ◼ User friendly design
