NEW PRODUCTS 20 10
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S H H E E HIGH SPEED STEEL – GENERAL PURPOSE STUB DRILLS – BRIGHT FINISH R R 1. General purpose HSS stub drills for use on automatics and turret lathes suitable W W for drilling steels, cast iron, alloy steel and malleable cast iron. Point angle 118°. Helix angle and web thickness is as per standard tolerances. O O 2. All produced to BS328 Part 1 1986/DIN 1987 with H8 tolerance on diameters – relief angle 10° - 20°. 3. New metric sizes: 2.00, 2.50, 3.00, 3.20, 3.30, 3.50, 4.00, 4.20, 4.90, 5.00, 6.00, 7.00, O O 8.00, 8.50, 10.00, 12.00mm. D D “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 K K E E N N CARBIDE TIPPED HOLESAWS N N 1. Manufactured to precise Internationally accepted standards and recognised as the best choice for cutting tough materials, such as tile, stainless steels, hardened steels and alloys E E 2. Full range can be used in conjunction with the standard product range of arbors etc. D D 3. Range includes the following sizes: Metric only – 19, 20, 22, 25, 29, 32, 35, 38, 40, 41, 44, 48, 51, 54, 57, 60, 64, 67, 70, 76, 105mm. Y Y “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S H H E E HIGH SPEED STEEL – TAPER SHANK EXTRA LENGTH MACHINE REAMERS R R 1. Used to produce a close tolerance surface finish in drilled holes to allow the W W fitting of hardened and ground taper pins in the building of jigs, fixtures, dies etc. 2. This range of products are manufactured to BS328 Part 4 : 1990 and DIN 9A. O O 3. Sizes: 6.00 x 203mm o/all – 8.00 x 203mm o/all – 10.00 x 203mm o/all – 10 x 254mm o/all – 12.00 x 203mm o/all – 12.00 x 254mm o/all – 12 x 305mm o/all – 16.00 x 254mm o/all – 16 x 305mm o/all. O O D D “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S H H E E HIGH SPEED STEEL GROUND THREAD TAPS 1. Range has been extended to include more of the metric coarse slower moving R R items and also some metric fine taps. 2. All standard, High Speed Steel Taps are produced in accordance with dimension W W tolerances of IS 529. 3. Addition items in the range: M3 x 0.6mm – M3.5 x 0.6mm – M4 x 0.50mm – O O M7 x 1.00mm – M8 x 0.75mm – M8 x 1.00mm – M9 x 1.25mm – M10 x 0.75mm – M11 x 1.50mm – M12 x 1.00mm – M14 x 1.00mm – M14 x 1.25mm – M14 x 2.00mm – M18 x 1.00mm – M18 x 1.50mm – M18 x 2.00mm – M20 x 1.00mm – O O M20 x 2.00mm – M24 x 2.00mm – M25 x 1.50mm – M27 x 2.00mm – M27 x 3.00mm – M30 x 1.50mm – M30 x 2.00mm – M33 x 3.5mm. D D “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S W W I I S S S S MODULAR DEBURRING TOOLS + + 1. The Kennedy range of deburring tools has now been discontinued and replaced B by a range of modern, easier to use and control Swiss+Burr products. B 2. Range comprises of 29 individual products and 6 sets, this will gradually be U U increased as customers request range extensions. R R 3. Blades are interchangeable with commonly available brands including – Kennedy – NOGA – RUKO – SECO – Snap Tap, Stellram. R R “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 I I N N D D E E INDEXABLE MILLING CUTTERS X X 1. Range produced to precise International Standards. A A Full range of spares available. - - 2. All products now have the “XP” Plasma ion coating which gives extended tool life and greater hardness, they are more wear resistant than normal cutters. S S 3. 4 products which feature in the range are: E E a) 20 – 25 – 32 – 40mm – Positive 90° Approach Weldon Shank End Mills b) 63 – 80 – 100 – 160mm – Super Positive 45° Approach “High Shear” Milling Cutters I I c) 63 – 80 – 100 – 125mm – Positive 90° Cutter “4 Square” Milling Cutters K K d) 63 – 80 – 100 – 125 – 160mm – 45° Super Positive “Face Hog” Milling Cutters I I “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S H H E E STRAIGHT SHANK SOLID CARBIDE JOBBER DRILLS R R 1. Micro Grain Solid Carbide Drills are manufactured to BS.328 DIN.338 Standards W W – Point Angle 118° – Diameter Tolerances h7 – Shank Tolerance H6. 2. Ideally suited to repetitive general purpose machining of a wide variety of O O metallic and non-metallic materials. Range in inch – 1/32” to 1/2” in 1/64 th sizes. 3. Range in metric – 1.00mm to 20.00mm. O O D D “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S H H SOLID CARBIDE E E CENTRE & SPOTTING DRILLS R R 1. Micro Grain Solid Carbide Drills are manufactured to BS328 Standards – 60° included angle and 118° Drill Point. W W 2. Mainly used to produce 60° centres in components for subsequent manufacturing operations to be carried out. Carbide extends the tool life and O O also enables difficult materials to be machined. 3. (a) Ranges – BS1 to BS6 Centre Drills (inch). (b) Ranges – 4mmx1.60mm to 16mm x 6.30mm Centre Drills. O O (c) Ranges – 4mm x 90° to 20mm x 90° Spotting Drills. D D “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 S S W W I I S S SHANK MILLING CUTTERS S S 1. All items produced from 8% Cobalt M42 material to international standards – Threaded shank to DIN.1835D cutting diameters to e8 – shank diameters to h6. + + 2. All NINE ranges have screwed shank – All are 3 flute cutters. T T 3. Short Series – Uncoated – T.I.C.N Coated – Ti ALN Coated. E E Standard Series – Uncoated – T.I.C.N Coated – Ti ALN Coated. Long Series – Uncoated – T.I.C.N Coated – Ti ALN Coated. C C H H “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 K K E E N N ABRASIVE CLOTHS N N 1. Grit from USA and Resin from Germany has lead to performance improvements to both the standard Blue Twill Economy Range and the Superflex products. E E 2. Rolls Range is 25-38-50mm wide and 50 metres long in Economy and 25-50mm wide and 50 metre long in Superflex Range. Emery sheets in Economy and D D Superflex Ranges are available in a wide range of Grits standard (P40 to P280) and Superflex (P40 to P320). Y Y 3. Due to increased volumes the prices are now generally competitive. “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 Y Y O O POLISHING & LAPPING PRODUCTS R R 1. Very comprehensive range of Polishing and Lapping products for use in a diverse range of industries. K K 2. Fully tested for use on wide range of materials and metals including brass, copper, aluminium, pewter, plastics, gold, silver and polishing mops for specific metals are “described” in the catalogue. 3. Details of Felt Bobs dimensions and styles are detailed in the catalogue. Also information on applications for the range of six different pre-finish and polishing bars are shown in the catalogue. “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 K K O O B B E E PNEUMATIC FITTINGS 1. The Kobe range of pneumatic fittings and airline accessories has been produced - - in accordance with the standards and dimensions generally accepted within the pneumatics industry. A A 2. The plan is to gradually widen the Kobe range in accordance with requests from our customers as we accept that this range is presently very basic. I I 3. Some products have “Third Level” zinc plating for protection against most forms of corrosion. R R “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 K K O O B B E E AIR TOOLS - - 1. Three ranges of products now available “Red” range - Automotive intermittent use “Green” range – automotive intermittent – composite grip, “Blue” range – industrial continuous use applications. A A 2. Range includes – Drills – Grinders – Impact Wrenches – Hammers – Scalers – Nibblers – Saws – Shears – Riveters – Sanders – Screwdrivers. I I R R “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 K O E X N F N PRECISION PRODUCTS O 1. Kennedy and Oxford Digimatic Caliper ranges extended. E 6”/150mm – 8”/200mm – 12”/300mm SPC Digimatic Kennedy Calipers. 6”/150mm – 8”/200mm – 12”/300mm Digital ABS Kennedy Calipers. R 6”/150mm - 8”/200mm – 12”/300mm Digital ABS Oxford Calipers. D 2. Oxford External Micrometers extended to 500 to 600mm. D Y 3. All products extensively tested in both laboratory and industrial environments. “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
“3,544” NEW PRODUCTS FOR YOU IN 2010 M M A A T T STORAGE SYSTEMS L L 1. Range of high strength polypropylene storage bins now extended to 28 products O O – 7 sizes and 4 colours – Red – Blue – Yellow – Green. 2. Unique design allows for storage bins to be used in a variety of positions – C C stacking – interlocking – nesting and also hanging. 3. Range of high strength polypropylene euro boxes with reinforced corners, rims K and integral interlocking hinged lids. Available in 20-40 and 50 litre capacities, K 2 colours, Grey and Blue. “19,107” PRODUCTS ARE AVAILABLE TO YOU IN 2010
