Mycobacterium Revelio TEAM IISER PUNE From Muggles to Wizards - PowerPoint PPT Presentation

iGEM 2015 Mycobacterium Revelio TEAM IISER PUNE From Muggles to Wizards Muggle Studies Jehangir Hospital, Pune ZN- staining LJ media culturing MGIT technique Image: www.scilogs.com http://medind.nic.in www.tbonline.info Muggle Studies


  1. iGEM 2015 Mycobacterium Revelio TEAM IISER PUNE

  2. From Muggles to Wizards

  3. Muggle Studies Jehangir Hospital, Pune ZN- staining LJ media culturing MGIT technique Image: www.scilogs.com http://medind.nic.in www.tbonline.info

  4. Muggle Studies Cepheid GeneXpert GenePath Dx lab

  5. Our Goal Detection of Mycobacterium using a genetic device : • Quick • Robust • Economic • Safe

  6. The three magical spells Gemino The Doubling Charm Aparecium The Visibility Charm http://animationsa2z.com/harry-potter.php Avada Kedavra The Killing Curse

  7. Gemino The Doubling Charm Overclocking the cell cycle

  8. Gemino in Harry Potter Video from Harry Potter movie showing Gemino curse

  9. The Gemino Analogy Target • Cell cycle controlling proteins • Oscillating concentrations during Behavior cell cycle period Gemino • Enhance the frequency of these oscillations • More number of cell cycles Resultant activated during same time period Genetic Gemino Oscillator

  10. The Fast, Robust,Tunable Oscillator Stricker et al. (2008) +arabinose AraC GFP LacI -IPTG Hybrid Promoter – p lac/ara1

  11. Oscillator Construct ready!

  12. Variable Link Oscillator Hasty et al (Chaos 2002) P RM P RM c1 GFP C1 Protein RCSA P RM rcsA Protease

  13. Original Model Two Plasmid System Our simulation to check the range of (m x : m y ) values for which oscillations occur - y x m x > m y Equations from literature : dx dt = m x f ( x ) - g x x - g xy xy dy = m y f ( x ) - g y y dt dg dt = m x f ( x ) - g g g - g gy gy Production terms Degradation terms The protease effect!

  14. Single Plasmid System Our Model Bio-brick part (RBS) Efficiency BBa_B0034 1.0 (Reference) x y BBa_B0030 0.6 BBa_B0031 0.07 m ' x = m ' y = m ' e x : e y = 0.6 : 0.07 = 8.75:1 e x > e y e x : e y :: m x : m y dx dt = e x ( m ' f ( x )) - g x x - g xy xy dy = e y ( m ' f ( x )) - g y y dt dg dt = e x ( m ' f ( x )) - g g g - g gy gy RBS Efficiency Factors

  15. The three magical spells Gemino The Doubling Charm Aparecium The Visibility Charm http://animationsa2z.com/harry-potter.php Avada Kedavra The Killing Curse

  16. How do we see them?

  17. Aparecium The Visibility Charm Making the invisible visible

  18. Aparecium in Harry Potter

  19. The Aparecium Analogy Invisible Cells Visible Cells β -carotene Lycopene

  20. Detection Techniques Microscopic Macroscopic http://www.zeiss.com/microscopy/en_de/products/light-microscopes/axio-imager-for-polarized-light.html http://www.thermoscientific.com/en/product/varioskan-flash-multimode-reader.html

  21. Measurement and Characterization of Pigments Using Spectroscopy Carotene Lycopene Optical methods for noninvasive determination of carotenoids in human and animal skin - Maxim E. Darvin (2013)

  22. Measurement and Characterization of Pigments Using Microscopy Beta carotene biobrick in E.coli MG1655 cells Control E.coli MG1655 cells Lycopene biobrick in E.coli MG1655 cells Beta carotene biobrick in E.coli TOP10 cells Lycopene biobrick in E.coli TOP10 cells

  23. Further Characterization Plans Further in Microscopy : • Use of colour filters in microscope • Use of portable and cost efficient microscope like • Foldscope • Paperscope http://www.zeiss.com/microscopy/en_de/service-support/filtersets-dyes/_jcr_content/stagepar/stage/slide/stageimage/image.img.jpg/1364973094776.jpg/filter-sets-stage.jpg

  24. Further Characterization Plans Testing Foldscope with slide containing blood smear stained with giemsa dye for it’s magnification power High Magnification Low Magnification beta tester lab

  25. Again to the Muggles

  26. The three magical spells Gemino The Doubling Charm Aparecium The Visibility Charm http://animationsa2z.com/harry-potter.php Avada Kedavra The Killing Curse

  27. Now we need to stop them!

  28. Avada Kedavra The Killing Curse

  29. Avada Kedavra in Harry Potter Video from Harry Potter movie showing Avada Kedavra curse

  30. The Avada Kedavra Analogy AHL LuxR I LuxR LuxR LuxI p(tetR) LacI+pL CcdB CcdB Lux pR

  31. The Test Constructs Receiver Sender Bba_R0011+Bba_K805016 Bba_T9002 – pSB1C3 - pSB1K3

  32. And the circuit works! All the cultures are induced with IPTG Scale bar- 5um

  33. Measurement and Characterisation

  34. When is the terminator triggered?

  35. At threshold cell density, terminator is switched on Termination for switch based mechanism Normal Termination Circuit

  36. The three magical spells Gemino The Doubling Charm Aparecium The Visibility Charm http://animationsa2z.com/harry-potter.php Avada Kedavra The Killing Curse

  37. Our Device Phage containing genetic device attack M.tuberculosis Genetic device enters the cell and takes control of the Genetic device cell cycle added to sample Rapid division and pigment production Pigment detected Termination “Self Destruct”

  38. Our Prototype Cap Temporary Seal Protective foil Sample Mycobacteriophage One way screw cap Breaking foil Mixing sample with phage

  39. Achievements Avada Aparecium Gemino • Pigmented cells Kedavra • Modelling shows obtained oscillations! • Assembled • Sender device in Characterized the • 3 plasmids pSB1K3 biobricks by containing various backbone Cambridge Team parts of the oscillator module • • Showed that Assembled ready Sender and foldscope to Receiver devices overcome the • Submitted 2 work in co- issue of expensive biobricks central culture! microscopy to the oscillator design • Characterized the working of these Biobricks by analyzing GFP output

  40. Team PI : Dr. Chaitanya Athale (1 st from left) Mentor : Neha Khetan (3 rd from left) Manasi Gangan (4 th from left)

  41. Acknowledgements Attributions - Dr. Vikram Padbidri, Jehangir Hospital - Dr. Mughda Gadgil, NCL - Dr. Kavita Khatod, GenePath Dx Lab - Dr. Nishad Matange, IISER Pune - Dr. Gayathri Pananghat, IISER Pune

  42. Thank You
