MECI Products and Company Overview MECI Location MECI is - PowerPoint PPT Presentation

MECI Products and Company Overview MECI Location MECI is specialized in custody transfer solutions for oil and gas MECI Since 1922 for instrumentation Since 1970 for metering solutions Our customers: National and international oil


  1. MECI Products and Company Overview

  2. MECI Location MECI is specialized in custody transfer solutions for oil and gas MECI • Since 1922 for instrumentation • Since 1970 for metering solutions Our customers: National and international oil and gas companies EPC companies Equipment integrators In April 2009: MECI joined the COUNTUM group – French investment funds – SATAM , sister company Date Titre 2

  3. Measurement solutions from Production to Distribution MECI : « up-stream » market, including SATAM : « down-stream » market refineries Oil and gas metering and proving Liquid hydrocarbons depots, systems for Refineries, Pipeline, Ship, Truck and Wagon loading and Offshore platforms, Storage offloading COUNTUM addresses the oil and gas metering market from the production up to the distribution Date Titre 3

  4. COUNTUM : The Metering from Production to Distribution Transportation networks, Underground gas storages offshore & onshore production Refineries FSO-FPSO-FSU-FSRU Terminals and pipelines Date Titre 4

  5. COUNTUM Group organization • Some functions have merged between MECI and SATAM – Top management, Human Resources, Financial, Sales and Marketing departments • For other functions, responsibilities are split and they share the same tools – Quality, Research, Customer Services departments • International sales are based on a mutual worldwide sales representative network Date Titre 5

  6. Geographical locations : the service proximity MECI Nantes Countum & Satam headquarter Lyon Products Production facilities Technical centers Marseille Projets Avec 64 distributeurs Services MECI : 80 people Date Titre 6

  7. COUNTUM Group Worldwide coverage 70 countries agents - distributors Date Titre 7

  8. MECI activities: Products, Projects and Services  Projects  Products Engineering and operation system Mastering the conception and manufacturing - Complete metering system with associated - Control room and site flow computers control panels - Prover controller computer - Analysis package for product quality control - Data logger - Automated truck loading application - Remote Terminal Unit - Calibration via prover or master meter - Energy metering package - Automation and supervisory system  Services  Periodical control verification - Commissioning, start-up and upgrade - Gas volume converter - Factory repairs - Chromatographs - Initial control verification - Measuring systems for liquids other - Training for customer than water - Technical assistance - Repairs on site or in Meci facilities - Proving & recalibration - Preventive maintenance Date Titre 8

  9. METERING DATA LOGGERS MECI products range REMOTE MONITORING ANALYSIS

  10. MECI Product Range CDN16 Flow Computer DES16 Densitometer transducer CDV15 on site gas flow computer PES15 Chromatographe and Calorimeter CDV15-3 P, PT, PTZ CDV15-4 DEPRIMOGENE Calorimeter Natural Gas analyzer LOG15 Data Logger SM@RT U Remote management GPRS/3G Date Titre 10

  11. The CDN16 the improved and optimized version by MECI of the Flow-X Local Or remote Date Titre 11

  12. MECI CDN16 Flow Computer CDN16/M CDN16/S CDN16/P CDN16/T CDN16/R Date Titre 12

  13. MECI CDV15 field gas Flow Computer MECI CDV15 CDV 15-3 : gas volume corrector for turbine and ultrasonic flow meters CDV 15-4 : gas flow computer for differential pressure system (  P) CDV15-3 P, PT, PTZ Innovative concept: CDV15-4 On-site maintenance with no impact on accuracy and certification:  Change of pressure captor  Change of temperature probe  Change of electronic box High level functionalities:  Chromatograph management for energy measurement  High accuracy  No impact of temperature variations  Compatible with supervisory Date Titre 13

  14. MECI LOG15: Data logger Functions - Data acquisition - Alarm watch - Recording ATEX low consumption concept Large storage capacities Ability to manage data stored on an external flash card Configuration RS232 1 – par PC 3 - Par compact flash or Date Titre 14

  15. MECI DES16 densitometer • Dedicated to custody transfer measurement system for liquids • Compatible with most of existing field and panel flow computers • Compact design • A ready-to-use solution Date Titre 15

  16. MECI DES16: general configuration DTV-16 : volumetric mass captor • Gross volumetric mass • Associated temperature DES16 : instrumented densitometer loop • Liquid volumetric mass • Associated temperature • Associated pressure CDN16 : Flow computer • Basic volumetric mass • Converted volume • Mass Date Titre 16

  17. CVM16 natural gas calorimeter • GasCVD is a natural gas calorimeter that measures the calorific value, wobbe indice of natural gas. • Compact design with lower price • Stable measurement • High reliability and accuracy • High speed response GDF SUEZ laboratory compliant ATEX compliant NMI compliant LNE compliant Date Titre 17

  18. MECI PES15: Energy metering package Energy system measurement for natural gas and biogas applications Measurement of the 11 main components of the gas ISO 6976 standard AGA 8 standard Date Titre 18

  19. MECI PES15: a compact solution PACK ENERGIE DE SITE PES 15 « He » A standard compact solution for analysis and measurement: « Event » - Optimization of installation costs - Competitive price « Gaz étalon » - Fast analysis cycle - Easy configuration and start « Gaz de ligne » - Maintenance (plug & play) - Modbus communication 1/4" 1/4" CENTRALE DE BASCULEMENT SEMI AUTOMATIQUE 1/4" + SONDE DE DETENDEUR PRELEVEMENT AVEC DETENDEUR INTEGRE PRESSION DE SORTIE 2 BAR Energy = measurement B50 B50 B50 PIQUAGE ¾’’ NPT F He He Gaz étalon TUYAUTERIE Date Titre 19

  20. sm@RTU Global solution device and software SM@RT U Data collection and exploitation SM@RT U Site configurator management Digital I / O P, T LF RS485 P T BF 24 Meter Date Titre 20

  21. sm@RTU Stand alone and wireless solution SM@RT U Remote access GPRS / 3G / ... On site access Bluetooth 4.0 LE More than 10 years Temperature Digital I / O Pressure RS485 Authorized in Atex area Date Titre 21

  22. sm@RTU MyMeci Cloud Remote maintenance SM@RT U configurator Overall view of your sites Friendly data exploitation Date Titre 22

  23. Turn key Projects

  24. MECI metering solutions  Ready-to-use solutions  Surrounded products with application software and supervisory system  Turnkey metering systems for liquids and gases  Feasibility, design, conception and manufacturing  Gas analyzing systems TT PT 0 F  Prover or master meter calibration systems TT PT F O O  Automation and supervisory systems TT PT DS  Remote control solutions DS  Up-grading & revamping of existing metering installations Date Titre 24

  25. Upgrading of metering installations Extends the life of existing installations - Improving performance levels - Bringing installations in line with new regulations requirements (ie MID in Europe) A comprehensive offer - Global audit and solution design - Incorporating the modification: metering system acceptance tests, metrology folders, automation and supervisory system - Commissioning and training of local operating team - Maintaining the installation Date Titre 25

  26. MECI projects solutions MECI takes in charge the project from the design of the solution Certification Tests Commissioning Procurement and manufacturing Training Project management After sale services Engineering MECI ensures : - the global working of the installation Revamping - the performance level Audits And manages its evolutions A comprehensive offer for a ready-to-use installation Date Titre 26

  27. Manufacturing – Integration : some examples Date Titre 27

  28. Engineering From Pre-design to P&ID… Date Titre 28

  29. Engineering ... To system’s architecture and customized Scada views Date Titre 29

  30. Engineering - Design Skid Date Titre 30

  31. Engineering - Supervision Date Titre 31

  32. Some projects  Gas Terminal - Fos Cavaou  Natural gas storage  LPG metering skid - Algeria  LPG un-loading / off-loading for trucks and wagons Date Titre 32

  33. Organization for the projects Date Titre 33

  34. Services & after sales team

  35. Services and metrology MECI : Service supplyer Services Periodic verification  Start-up, commissioning  Volume gas flow converter  Initial calibration  Chromatograph  Customer training  Measuring systems for liquids other than water  Technical support  On site or factory repairI  Proving & recalibration  Preventive Maintenance Lyon The service team: 25 people Marseille spreaded all over the country and abroad Date Titre 35

  36. A complete Quality Management System ISO 9001 Quality insurance Manufacturing, Repair & Installation Periodical Verification COFRAC accredited body ACCREDITATION N°2-1878 Quality Insurance - Manufacturer ATEX certificates Delegation of initial control verification since 2002 Date Titre 36

  37. MECI’s References

  38. References Date Titre 38
