www.m-shot.com Biological microscope Introcuction Biological microscope ML31 is a high quality compound biological microscope equipment with infinity optical system and LED light. It is idea for laboratory microscopy purpose of biological tissue

www.m-shot.com
Biological microscope Introcuction Biological microscope ML31 is a high quality compound biological microscope equipment with infinity optical system and LED light. It is idea for laboratory microscopy purpose of biological tissue and slides. Widely used for educational, medical, biological, etc. Performance compared to Olympus CX23 and Nikon E200. Binocular Trinocular With camera
Biological microscope components Infinity Optical system • Support upgrade to dark field and phase contrast. Eyepiece • High eye point, more comfortable for eyes. • Diopter 5 degrees adjustable, convenience to different eyesight. • Field of view 22mm, wide & brighter view. • Can upgrade to 16X / 20X, max. total maginification to 2000X . Objective • Infinity plan achromatic 4X,10X, 40X, 100X • Super wide field of view 25mm, brighter view • Quadruple nosepice, optional with quintuple
Biological microscope ML31 components Focuse • Low postioned stage control system • Accuracy fine and coarse focusing with 0.001mm Light source • 3W LED • Simply light cover take off to replace lamp. Stage • Bigger stage size 216mm*150mm. • Longer slide holder for 2 pieces slide. • Plumbaginous surface is high strength and anti dust.
Biological microscope ML31 components C-mount adapter • 0.5X for better digital imaging • Internal design for rapidly imaging Power plug • User friendly & safe to use Arm & body • Easier to take and move • Forsted surface anti hand sweat
Performance photo Lower quality microscope, field of view edge is with a fusion yellow light circle. ML31 microscope field of view is very clear and bright.
Dimensions Package size : 53 X 33X 40 cm Gross Weight: 9KGs
Specification Optical system Infinity optical system Observation head Trinocular head ， inclinationof30°interpupillarydistance48mm-75mm Eyepiece Wide field of view WF10X/F.N.22mm , diopter 5 degrees adjustable Nosepiece Quadruple backward Objective Infinity plan achromatic 4X ,10X ,40X ,100X (oil) Condenser Abbey condenser NA1.25 Coaxial coarse and fine with limit and locking devices, low coaxial focus adjusting handle, fine adjusting handle scale value 0.001mm, Focus coarse focusing circle range 37.7mm, fine focusing circle range 0.1mm, focusing moving range 24mm Double layer mechanical stage, graphite surface size 216×150mm ， Stage movingrange75mm×55mm Kohler illumination External detachable LED light source, 3W/LED Power light AC 100-240V 50-60HZ output 4.3V Max:0-750mA adjustable Digital adapter 0.5X C-mount adapter Optional accessories Observation head Binocular head ， inclinationof30°interpupillarydistance48mm-75mm Wide field WF16X/F.N.15mm Eyepiece Wide field WF20X/F.N.12mm Nosepiece Quintuple backward
Microscope Imaging Expert sales@m-shot.com
