LPC-01 1940 TAX PHOTOGRAPH, 1980 TAX PHOTOGRAPH, Courtesy NYC - PowerPoint PPT Presentation

Jan 09, 2023 •785 likes •1k views

181-183 Madison Avenue The Madison Belmont Bldg N 181-183 MADISON AVENUE, SITE PLAN 181-183 MADISON AVENUE, VIEW SOUTHEAST CORNER OF 34TH STREET & MADISON AVENUE MADISON BELMONT BUILDING LPC-01 1940 TAX PHOTOGRAPH, 1980 TAX PHOTOGRAPH,

  1. 181-183 Madison Avenue The Madison Belmont Bldg N 181-183 MADISON AVENUE, SITE PLAN 181-183 MADISON AVENUE, VIEW SOUTHEAST CORNER OF 34TH STREET & MADISON AVENUE MADISON BELMONT BUILDING LPC-01

  2. 1940 TAX PHOTOGRAPH, 1980 TAX PHOTOGRAPH, Courtesy NYC Municipal Archives Courtesy, NYC Municipal Archives MADISON BELMONT BUILDING LPC-02

  3. AREA OF FOCUS AREA OF FOCUS ORIGINAL CHENEY BROTHERS BUILDING LOBBY SHOWROOM ENTRANCE ENTRANCE ELEV: 0.00’ ELEV: -3.5’ ELEV: -3.5’ ELEV: -5.20’ MADISON BELMONT BUILDING LPC-03 EXISTING ELEVATIONS

  4. ORIGINAL CHENEY BROTHERS SHOWROOM ENTRANCE. IRON AND BRONZE ENTRY DOOR AND TRANSOM PANEL. EXISTING STANDPIPE ELEV AT NORTHWEST CORNER: -3.5’ ELEV AT SOUTHWEST CORNER: -5.85’ EXISTING GRANITE STEPS. +10” CHANGE IN LEVEL MADISON BELMONT BUILDING PARTIAL EXISTING WEST LPC-04 ELEVATION

  5. ELEV: 0.00’ ELEV: -3.5’ BLDG LOBBY PROPOSED PROPOSED ENTRANCE RETAIL RETAIL NO CHANGE ENTRY 01 ENTRY 02 MADISON BELMONT BUILDING LPC-05 PROPOSED NORTH ELEVATION

  6. VIEW OF 34TH STREET STOREFRONTS VIEW OF ORIGINAL CHENEY BROTHERS SHOWROOM ENTRANCE AT MADISON AVENUE NOTE: SIDEWALK SLOPE FROM CORNER MADISON BELMONT BUILDING 34TH ST & MADISON AVENUE STOREFRONTS LPC-06

  7. DETAIL VIEW OF MADISON AVENUE ENTRANCE STEPS AND CHANGE IN LEVEL ORIGINAL MADISON AVENUE ORIGINAL CHENEY BROTHERS SHOWROOM ENTRANCE & ORNAMENTAL IRON & BRONZE ENTRANCE DOORS IRON DOORS ORIGINAL EDGAR BRANDT IRON PHOTO: JOAN KAHR, 1925 ENTRANCE DOORS PHOTOS OF ORIGINAL MADISON MADISON BELMONT BUILDING AVENUE ENTRANCE & CHANGE OF LEVEL LPC-07

  8. STOREFRONT BASE AT PROPOSED LOCATION OF RETAIL ENTRANCE 01 STOREFRONT BASE AT PROPOSED LOCATION OF RETAIL ENTRANCE 02 TYPICAL DAMAGE AT SILL TYPICAL DAMAGE AT PILASTER BASE MISSING IRONWORK TYPICAL DAMAGE AT PILASTER BASE PROPOSED RETAIL ENTRANCE 01 PROPOSED RETAIL ENTRANCE 01 PROPOSED RETAIL ENTRANCE 02 PROPOSED RETAIL ENTRANCE 02 MADISON BELMONT BUILDING TYPICAL EXISTING CONDITIONS AT LPC-08 LOCATION OF PROPOSED RETAIL ENRTRANCES

  9. VIEW OF INTERIOR FLOOR LEVELS INDICATING RAISED RETAIL DISPLAY AREA ADJACENT TO MADISON AVENUE ENTRANCE VIEW OF RAISED RETAIL DISPLAY AREA ADJACENT TO 34TH STREET STOREFRONT WINDOWS VIEW RAISED RETAIL DISPLAY FROM EXTERIOR MADISON BELMONT BUILDING PHOTOS OF INTERIOR LEVEL CHANGES LPC-09

  10. BUILDING ENTRANCE LOBBY, WEST WALL & CONCIERGE DESK ENTRANCE LOBBY & VESTIBULE, FACING NORTH MADISON BELMONT BUILDING PHOTOS OF DESIGNATED INTERIOR LPC-10 ENTRANCE LOBBY

  11. WEST WALL OF EXISTING LOBBY ORIGINAL EGRESS DOOR FROM ORIGINAL DOOR FROM BUILDING EGRESS ORIGINAL MARBLE WALL PANELS, BRONZE RETAIL SALES FLOOR STAIR, BASEMENT & UPPER LEVELS GRILLES & DECORATIVE BRONZE FRAMES APPROX ELEVATION: +49” (19 FLOORS) EGRESS FROM SHOWROOM FLOOR EGRESS STAIR FROM SHOWROOM BUILDING EGRESS STAIR, EXIT APPROX ELEVATION: +49” FLOOR. THROUGH LOBBY 7 STEPS, 49” CHANGE IN LEVEL MADISON BELMONT BUILDING PHOTOS OF DESIGNATED INTERIOR LPC-11 ENTRANCE LOBBY

  12. PROPOSED SOLUTION: EAST 33RD STREET NOTES: 1. NO CHANGE TO EXISTING INTERIOR LOBBY. 1. ADA ACCESS TO RETAIL SPACE THROUGH BUILDING LOBBY IS NOT POSSIBLE DUE TO 2. EXISTING EGRESS DOOR FROM RETAIL SPACE 49" INCH DIFFERENCE IN FLOOR ELEVATION. THROUGH LOBBY TO BE MAINTAINED AND SERVE 2. BUILDING LOBBY IS AN NYC DESIGNATED INTERIOR LANDMARK. ANY NEW OPENING THROUGH AS SECOND MEANS OF EGRESS. EXISTING WEST WALL OF LOBBY WOULD REQUIRE THE REMOVAL AND ALTERATION OF 3. PROVIDE NEW ADA COMPLIANT ENTRANCE/EGRESS HISTORIC FABRIC. DOOR AT 34TH STREET STOREFRONT OPENING. 3. EXISTING DOOR OPENINGS ON WEST WALL OF LOBBY LEAD TO EGRESS STAIRS SERVING FLOORS ABOVE AND BELOW. MADISON AVENUE EAST 34TH STREET KEY PLAN NORTH 0.00” 2 STEPS MADISON BELMONT BUILDING PARTIAL EXISTING GROUND FLOOR LPC-12 PLAN

  13. MADISON BELMONT BUILDING PARTIAL PROPOSED GROUND LPC-13 FLOOR PLAN

  14. SERVICE BUILDING ENTRANCE LOBBY ENTRANCE MADISON BELMONT BUILDING ENLARGED EXISTING NORTH LPC-14 ELEVATION

  15. SIGNAGE SIGNAGE SIGNAGE ENLARGED PROPOSED NORTH MADISON BELMONT BUILDING LPC-15 ELEVATION

  16. 7'-1" 1'-8" " 0 1 MADISON BELMONT BUILDING LPC-16 ENLARGED STOREFRONT DETAILS

  17. MADISON BELMONT BUILDING LPC-17 PROPOSED ENTRY DOOR DETAILS

  18. MADISON BELMONT BUILDING APPENDIX - EXISTING CONDITIONS APP-01

  19. MADISON BELMONT BUILDING APPENDIX - INTERNAL RAMP STUDY APP-02

  20. MADISON BELMONT BUILDING APPENDIX - EXTERNAL RAMP STUDY APP-03
