TABLE OF CONTENTS The brand. Our skills. Our IOT arquitecture. WEB SCADA CENTRALIZED CENTRALIZED WIRELESS/CABLING BUS Lobiot One. General description Physical interfaces Technical specification Firmware specification Thanks. Madrid, Spain, Europe, May 2020 Page 1/11
The Brand Lobiot is a new brand created by Lobo Brothers company. Lobo Brothers is a technology consultants company situated in Madrid ( Spain-Europe ). Lobo Brothers is a young company but made up of professionals with a lot of experience and qualification in the sector. Lobiot is a new brand of IOT industrial products with the next focus: • Creating the best and most competitive IOT industrial products . • Simplifying the configuration and connection processes of IOT devices. • Using the most common IOT protocols and net interfaces ( API REST JSON, TCP-IP, Modbus, RS485, Wifi, etc ). • With a database in each IOT controller to get a back up all the data and securing it. • Using Linux/Windows based operating system to get all the power of the IOT devices. • With an all configurable firmware to integrate in it all possible future systems ( LoraWan, Mbus, etc ). Madrid, Spain, Europe, May 2020 Page 2/11
Our Skills In the next table are our main skills: Team Skills Programming and architecture of all kinds of virtualization systems ( Proxmox, XCP- Comunications, ng, Kvm, Vmware, etc. ) Operating Architecture all kind of networks ( structured data cable TCP-IP, wifi, LoraWan, Optic systems and fiber, radiofrecuency, zigbee etc ). Consulting and programming of al kind of security systems ( routers, smart switches, security anti hacking systems , firewalls, etc. ) and creating the most secured environments (Leader: Tomás Lobo) anti intrusions. Customizing all kind of Linux and Windows operating systems, servers and workstations. Designing of all kind of electronic unit shells, and all kind of pieces, using Autocad Industrial IOT CAD/CAM/CAE software. (Leader: Jose Luis Béjar) Selecting express mannufacturing process ( 3D printing, stereolithography, etc ). Programming industrial devices and all kind of sensors ( TCP-IP to RS485, TCP-IP to RS232, Modbus, Mbus, RS485, RS232, etc. ). Designing IOT industrial systems including all layers of the process ( IOT arquitecture, prototiping, modeling, manufacturing, testing ). Designing and customizing all kind of electrical and electronical systems ( electromecanical distribution and control panels, water pumping systems, energy monitoring systems, sensor local and remote systems, all kind of industrial manufacturing systems, etc ). Madrid, Spain, Europe, May 2020 Page 3/11
Our Skills In the next table are our main skills: Team Skills Programming in all kinds of languages ( C#, java, php, phyton, etc .). Firmware and Programming for Windows and Linux operating systems ( Web management software systems, hosted services, APIs, Docker microservices, etc. ) development Programming of all kinds of databases ( SQL Server, MySQL, MongoDB, etc. ). (Leader: Santiago Lobo) Programming of all kinds of peripheral PCB systems ( GPIO ports, TTL interfaces, etc. ). Programming of GPRS systems and GPS systems. Programing custom IA algorithms Always up to date on new web standards, modern best practices, the latest Technical advice frameworks, improvements to the user experience, and other changes in technology. and consulting Constantly learning ... to help my team. (Leader: Raúl Pérez) 2020 JAMstack , DRY “Don’t Repeat Yourself”, XaaS ( anything as a service ), IoT, Cognitive technologies, AI Adoption ( Bots, ChatBots ), Smart Automation, “ AutoML ” for “auto -machine learning, GraphQL, Microservices, Self service BI, Reactive Programming, TypeScript, PWA ( Progressive Web Apps ), Blockchain, Docker, Container Demonstrated ability to multi-task in a dynamic and agile environment. Excellent Time management, Organizational skills. Technical design lead/developer as part of an IT Systems Engineering team or in IT Client Account Management Madrid, Spain, Europe, May 2020 Page 4/11
Our IOT Architecture WEB SCADA CENTRALIZED Hardware: CENTRALIZED LINUX / WINDOWS SERVER Software: CENTRALIZED WEB SCADA FEATURES OF THE WEB APPLICATION "CENTRALIZED WEB SCADA": Authentication by user and password. By default a "god" user will be created ( with total powers ). From such user we will create the new environment of hierarchies and users. Creation of users according to different hierarchies. Total management of users. Possibility to apply any level of hierarchy to each element of SCADA. Creation of "control rules", of each concentrator / s, independently or together, through the use of simple "graphical schemes". This will give us the possibility to "program" each Lobiot One as needed. Immediate synchronization of the control rules in each concentrator of the network, to which changes apply. Display, in real time, of all the “field variables” and “states” of the field devices (temperatures, humidities, on / off states of digital inputs and outputs. Generation of alarms via email , SMS. Madrid, Spain, Europe, May 2020 Page 5/11
Our IOT Architecture WEB SCADA CENTRALIZED Hardware: CENTRALIZED LINUX / WINDOWS SERVER Software: CENTRALIZED WEB SCADA LOCAL NETWORK WEB BROWSER LOCAL NETWORK -> SYNCHRONIZATION CONTROL RULES + ACCESS TO SCADA INQUIRIES TO LOCAL DATABASES + SECURITY COPIES LOCATIONS LOCATION N LOCATION 1 LOCATION 2 SWITCH/ROUTER SWITCH/ROUTER SWITCH/ROUTER LOBIOT ONE LOBIOT ONE LOBIOT ONE LOCAL CONCENTRATOR: LOCAL CONCENTRATOR: LOCAL CONCENTRATOR: CONTROL RULES + API CONTROL RULES + API CONTROL RULES + API …N… REST JSON + DATABASE + REST JSON + DATABASE + REST JSON + DATABASE + INPUT/OUTPUT SIGNALS INPUT/OUTPUT SIGNALS INPUT/OUTPUT SIGNALS Madrid, Spain, Europe, May 2020 Page 6/11
Our IOT Architecture CENTRALIZED WIRELESS/CABLING BUS CENTRALIZED SCADA SERVER WEB SCADA LOCAL NETWORK WEB BROWSER CENTRALIZED ACCESS TO SCADA LOCAL NETWORK -> SYNCHRONIZATION CONTROL RULES + INQUIRIES TO LOCAL DATABASES + SECURITY COPIES LOCATION SWITCH/ROUTER LOCAL NETWORK LOCATION Lobiot One - LOCAL CONCENTRATOR: CONTROL RULES + API REST JSON + DATABASE + INPUT/OUTPUT SIGNALS LOCAL NETWORK/RS485/RS232 LOCAL NETWORK/RS485/RS232 *Wireless/Cabling Access Point 1 *Wireless/Cabling Access Point N *Access Points are optional *Access Points are optional …N… LOCAL NETWORK/RS485/RS232 LOCAL NETWORK/RS485/RS232 SENSORS and SIGNALS <GROUP 1> SENSORS and SIGNALS <GROUP N> 4-20ma, 0-10V, 0-20V, Digital/Relay I/O, 4-20ma, 0-10V, 0-20V, Digital/Relay I/O, Modbus RTU, Modbus TCP, etc… Modbus RTU, Modbus TCP, etc… Madrid, Spain, Europe, May 2020 Page 7/11
Lobiot One General Description Lobiot One is the IOT signals concentrator of Lobiot. Our purpose doing the Lobiot One is include in one unit the best of the next concepts • Easy management of the unit with a secure and captive HTTPs web manager. • Easy and secure data accesibility ( API REST JSON ). • Easy conection to industrial interfaces and protocols ( Modbus, RS485,etc. ). • Easy auto back up and accesibility of the data ( relational database ) • Enought memory for all the unit life ( maximum 32GB, up to 25 life years ). Lobiot One image Madrid, Spain, Europe, May 2020 Page 8/11
Lobiot One Physical Interfaces In the next two images are the visual description of the Lobiot One physical interfaces: RS485 bus connector Caoba wood cover Micro USB type B power connector Hidden wifi antenna RJ45 connector Ventilation grill Status LED Ventilation grill Fixing holes Fixing holes Power LED Madrid, Spain, Europe, May 2020 Page 9/11
Lobiot One Technical Specification In the next list are the Lobiot One technical specification: CPU: Quad-core Cortex-A7 GPU: Mali400MP2 GPU RAM: 512MB DDR3 ( shared with GPU ) ETHERNET: 100M RJ45 ( POE optional ) WIFI: XR819, IEEE 802.11 b/g/n Operating System: Linux Product size: 57 mm × 49 mm x 25 mm Weight: 46 g Power consumption: 1,5 W Maximum Ambient Humidity: 80% Maximum Ambient Temperature: 55ºC Madrid, Spain, Europe, May 2020 Page 10/11
Lobiot One Firmware Specification In the following diagram are the Lobiot One firmware specifications: HTTPs ( RJ45 / Wifi ) Lobiot One MODBUS TCP API REST ( JSON ) CAPTIVE WEB DATABASE MANAGER ( all the data are MODBUS saved periodically RS485 BUS PROTOCOL by tracker service ) MODBUS RTU Tracker Madrid, Spain, Europe, May 2020 Page 11/11
Thanks!! lobiot.com
