Lecture 6: Universal Gates CSE 140: Components and Design Techniques - PowerPoint PPT Presentation

Lecture 6: Universal Gates CSE 140: Components and Design Techniques for Digital Systems Spring 2014 CK Cheng, Diba Mirza Dept. of Computer Science and Engineering University of California, San Diego 1 Combinational Logic: Other Types of


  1. Lecture 6: Universal Gates CSE 140: Components and Design Techniques for Digital Systems Spring 2014 CK Cheng, Diba Mirza Dept. of Computer Science and Engineering University of California, San Diego 1

  2. Combinational Logic: Other Types of Gates § Universal Set of Gates § Other Types of Gates 1) XOR 2) NAND / NOR 3) Block Diagram Transfers: Converting a circuit to an equivalent circuit 2

  3. Universal Set Universal Set: A set of gates such that every switching function can be implemented with gates in this set. Ex: {AND, OR, NOT} {AND, NOT} {OR, NOT} 3

  4. Universal Set Universal Set: A set of gates such that every Boolean function can be implemented with gates in this set. Ex: {AND, OR, NOT} {AND, NOT} OR can be implemented with AND & NOT gates a+b = (a ’ b ’ ) ’ {OR, NOT} AND can be implemented with OR & NOT gates ab = (a ’ +b ’ ) ’ {XOR} is not universal {XOR, AND} is universal 4

  5. iClicker Is the set {AND, OR} (but no NOT gate) universal? A. Yes B. No 5

  6. Universal Set {AND, NOT} combined into a single gate: {OR, NOT} combined into into a single gate: 6

  7. Implementing NOT, AND and OR using NAND gates 1. Implementing NOT using NAND 2. Implementing AND using NAND 3. Implementing OR using NAND 7

  8. Implementing NOT, AND and OR using NOR gates 1. Implementing NOT using NOR 2. Implementing OR using NOR 3. Implementing AND using NOR 8

  9. Universal gates {XOR, AND} 1. Implementing NOT using XOR 1 X 1 = X.1 ’ + X’.1 = X ’ if constant “ 1 ” is available. 2. Implementing OR using XOR and AND Same as implementing OR using AND and NOT except NOT is implemented using XOR as shown above 9

  10. Universal Set Remark: Universal set is a powerful concept to identify the coverage of a set of gates afforded by a given technology. 10

  11. Other Types of Gates X Y 1) XOR X Y = XY ’ + X ’ Y XY ’ X ’ Y (a) Commutative X Y = Y X (b) Associative (X Y) Z = X (Y Z) (c) 1 X = X ’ 0 X = 0X ’ + 0 ’ X = X (d) X X = 0, X X ’ = 1 11

  12. e) if ab = 0 then a b = a + b Proof: If ab = 0 then a = a (b+b ’ ) = ab+ab ’ = ab ’ b = b (a + a ’ ) = ba + ba ’ = a ’ b a+b = ab ’ + a ’ b = a b f) X XY ’ X ’ Y (X + Y) X = ?? To answer, we apply Shannon ’ s Expansion. 12

  13. Shannon ’ s Expansion (for switching functions) Formula: f (x,Y) = x * f (1, Y) + x ’ * f (0, Y) Proof by enumeration: If x = 1, f (x,Y) = f (1, Y) : 1*f (1, Y) + 1 ’ *f(0,Y) = f (1, Y) If x = 0, f(x,Y) = f (0, Y) : 0*f (1, Y) + 0 ’ *f(0,Y) = f(0, Y) 13

  14. Back to our problem… X XY ’ X ’ Y (X + Y) X = ? X (XY ’ ) (X ’ Y) (X + Y) X = f (X, Y) Þ If X = 1, f (1, Y) = 1 Y ’ 0 1 1 = Y If X = 0, f (0, Y) = 0 0 Y Y 0 = 0 Thus, f (X, Y) = XY 14

  15. XOR gates iClicker: a+(b c) = (a+b) (a+c) ? A. Yes B. No 15

  16. 2) NAND, NOR gates NAND, NOR gates are not associative Let a | b = (ab) ’ (a | b) | c ≠ a | (b | c) 16

  17. 3) Block Diagram Transformation a) Reduce # of inputs. ó ó 17

  18. b. DeMorgan ’ s Law ó (a+b) ’ = a ’ b ’ ó (ab) ’ = a ’ +b ’ 18

  19. c. Sum of Products (Using only NAND gates) ó ó Sum of Products (Using only NOR gates) ó ó 19

  20. d. Product of Sums (NOR gates only) ó ó 20

  21. NAND, NOR gates Remark: Two level NAND gates: Sum of Products Two level NOR gates: Product of Sums 21

  22. Part II. Sequential Networks Memory / Timesteps Clock Flip flops Specification Implementation 22

  23. Reading [Harris] Chapter 3, 3.1, 3.2 23
