IP500 Alliance Business Opportunity & Partnership Wireless Sensor Mesh Networks Helmut Adamski, Chair of IP500 / Senior Vice President & General Manager of Funkwerk Mobile Systems & Messaging 07/10/22 v 1.2 1

1.0 IP500 - Goals / Vision & Milestones Goal / Vision: ! Build business opportunity based on a standardized (802.15.4 2006 / 250 Kbps) reliable wireless sensor mesh network solutions focused on industrial and commercial applications. Milestones: ! Focus on standard wireless solutions ! Wireless IC based on IEEE 802.15.4 2006 / 250kbps ! IP based Network Layer (NWL) Stack ! Applications Layer (profiles for various applications) ! Act as official and open organization (as association) world wide ! Invite key OEMs to support and provide wireless mesh-network solutions ! Focus on business opportunities in industrial & commercial applications ! Support SW NWL providers & IC Manufacturer to deliver a high performance, reliable and cost effective wireless mesh network solution based on IEEE 802.15.4 2006 / 250 and IP-NWL 2

2.0) IP500 - Members IP500 Members Product Protfolio Target Segment Belimo Automation , Swiss Drives for HVAC Industrial & Commercial BOSCH Sensortech, Ger. Sensors Industrial & Commercial Temperatur Systems Industrial, Commercial Danfoss , Denmark Funkwerk , Germany Building Management Sys. Industrial, Commercial Gunnebo , France/Sweden Entrance control sys. Industrial, Commercial Schueco , Germany Windows & doors Industrial, Commercial Sommer , Germany Gate & garage drives Industrial, Commercial WAGO , Germany I/O Systems Industrial, Commercial ... Entire member list on request 3

2.0) IP500 - Board Members IP500 Board Member Board Seat Company Helmut Adamski Chairman Funkwerk Dr. Thomas Albers Co-Chairman WAGO Technical Director Danfoss Klaus Nielsen Patrik Ditz Board Member Gunnebo Thomas Billi Board Member Sommer Dr. Joerg Teunissen Board Member Schueco Thomas Nitz Board Member Belimo 4

4.0) IP500 - Focus on Market Segments IP500 OEMs are focused on industrial and commercial applications ! Energy ! Industry ! Office Buildings ! Oel & Gas Mfg Automotive Pharma chemical ! Airports ! Government ! Prisons ! Sport arenas 5

5.0) IP500 - Partnership & Standardization IP500 OEMs and its Partners will generate business opportunities based on wireless mesh network standards OEMs Alliance Standard Partner Building Building Application System Application System Management Management Profiles I ntegrator Profiles I ntegrator System System Security SW Stack Mesh Network Security SW Stack Mesh Network System Provider I P Stack System Provider I P Stack I C I C I EEE 802.15.4 Sub-Systems I EEE 802.15.4 Sub-Systems Manufacturer Manufacturer 2006 / 250 Kbps 2006 / 250 Kbps Business Opportunity 6

6.0) Star Network in Building Automation Most of the current wireless Sub-Systems are connected in a star-network structure using proprietary wireless technologies / IC solutions (e.g. FSK) 7

7.0) IP500 - Mesh-Network in Building Automation Wireless applications are going to communicate in a mesh-network structure to ensure higher redundancy and best coverage. Wireless Bridge / Gateway BMA Mobile Handset 8

8.0) IP500 - USPs of IP Mesh-Network / 802.15.4b ! Technical Data: ! Bi-directional communication ! Frequency 868 MHz (Europe) and 915 MHz (USA) ! PHY/MAC: IEEE 802.15.4 2006 250/PSSS ! Two IC-transceiver in development ! Battery life time ca. 5 years ! IP-based mesh network protocol stack Wireless Bridge / ! USPs of wireless mesh network: BMA Gateway ! IP-Communication to the sensor Mobile Handset ! highest coverage and robustness ! Redundancy due to mesh topology ! Longest battery life time (over 5 years) ! Fastest date transmission (250 Kbps) in 868/915 MHz 9

9.0) IP500 - Wireless 802.15.4b Module The Sub-1GHZ wireless module is capable to deliver highest data rate (250 Kbps) and robustness for industrial & commercial applications 802.15.4b / 250 Kbps Module Application Application Profiles Profiles Micro flexible Micro Controller Protocol Controller Stack Network Layer I P Network Layer Sensor Sensor MAC MAC Media Access Control Media Access Control RF Chip I EEE RF Chip Front & Standard Front & I EEE 802.15.4b Base-Band I EEE 802.15.4b Base-Band Battery Battery 250 kbps 250 kbps 10

10.0) IP500 - Building Management System - Structure Mobile Terminal Alarm- / Control Unit (PC) e.g. PDA, FC2 or Messaging UI F IP-Network (e.g. LAN or WLAN) Building-Management-System (BMS) BMS Driver A Driver C Driver D Driver B . . Driver E Entrance Video- Smoke 802.15.4b Sub- DECT- Control System . . Detector Wireless Syst. Security Sub-Systems Security B O S C H B O S C H BMA Wireless PAN Wired Systems PAN (Personal Area Network) UIF (User Interface) BMS (Building-Management System) BAS Building Automation Systems 11

11.0) IP500 - Building Automation application using wired installation of Sub-Systems Management System Voice Server I/O Gateway to Sub-Systems (wired) Security Server 12

12.0) IP500 - Building Automation application using 802.15.4b wireless connection to Sub-Systems Management System Voice Server I/O Gateway to Sub-Systems (via 802.15.4b) Security Server 13

13.0) IP500 - Product-Roadmap of Key Components BMS Building-Management Q4 / 08 2 Full-Version Wireless-802.15.4b Building-Automation I/O Gateway Q1/ 09 Gateway with ISM ( 802.15.4 - 2006 - 250 Kbps) Sub-System / Products with 802.15.4b ICs BMA Q1/ 09 Sub-System connected to a 802.15.4b I/O Gateway Klima 2008 2009 14

15 Thank You!
