  1. Infinera waves on a Ciena light system Guy Roberts, GEANT Association Terena Architects workshop, 12 Nov 2014

  2. Fibre sharing Field Trial Background • GÉANT Telia Sonera fibre will not be renewed. Looking for cost saving solution. • Field trial has been approved Field Trial • Will test if GÉANT can make use of SURFnet’s dark fibre to carry GÉANT DWDM trunks. • Will be carried out on the SURFnet system Amsterdam-Hamburg line system Objectives • To test the engineering feasibility SURFnet sharing their fibre with GÉANT • To understand the costs of operating such a solution • To understand the operational model of such a solution Partners • The GÉANT Association will lead and SURFnet be a partner in the field trial • Infinera will loan GÉANT the cards necessary for the field trial for a period of 60 days 2 Connect | Communicate | Collaborate

  3. Challenge 1: Matching Infinera and Ciena channel plans • The CMB8 channel muxes used result in guard bands of two 50GHz channels between each of the 9 groups of 8 channels to form a total of 88 channels with two of these unavailable to use (shaded dark grey) • Infinera channels 3 and 8 overlap with guard-bands so can not be used. • Because of these guard bands and CMB8 only 400G possible in the blue spectrum: 3 x 100G and 2 x 50G. • For the field trial CMB8 channel muxes can be used. • A better long-term solution is to use a single 44 channel Ciena Mux (CMB44) or WSS which will remove the guard bands 3 Connect | Communicate | Collaborate

  4. Challenge 2: 10 Wavelengths on one fibre Infinera Photonic Integrated Circuit (PIC) has an integrated AWG which multiplexes 10 x 50Gbps onto a single fibre Connecting direct into Ciena WSS is not a supported configuration. Field trial will overcome this by splitting out one 50Gbps wave per patch Requires an AWG and an amplifier to compensate for losses. 4 Connect | Communicate | Collaborate

  5. Field trial wavelength selection • Two waves: 1556.55nm, 1554.94nm • One of the Infinera wavelengths is 50 GHz and the other is 150GHz away from a Ciena 100G PM-QPSK • This allows us to check the impact of adjacent waves. OCG-1 OCG-2 OCG-9 OCG-10 Channel Frequency (THz) Wavelength (nm) Frequency (THz) Wavelength (nm) Frequency (THz) Wavelength (nm) Frequency (THz) Wavelength (nm) 1 191.75 1563.45 191.8 1563.05 191.725 1563.66 191.775 1563.25 2 191.95 1561.83 192 1561.42 191.925 1562.03 191.975 1561.62 3 192.15 1560.20 192.2 1559.79 192.125 1560.40 192.175 1560.00 4 192.35 1558.58 192.4 1558.17 192.325 1558.78 192.375 1558.38 5 192.55 1556.96 192.6 1556.55 192.525 1557.16 192.575 1556.76 6 192.75 1555.34 192.8 1554.94 192.725 1555.55 192.775 1555.14 7 192.95 1553.73 193 1553.33 192.925 1553.93 192.975 1553.53 8 193.15 1552.12 193.2 1551.72 193.125 1552.32 193.175 1551.92 9 193.35 1550.52 193.4 1550.12 193.325 1550.72 193.375 1550.32 10 193.55 1548.91 193.6 1548.51 193.525 1549.11 193.575 1548.71 5 Connect | Communicate | Collaborate

  6. Current GÉANT connectivity DANTE DANTE Amsterdam Hamburg To OTM OTM To Copenhagen Brussels N amplifiers Switch Switch AOLX- AOLX- AOLX- AOLX- AOLX- AOLX- Matrix Matrix 500 500 500 500 500 500 OTC OTC OTC AOLX- 500 DTN-X DTN-X OTC To DANTE Copenhagen Frankfurt AOLX- 500 N amplifiers Switch AOLX- AOLX- Matrix 500 500 OTC OTC To Prague AOLX- OTM 500 DTN-X 6 Connect | Communicate | Collaborate

  7. Field trial connectivity Pair of loan Pair of loan AOLXs in the ATCs with blue spectrum SURFnet/Ciena OLA and (OCG 2) line system DANTE SURFnet SURFnet DANTE OFM-40 Amsterdam Hamburg Amsterdam Hamburg N x ATC ATC 6500 CPL amps 6500 CPL AOLX- AOLX- 500 500 To To Brussels Copenhag N x en amps Switch Switch AOLX- AOLX- AOLX- AOLX- Matrix Matrix 500 500 500 500 OTC OTC OTC AOLX- Existing DANTE OTM 500 OTM Existing AOLX DTN-X fibre DTN-X on OCG 7 OTC To DANTE Copenhagen Frankfurt AOLX- 500 N amplifiers Switch AOLX- AOLX- Matrix 500 500 OTC OTC To Prague AOLX- OTM 500 DTN-X To Geneva 7 Connect | Communicate | Collaborate

  8. Detail: Amsterdam end of the field trial Power budget Tx Rx launch power -4.5 -10 Address: Address: fibre between sites -3 -3 VANCIS B.V. Science Park SARA Kruislaan 415 121 Amsterdam 1098 XG amp 13 13 Amsterdam 1098 SJ Netherlands OFM4 -6 -6 Netherlands Floor: 1 st Patch -2 -2 Room: S043 Room: S145 receive power -2.5 -8 DANTE Amsterdam PoP SURFnet Amsterdam PoP DTN-X 1554.94nm 2 x 50Gbps ATC 1556.55nm Ciena on 2 fibre OTM 6500 CPL pairs TrueWave Tx -4.5dBm +13dB -6dB -3dB reduced slope min/channel -2dB fibre Switch AOLX- AOLX- WSS Matrix 500 500 Rx -21.5dBm -2dB CMB8 +13dB -3dB AOLX- OFM-4 min/channel 500 Q-factor 8.9 Ciena Input power -3dBm to +3dBm per wave launch power -7dBm to -10dBm per wave Some WSS implementations look for a carrier as a ‘keep alive’ for the WSS to operate. Without the carrier, the WSS seemingly won’t work. Hence if a 3 rd party connects to a WSS port, it won’t acknowledge what is coming in. 8 Connect | Communicate | Collaborate

  9. Detail: Hamburg end of the field trial Power budget Tx Rx launch power -4.5 -10 fibre between sites -3 -3 Address: Address: Wendenstrasse 377 amp 13 13 Customer room 6 Hall 3, Hamburg OFM4 -6 -6 Wendenstrasse 377 20537 Germany 20537 Germany Patch -2 -2 Room: R31476-00001-00004 receive power -2.5 -8 SURFnet Hamburg PoP DANTE Hamburg PoP DTN-X 1554.94nm 2 x 50Gbps on Ciena 1556.55nm 2 fibre pairs ATC 6500 CPL OTM TrueWave Tx -4.5dBm -6dB +13dB To reduced slope min/channel -3dB -2dB Copenhagen fibre Switch AOLX- C WSS Matrix 500 AOLX- 500 CMB8 -2dB -3dB AOLX- +13dB OFM-4 Rx -21.5dBm 500 min/channel Q-factor 8.9 Ciena Input power -3dBm to +3dBm per wave launch power -7dBm to -10dBm per wave To Frankfurt 9 Connect | Communicate | Collaborate

  10. Infinera Equipment Following cards fit into Infinera ATC-A chassis: AOLX-500 goes into the DTN-X GÉANT • OFM-4 Optical multiplexer • AAM Amplifier module • PCM Power control module • AMM Management module • IQA Network operating system IQASW-R4.1.0-IMG-AMM IQA-CMPL-4.1-ATC-A AOLX-500-T4-1-C5 TOM-100M-C45-L2 OFM-4-D-AV-2629 IQA-LIC-SYS-ATN DB9F-RJ45-3.0 LC-LC-DS-2.0 PCM-BLANK OSC-BLANK A-FANTRAY SIM-BLANK NodeName PCM-AC DMC1-B AAM-P1 AMM-A ATC-A Amsterdam 1 1 1 1 1 1 1 1 7 1 1 1 1 1 1 1 1 Hamburg 1 1 1 1 1 1 1 1 7 1 1 1 1 1 1 1 1 Total Count 2 2 2 2 2 2 2 2 14 2 2 2 2 2 2 2 2 10 Connect | Communicate | Collaborate

  11. Production phase Objectives: • At the end of the field trial the loan optical components will be returned to Infinera. • At this point it is proposed to re-engineer the system to use alien waves as a production solution. • The aim is to re-use as many existing components as possible. • The system should support up to 500G at the lowest engineering cost. • Robust operational model is needed Two options considered: • Use AWG to separate out each wave onto a separate fibre (as in field trial) • Use WSS as a more flexible solution 11 Connect | Communicate | Collaborate

  12. Production – Option 1: 10 patches SURFnet Dante 44-channel mux line amplifier Add/drop of up to 10 Infinera waves drop amplifier CMD44 AOLX CMDA 500 DTN- ATC X Line Fiber WSS MLA SCMD8 Add/drop other waves 8-channel mux Wavelength Selective Switch 12 Connect | Communicate | Collaborate

  13. Production – Option 2: WSS solution Dante SURFnet Wavelength Selective Switch for Directional Independent Access (DIA) line side Up to 10 waves line amplifier add/drop In one fiber pair WSS Line Fiber WSS MLA MLA AOLX 500 SCMD8 Infinera • AOLX 500 • OTC? 8-channel mux Virtual splitter and Wavelength Selective Switch 44-channel mux for ROADM line side 13 Connect | Communicate | Collaborate

  14. Thank you! Connect | Communicate | Collaborate www.geant.net www.twitter.com/GEANTnews | www.facebook.com/GEANTnetwork | www.youtube.com/GEANTtv 14 Connect | Communicate | Collaborate
