I-39/US 10 Bridge Public Involvement Meeting Wisconsin Department - PowerPoint PPT Presentation

I-39/US 10 Bridge Public Involvement Meeting Wisconsin Department of Transportation Portage County Library Stevens Point August 22, 2019 4:30 p.m. to 6 p.m. Project Location End Begin Project Project Need for a Project 278 crashes


  1. I-39/US 10 Bridge Public Involvement Meeting Wisconsin Department of Transportation Portage County Library Stevens Point August 22, 2019 4:30 p.m. to 6 p.m.

  2. Project Location End Begin Project Project

  3. Need for a Project • 278 crashes from Country Club Drive to Maple Bluff Road • Bridge is in need of repair

  4. Bridge Needs

  5. Bridge Needs

  6. Project Goals • Improve Safety • Extend life of bridge • Maintain the integrity of existing roadway

  7. Proposed Bridge Improvements • Replace bridge deck and approaches • Repair support structure • Paint steel components of the bridge • Provide improved wider pedestrian accommodations

  8. I‐39 & US 10 Stevens Point

  9. Example Picture I‐35W & 96W Arden Hills, MN

  10. Proposed Intersection Improvements • Shift left turn lanes • Extend US 10 WB auxiliary lane 500 feet • Change US 10 EB to I-39 NB to free flow • Signalize I-39 NB ramp intersection • Install a traffic signal head over each lane • Update curb ramps • Proposed Work

  11. Traffic Impacts • Stage 1  Off peak lane closures  WIS 66 EB to I-39 SB turn lane  Nighttime ramp closures

  12. Traffic Impacts • Stage 2 & Stage 3  I-39: Periodic lane closures  US 10/WIS 66 • Three lanes; two EB, one WB • Temporary signals • Stage 2 • Stage 3

  13. Traffic Impacts • Stage 4  Off peak lane closures  Nighttime ramp closures

  14. Traffic Impacts • Ramp Closures  I-39 NB to US 10 EB ramp closed during bridge construction • Access to I-39 restricted to right turns  Detour will use adjacent interchanges

  15. Construction Timeframe • Construction is currently scheduled to begin spring 2022  Bridge painting may occur fall 2022 or spring 2023

  16. Where to find project information? Wisconsindot.gov/pages/projects/by-region

  17. Questions?
