GC E NERGY P RODUCTS AND S ERVICES GREEN CONSTITUTES SDN BHD - PowerPoint PPT Presentation

GC E NERGY P RODUCTS AND S ERVICES GREEN CONSTITUTES SDN BHD (916287-M ) No. 14-B, Jalan SG 3/5, Taman Sri Gombak, 68100 Batu Caves, Selangor, MY T: +603 6186 6931 F: +603 6185 6931 WHAT WILL BE DISCUSSED? W HAT WE DO .. H OW D OES I T B ENEFIT


  1. GC E NERGY P RODUCTS AND S ERVICES GREEN CONSTITUTES SDN BHD (916287-M ) No. 14-B, Jalan SG 3/5, Taman Sri Gombak, 68100 Batu Caves, Selangor, MY T: +603 6186 6931 F: +603 6185 6931

  2. WHAT WILL BE DISCUSSED? W HAT WE DO .. H OW D OES I T B ENEFIT Y OU ?

  3. PRODUCTS WIND TURBINE Suitable For Low Wind Condition

  4. COUNTER ROTATING BLADES Efficiently capture kinetic wind energy at both high and low wind speeds. Capturing a larger “swept area”, leading to greater wind energy output. Customers will experience optimum ROI

  5. INNOVATIVE GENERATOR DESIGN Our dual input six-phase generator (DISG) provides substantially more power due to the relative motion between its two sets of counter-rotating rotors. It has the ability to operate as single input or both. A rotor can be rotated in the same direction or in counter-rotation. Our innovative DSIG thereby further enhancing the efficiency of our turbines.

  6. POWER OUTPUT The superiority of our Dolphin Series turbines lies in our ability to generate more power at lower wind speeds Most turbines are rated at 12 m/s or more, those sustained high winds rarely even occur, as represented in the graph

  7. OPTIMIZATION THROUGH DESIGN IWE’S unique design improves wind energy conversion. Because of its counter-rotating generator, the complex and unreliable gear box is not required. The additional blade set provides a secondary input that enhances the energy output.

  8. ON & OFF-GRID CONNECTION

  9. SCHEMATIC DIAGRAM

  10. TECHNICAL SPECIFICATIONS

  11. INSTALLED DOLPHIN 3.6

  12. PRODUCTS VENTILATION RECOVERY SYSTEM (V.R.S)

  13. CONNECTION DIAGRAM This Wind Turbine being equipped on the outlet of the ventilation fan system achieves both merits of not only generating the recovery wind power but also reducing the fan power consumption.

  14. GENERATOR SPECIFICATIONS Generator Specifications Generator Type AC, 3 Phases Synchronism PMG Rated Power 300W Inverter System MPPT, Over Speed Brake Control, Grid-tied Output Voltage (Inverter end) 110~240 V AC Single Phrase Output Current 1~10 Amp Braking System Over Speed Braking Control Automatic Short-Circuit Braking System Manual Braking System Optional Operation Temperature Ambient Temperature -10~40 °C Ambient Humidity 95% Maximum

  15. ROTOR SPECIFICATIONS

  16. PRODUCTS UTILITY SCALE WIND TURBINE by GAMESA CORPORTATION

  17. GREEN CONSTITUTES: A WIND FARM DEVELOPER • Wind and energy resource assessment and optimize design layout. • Land acquisition, license, planning permission, PPA, EIA, EPCC. Greenfield • Development fund management and reporting. Development • Selection of turbines based on greenfield development. • Installation and Commissioning of turbines, Civil and Electrical Construction. Turnkey • Unmanned and fully automatic wind plant technical management. • Wind energy forecasting - new Technical and Commercial • Financing and Accounting services. Management

  18. WHY GAMESA ?  Innovative blade for low wind sites (CLASS IIIA)  97m rotor (G9x 2.0MW) maximizes AEP up to 14% Recommends:  New optimized airfoil to guarantee minimal noise  Production of lighter blades using fiberglass and carbon fiber  Compliance with the main International Grid Codes  “ Gamesa WindNet ” for remote monitoring and control system with Web Access  “ Gamesa NRS” to minimize noise emissions

  19. HOW DOES A WIND FARM LOOKS LIKE?

  20. PRODUCTS PV Modules coupled with MICRO INVERTERS

  21. CARBONMETRICS PV MODULES We will oversee your entire project and provide a single point of contact and accountability throughout the life of your system. Our in-house engineering team will custom design your solar system based on your home's architecture and your family's projected electrical needs.

  22. PROJECT MANAGEMENT We have a full Customer Care team that will plan out your installation and coordinate all team members. They will keep you apprised of project status every step of the way.

  23. CARBONMETRICS MICRO-INVERTER The key feature of a true micro-inverter is its one-to-one control over a single panel, and its mounting on the panel or near it. The principal advantage is that shading of any one solar panel, or a panel failure, does not disproportionately reduce the output of an entire array. Each micro-inverter can act as a maximum power point tracker for its connected panel. CM250-E CM250-N

  24. TECHNICAL SPECIFICATIONS

  25. PRODUCTS THE “SMART GRID” SYSTEM

  26. WHAT MAKES A SMART GRID ? It is a system that optimizes power supply and delivery, minimizes losses, is self-healing, and enables next- generation energy efficiency and demand response applications. A Smart Grid would potentially provide constant communications between a utility and its customers to optimize energy efficiency and mitigate emissions.

  27. THE CENABLE SOFTWARE It’s a software that has an effective graphical interface that shows you your energy consumption, per device connected, on a 30 minutes basis. You can even turn the devices on or off from your location.

  28. SMART GRID HARDWARES DISTRIBUTION BOARD WITH CLAMP-ON SENSORS REAL TIME SMART METER AND SWITCH PLUG-IN REAL TIME SMART METER AND SWITCH

  29. PRODUCTS LIGHT EMITTING DIODS (L.E.D)

  30. PRODUCT RANGE  Conventional T5, T8 indoor lighting tube  Indoor LED Bulb  Indoor LED Crystal Lamp  LED Down Light  LED Spot Light  LED Street Lamp  LED Tunnel Lamp  LED Mine Lamp

  31. FEATURES  Life Span of 50,000 – 100,000 hours  Uses only 1/3 of Compact Fluorescent and 1/30 of incandescent Light  High Illumination  Highly recommended to incorporate with wind turbines /solar panels due to its low power usage

  32. SERVICES WIND MONITORING SERVICES kW class assessment MW class assessment

  33. TOPOGRAPHICAL INDICATORS

  34. IMPORTANCE OF WIND RESOURCE ASSESSMENT  Same like an oil exploration, WIND being an ENERGY RESOURCE also can be measured and classified.  It enables developers to locate the best wind speed area and estimate the future energy production.  Therefore it is crucial to the successful development of wind farms

  35. SERVICES ENERGY MANAGEMENT AND AUDITING (E.M.A)

  36. THE PROCESS  PRE AUDIT: We request details of your utility bills, building plans, electrical plans.  AUDIT: During the audit, we will undertake a full energy audit of your buildings, behavioral energy/water usage, and climate assessment for renewable energy considerations.  REPORTING: We will provide a report with our findings and recommendations. We will explain the required actions, solutions and options. We will work with you directly to implement the report findings.  POST AUDIT REVIEW: We will review your utility bills in 3 months to review your consumption. At this stage, we will make additional recommendations (if warranted). In addition, you will always have access to us for questions and additional implementation

  37. G REEN C ONSTITUTES R ENEWABLE ENERGY AND ENERGY EFFICIENCY

  38. HOW DOES IT BENEFITS YOU? Long Term Cost Effectiveness : Promising ROI Promote Healthier Lifestyle : Reducing carbon footprint Create Awareness : Green profiling Investment Tax Allowance Contribute up to 10 points under GBI

  39. T HANK Y OU QUESTIONS GREEN CONSTITUTES SDN BHD (916287-M ) No. 14-B, Jalan SG 3/5, Taman Sri Gombak, 68100 Batu Caves, Selangor, MY T: +603 6186 6931 F: +603 6185 6931
