No major behavioral changes for drivers. A refueling station for EVs similar to a liquid refueling For station Char ging in M inutes, not hours successful Available network of charging rollout infrastructure available When and

  2. No major behavioral changes for drivers. A “refueling” station for EVs similar to a liquid refueling For station Char ging in M inutes, not hours successful Available network of charging rollout… infrastructure available When and where the vehicle runs low on charge Image from Philippine Travel Notes efficient energy management both on the supply and usage side

  3. SMART NETWORK OF ENERGY AWARE ELECTRIC VEHICLES AND CHARGING INFRASTRUCTURE

  4. SYSTEM OVERVIEW Driver Side Rider Side Charging E-trike Probe Mobile Phone Mobile Phone Mobile Phone Station Probe Wireless Gateway Data and Algorithm Servers Wireless Gateway

  5. SYSTEM OVERVIEW Driver r Sid Side E-Trike Probe Mobile Phone Wireless Gateway (to data and algorithm servers)

  6. SYSTEM OVERVIEW Rid Rider r Si Side Mobile Phone Mobile Phone Wireless Gateway (to data and algorithm servers)

  7. SYSTEM COMPONENTS RIDE-SHARING MONITORING AND GUIDANCE SYSTEM Charging station placement, driving route, and booking match calculations DATA HARVESTING SYSTEM Communication systems for data collection and analytics RIDE-SHARING MOBILE APPS Driver and rider application and internet platform

  8. RIDE-SHARING SYSTEM Ro Route te Com Computati tion and nd Matchi tching - Crude route computation using Dijkstra’s algorithm - Ride-sharing matching computation using: - Empirically-derived GrabShare algorithm (short distance) - Expansive search-based matching (long distance)

  9. DATA HARVESTING

  10. CHARGING STATION

  11. 20 E-TRIKES... … to be driven in each testing location to service admin personnel for official purposes

  12. TESTING LOCATIONS University of the Philippines Cagayan State University Diliman Campus Carig Campus

  13. Optimal placement of charging infrastructure Algorithm to strategically place fast charging stations within a local transportation system to address range anxiety towards the use of electric tricycles. This methodology will be used to pilot a network of charging infrastructure in a locality with existing deployment of electric tricycles.

  14. E-TRIKE RIDE-HAILING SERVICE

  15. … lets you book a ride in your community

  16. Choose where to ride and alight!

  17. Wait for a ride... … and a driver will arrive!

  18. Ride and enjoy!

  19. DRIVER … is a companion app for drivers.

  20. Minimal controls to focus on driving.

  21. Accept or reject rides simply and flexibly.

  22. Manage rides without the fuss!

  23. ADMIN … manages your Hatid community.

  24. TARA NA AT MAGPAHATID* SA HULYO 20! * UP Diliman, CSU Carig, and Tuguegarao RGC only * Faculty and staff only
