ICE Workshop, STAR Global Conference 2012 March 19-21 2012, Amsterdam Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss , Thomas Lauer

Content  Introduction & Motivation  Mesh Description  Definition and Implementation of Multi-Component Fuels  Verification of Spray Dynamics  Analysis of Piston Cooling due to Wall Wetting  Wall Film Formation for Single- and Multi-Component Fuels  Conclusion  Summary and Outlook Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 2

Introduction  In order to reduce soot emissions and oil dilution of future SI-engines with direct injection a fundamental knowledge about wall film formation and its prediction is crucial.  In the presented work, a turbocharged SI engine with direct injection was used to analyze the influence of different injection timings on the wall film formation.  Numerical investigations and accompanying experiments at the engine test bench have been carried out to show the benefit of the multi-component fuel approach. Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 3

Motivation high abrupt increase of soot formation 20°CA low early late The measured soot increased abruptly after a critical threshold of the injection start timing (SOI) was exceeded.  Soot is an indicator for a diffusive combustion of wall film  Analysis of the differences in wall film formation depending on SOI Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 4

Mesh Description • Mapped meshing in es-ice V4.16 • detailed modelling of the spark plug geometry 6-hole injector • thin boundary layers Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 5

Fuel Definition RON95 I 7 component approach having the same distillation curve as gasoline reference fuel high boiling temperature low-boiling temperature Batteh, J. J.; Curtis, E. W.: Modeling Transient Fuel Effects with Alternative Fuels, SAE Paper 2005-01-1127 Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 7

Fuel Definition RON95 II Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 8

Fuel Definition RON95 III Implementation in user subroutine dropro.f  Bulk Properties: Calculated for the 7 component mixture (density, viscosity, surface tension coefficient, thermal conductivity)  Component properties: Vapour pressure for each component as temperature dependant functions having the form of the Clausius Clapeyron equation: y = y 0 + C 1 e T C 2 Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 9

Spray Dynamics – Verification with Optical Measurements 1°CA after injection start 10°CA after injection start 25 mm 50 mm  Droplet spectrum definition according to PDA spray measurements  Good correlation of spray penetration Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 10

Analysis of Piston Crown Cooling due to Wall Film Wetting Static Mesh @ 450°CA Motivation: Checking if a constant piston wall temperature is acceptable A moving mesh with solid cells is not possible yet. Fluid Cells Therefore, the analysis was performed on a static mesh. Calculation of the piston temperature considering Solid Piston evaporative cooling and Cells heat conduction (Aluminium) Constant Ambient Temperature Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 11

Analysis of Piston Crown Cooling due to Wall Film Wetting  Formation of Liquid Film Liquid Film Thickness [µm]  A maximum cooling of ΔT ~5 K was calculated.  Using a constant piston crown wall temperature is justified. Δ Temperature [K] 0 -5 Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 12

Investigated Injection Timings high “early injection” “late injection” 20°CA low Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 13

Formation of Liquid Film, “late injection” Liquid Film Thickness [µm] 1-Component Fuel Multicomponent Fuel Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 14

Investigated Injection Timings high “early injection” “late injection” 20°CA low Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 15

Formation of Liquid Film, “early injection“ Liquid Film Thickness [µm] 1-Component Fuel Multicomponent Fuel Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 16

Comparison with Smokemeter Measurements high The remaining wall film mass correlates with the measured smoke number low late injection early injection Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 17

Multi-Component Liquid Film Composition, “early injection“ injection high boiling temperature low-boiling temperature Components with lowest mass fractions in the fuel definition Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 18

Vapour Sources, “early injection“ 50°CA Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 19

Mixture Preparation @ Spark Timing 717°CA, “early injection“ 1-Component Fuel Multi-Component Fuel Lambda [-]  4% higher global lambda  12% higher lambda close to the spark plug Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 20

Mixture Preparation @ Spark Timing 717°CA, “late injection” 1-Component Fuel Multi-Component Fuel Lambda [-]  global lambda is equal  lambda distribution is similar Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 21

Conclusion  The CFD simulation for an early injection timing showed significant differences between the single- and multi-component fuel approach.  The intensified wall wetting and the remaining wall film mass after compression for early injection timings could only be represented correctly with the multi-component fuel definition.  The fast wall film vaporisation of the single-component fuel led to an overestimation of the charge homogenisation and the fuel vapour fraction especially close to the spark plug.  For operating points where only low wall film masses are to be expected the single-component approach is a reasonable simplification. Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 22

Summary and Outlook  At the test bench a sharp increase of soot emissions was measured when the start of injection exceeded a critical limit .  With a 7 component fuel approach it was possible to calculate a remaining wall film mass after compression that correlated with the measured soot number .  In contrast, the single-component fuel led to considerable differences in wall film mass and lambda distribution for an early injection.  Therefore, the multi-component fuel approach has a big potential especially for operating points with intensified wall wetting e.g. cold start conditions and for a following combustion calculation where lambda needs to be as accurate as possible.  For alternative fuels with a higher heat of vaporisation like ethanol, a moving mesh simulation with solid piston cells would be necessary to account for the intensified wall cooling. Simulation of the Mixture Preparation for an SI Engine using Multi-Component Fuels Michael Heiss | Sheet 23
