PLM-based Solutions for Extended Enterprises David BAUDRY, dbaudry@cesi.fr LUSINE Research Lab, CESI FRANCE LE CESI : ENSEIGNEMENT SUPERIEUR ET FORMATION PROFESSIONNELLE
PLM-based Solutions for Extended Enterprises Main Outputs of the WP3 of the project: Building an expertise network for an efficient innovation and training (BENEFITS), INTERREG Programme France (Channel) England. Jul 2012 – Jun 2015 WP3 - Maintaining and developing the industrial tissue WP3 Academic partners : Centre for Innovative Product Development & Manufacturing - James GAO, Head of the CIPDM CESI – IRISE and LUSINE laboratories work lead by Mourad MESSAADIA , Lecturer and Researcher 2 CAD’15 – London
Overview of PLM LE CESI : ENSEIGNEMENT SUPERIEUR ET FORMATION CAD’15 – London PROFESSIONNELLE
PLM and Literature review Standard ICT Process 4
PLM Definitions PLM is an integrated approach including a consistent set of methods, models and IT tools for managing product information, engineering processes and applications along the different phases of the product lifecycle. PLM addresses not only one company but a globally distributed, interdisciplinary collaboration between producers, suppliers, partners and customers (Abramovici, 2005) . For the analyst (CIMdata) , PLM is defined as: “a strategic business approach that applies a consistent set of business solutions in support of the collaborative creation, management, dissemination, and use of product definition information across the extended enterprise from concept to end of life – integrating people, processes, business systems, and information. ” (IBM) defines PLM as “… a strategic approach to creating and managing a company's product-related intellectual capital, from its initial conception to retirement ” For the PLM Interest Group (PLMIG) , PLM includes research, management of customer requirements, product development CAD, CAM, simulation, rapid prototyping and virtual concurrent engineering, product / process design, sourcing of components, machining digital control, collaboration via the web with customers and suppliers. PDM is the IT Platform for PLM, the terms 'PLM System' and 'PDM System' mean the same thing, and are interchangeable 5 CAD’15 – London
PLM Definitions: Synthesis Terms listed in different definitions multitude of acronyms and other topics associated to PLM. Terms related to PLM Autors CIMData (Miller, 2003) Collaborative Mode (PLM Interst Group) (Abramovici, 2005) (Abramovici et al., 2004) (Saaksvuori, 2008) Strategic approach (CIMData), (IBM) (Amman, 2002) (PLM Interst Group) Requirement management (CIMData) (Saaksvuori, 2008) (Fathi, 2007) PLM Process (Schuh, 2006) (Feldhusen, 2008) (PLM Interst Group) (CIMData) (Saaksvuori, 2008) (Fathi, 2007) PLM Architecture (IT tools) (Feldhusen, 2008) (Miller, 2003) (Abramovici, 2005) (Miller, 2003) Integrated Business approach (Abramovici, 2005) (Feldhusen, 2008) Integrated management (Feldhusen, 2008) Product structure (PLM Interst Group) (PLM Interst Group) Concurrent Engineering 6 (Abramovici, 2005) Engineering process management
Overview of PLM Need of Information management 3D 2D ( 1980s) CAD evolution 1. (Computer aided design and manufacturing) 2. (1990s) PDM: Managing technical data flow (CAD, technical data, Specification, Standardisation (STEP, ..), …) 3. (Early 2000s) PLM (Product Lifecycle Management): DATA+Process+Human Managing technical data through (Vaulting) allowing the access of different department Process management (Engineering Change request, Engineering Change Order etc.) Product structure management (BOM, etc.) and family product PLM system (Tool) evolution: Workflow and change management Knowledge management Web-based solution Extended enterprise and distributed product development 7 CAD’15 – London
Product Lifecycle Management (PLM) 8 CAD’15 – London
Product Lifecycle Management (PLM) 9
PLM axes proposed from the literature review Change management Defining general guidelines Standards External/internal Evaluation STEEP, SWOT Capture, Dissemination, Transformation, sharing Business model supporting End of life decision making product/service Product portfolio Decides Strategy Process Defines Implement Use Tools Organization Specification of the operational organization/ 3D Model, CAX (CAD, CAM, …) Structure Strategy is the highest level, where important decisions are taking and in Requirements tools (Doors, etc.) this level we define the kind of organization and processes. The Skills, motivation, turnover management PDM, ERP, CRM, SCM, MES, … tools organizational level describes the shape of structure based on processes. People and culture management Product models Tools level is the implementation of processes and the support for the organization. 10 CAD’15 – London
Origin of the project and industrial issues LE CESI : ENSEIGNEMENT SUPERIEUR ET FORMATION CAD’15 – London PROFESSIONNELLE
Industrial issues Booming of digital engineering for product development, industrialization, manufacturing and product services in many industrial sectors. Knowledge management, constraints links to subcontracting and concurrent engineering including the development of mechatronic products. Courtesy O2M project 12 CAD’15 – London
Generic V-cycle used during system development Requirements System Analysis Acceptance System System engineering System Analysis and Integration (Ex: SysML PLM solution Design and Test language) Module Module Simulation. analysis and Integration Design and Test (Ex: Simulink, Modelica) HW/SW Components components validation Design CAD Tools (mechanical, HW / SW Implementation electrical, multi-physics) and Unit Test + prototype Simulation multi-physiques 13 CAD’15 – London
V-cycle for the global system and for the equipments (OEM and suppliers) Requirements System Analysis Acceptance System System Analysis and Integration Design and Test Module Module System analysis and Integration Design and Test HW/SW Components components validation Design Product How to manage the HW / SW Implementation development in communication and Unit Test + prototype collaboration issues, design with suppliers sharing, project management, … ? Equipment 1 Equipment 2 14 CAD’15 – London
Industrial issues Problems to be addressed: Product development/manufacturing in collaboration with suppliers (communication issues, design sharing, project management, …) Management of various versions and configurations of products (including supplier parts) Knowledge management (requirements, manufacturing capabilities, testing knowledge, suppliers knowledge, …) Evolution of the Information System (IS) and processes to take into account of the entire Product Lifecycle Management Structured databases, process based information management (PDM, PLM), web services, social media 15
OEM Industrial Needs LE CESI : ENSEIGNEMENT SUPERIEUR ET FORMATION CAD’15 – London PROFESSIONNELLE
OEM Industrial Investigation The investigation covered the three specific areas of: Employee Collaboration and Knowledge Sharing Product Lifecycle Management and ICT Tools Maintenance, Servicing and Testing Methodology employed: Informal individual audio-recorded face to face interviews: 60 - 90 minutes 17 employees, inc. Plant Manager, Manufacturing Engineers and Production Line Team Interview panel of 3 Standardised 7-part questionnaire with a mix of open and closed questions Audio transcriptions of interviews for analysis purposes Aim: To identify organisational practices and challenges in relation to the 3 subject areas Essop, I.A., Evans, R.D., Giddaluru, M.P., Wan, S., Gao, J.X., Baudry, D., Mahdikhah, S. and Messaadia, M. 2015. An Investigation into Current Industrial Practices relating to Product Lifecycle Management in the Manufacturing Industry. Computer-Aided Design and Applications. 17 CAD’15 – London
Investigation results Results relating to PLM include… Product information traceability and Integration issues CAD PDM PLM Cross functional Data Sharing between different business units Common standards issues Change management Supplier integration Part numbers not consistent between legacy and current systems – prone to error 18 CAD’15 – London
Investigation results Results relating to Maintenance include… No current methods to capture the degradation of the equipment Decisions made dependent on engineers’ experience – not by decision support system Limited knowledge sharing between manufacturing and assembly line Results relating to KM include… E-mail used as preferred communication method – relied on too much Face to face collaboration is encouraged to speed-up communication Provides opportunity to listen and ask questions • Difficult to get everybody involved in a project together at the same time • Face to face and telephone communication relied upon for supplier collaboration Builds trust – get to know suppliers on a personal level • Project Teams can create and manage their own intranet sites – ‘Team Rooms’ 19 CAD’15 – London
Knowledge Management and Evolution of the Information System LE CESI : ENSEIGNEMENT SUPERIEUR ET FORMATION CAD’15 – London PROFESSIONNELLE
