ETCS Mission Gage and Fixture LLC Company Profile Founded in 2013, - PowerPoint PPT Presentation

ETCS Mission Gage and Fixture LLC Company Profile Founded in 2013, fully dedicated to gauge & fixture ISO 9001:2008 certified 3,000 Plant area 180 Employees in total Gauge & Assembly fixture design and manufacturing


  1. ETCS Mission Gage and Fixture LLC

  2. Company Profile Ø Founded in 2013, fully dedicated to gauge & fixture Ø ISO 9001:2008 certified Ø 3,000 ㎡ Plant area Ø 180 Employees in total Ø Gauge & Assembly fixture design and manufacturing Ø Welding fixture design, simulation and manufacturing Ø Capacity: 140 medium gauges & fixtures per month Ø Size up to 5 meter

  3. We Offer Gauge for Metal Parts Gauge for Metal Assembly Welding Fixture Gauge for Plastic Parts Gauge for Plastic Assembly

  4. Project Management Design Review Machining PO Review Material Preparation Project Management Assembly Fixture Delivery Buy Off CMM Check 3rd Party Cert's Gauge Improvements

  5. Engineering Center Gauge & fixture designer : 30(5 of them with welding fixture experience), obtained many nation patents Capacity: Every month can complete 140 sets of fixture

  6. Machining Center Dmanisi 5 Axis Machine: 2 sets 3 Axis machine: 9 sets Brand: DMU 60 & 80 monoBLOCK Precision : 0.006 mm/0.00023 in

  7. New Equipment Ordered in 2018 5 axis Machine 5 axis Machine (Imported from German) (Imported from Italy) Brand :DECKEL MAHO Brand :BRETON MATRIX 800 (DMU 95 Mono BLOCK) Parameter: 3000*2000mm Parameter: 1000*750mm Qty:4 sets Qty: 2 sets 3 axis Gantry CNC High Speed 3 axis CNC AWEA LP-4025Z 4020*2400mm 1 Set AWEA AF series AWEA LP-3021Z 3020*2010mm 1 Set Qty:10 sets

  8. New Facility Floor Plans 6000 ㎡ Plant area

  9. Assembly Center Experienced technician with rich experience on Gauge/assembly Gauge/ welding fixture assembly and debugging

  10. Quality Assurance Hexagon 5 Meters CMM Software: PC DMIS 2013MR1 Table size: 5000X2500X1800 mm

  11. Gauge for Metal Parts - Aluminum Size: 1200X940X495mm Size: 550X400X306mm Size: 1400X800X350mm Size: 740X520X290mm

  12. Gauge for Metal Parts - Resin Size: 1490X1005X628mm Size: 1380X638X877mm Size: 1840X628X864mm Size: 1140X868X929mm

  13. Gauge for Metal Parts - Steel Size: 740X520X290mm Size: 600X380X230mm Size: 750X420X240mm Size: 900X800X300mm

  14. Gauge for Plastic Parts - Aluminum Size : 700X380X500mm Size: 1100X530X400mm Size: 600X500X260mm Size: 1100X900X460mm

  15. Assembly Gauge - Metal Assembly Size: 1400X1000X600mm Size: 2200X1300X600mm Size : 1059X1406X367mm Size : 700X600X380mm

  16. Assembly Gauge - Plastic Assembly Size: 1500X1000X1600mm Size: 2600X1300X1400mm

  17. Welding Fixture Manual welding fixture design, simulation and manufacturing ability, turnkey project overseas experience with parts welding experience, plus robot welding fixture design, simulation and manufacturing capability

  18. Direct Customer

  19. End Customer Customer Customer Customer
