CASE STUDIES: ENTREPRENEURSHIP ON THE ISS D-Orbit – Luca Rossettini, Founder Benevolent Technologies – Jeremy Jo, Director of Product Engineering & Development Kentucky Space/Space Tango – Kris Kimel, President & Founder Zero Gravity Solutions – Rich Godwin, CEO HNu-Photonics – Dan O’Connell, CEO Terminal Velocity Aerospace – Dominic DePasquale, CEO

D-SAT and Decommissioning Demonstration Chicago, 19 June 2014 Dr. Luca Rossettini, CEO 2

COMPANY CONFIDENTIAL

offers proprietary and independent smart motors for satellites to safely re-orbit them ISS is the enabling factor to at the end-of-life, eliminating end-of-life effort and pain, demonstrate the technology increasing lifetime of satellites and create worldwide impact and revenues for space operators. 4 1

5 5

6

7

COMMERCIAL SPACE AT RISK IMPACT ON OPERATORS Avoidance maneuvers increase in frequency; More than 6000 satellites are Proper decommissioning wastes orbiting around the Earth an amount of onboard propellant that would otherwise be used to Only 900 satellites are fully extend the satellite mission in operating. The others fly orbit; uncontrolled at about 30,000 km/h, Service life estimation and at risk of collision with other decommissioning operations are spacecrafts or falling down into our complex activities; planet. Monitoring dead satellites will soon The risk of collision in orbit is be another activity charged to increasing exponentially (doubled satellite operators. in the last 3 years). Only few satellites are LESS PROPELLANT = LESS REVENUES decommissioned according to international guidelines. 8

STRATEGY As of today, going into Space to clean space junk is neither economically convenient nor effective. High technological B$ spacecrafts ’ theoretical target is to clean up to 10 satellites per year. Market demand foresees more than 100 new satellites per year (1200 in the next 8 years). BASIC SPACE STRATEGIC PRINCIPLES STEPS: Stop increasing the Make it economically viable; Remove the junk concentration that is already there. of defunct objects in space; D-Orbit offers to satellite operators the most convenient solution to drastically reduce liabilities and costs and at the same time increase revenues. D-Orbit makes possible a clean and sound access to Space 9

10 10

DECOMMISSIONING DEVICES Unique and patent pending smart Independent from the Safe, controlled and quick propulsive device, easy to install satellite, it may works even if decommissioning (few hours) before launch the satellite does not both for LEO and GEO satellites 11

END-OF-LIFE / DEFUNCT EASY RE-ORBITING INDEPENDENT QUICK RE-ORBIT CHEAP & COMPACT SAFE REENTRY AREA EASY INTEGRATION 12 12

Strong master PATENT covering the use of decommissioning device in space and all its sub-units In January 2014 D-Orbit patent application was filed in 11 countries worldwide 13 13

ADVANTAGES for Operators Increased mission time Zero impact costs Controlled re-orbit Backup thruster Stress-free decommissioning 15 15 * C. Wiedemann , “Analyzing costs of space debris mitigation methods” and K.K. Galabova , MIT, “Economic case for the retirement of geosynchronous communication satellites via space tugs”

“Thus, operators can extract full useful life from their satellite and still be able to safely “clean up their mess” at the end. The D-Orbit solution is clean, simple and relatively inexpensive. For a commercial operator its cost would likely be offset by reduction of liability insurance premiums.” Dr. Edward Cornet, former Booz Allen Hamilton partner 17 17

RECENT COMMERCIAL MILESTONES May 2014 FIRST LETTER OF INTENT by one of the two biggest satellite operators worldwide “[…] The parties express their wish, and share their interest, for assessing the possibility of integrating a d-Orbit device in satellite platform(s) to perform end of life re-orbiting. Both parties may convene on mutually-agreed milestones aimed at reaching intermediate critical design reviews with the aim to be able to have a d-Orbit device available by the end of 2015 such that it can be assessed against the other available re-orbiting techniques. […]” FIRST COOPERATION AGREEMENT by one of the biggest satellite manufacturer worldwide 18

CUSTOMERS OPERATORS LAUNCHERS (confirmed) Heavy Medium Small 2015 2015 2015 Atlas 5 5 Delta 2 0 Dnepr 3 Sat/y Up to Confirmed Delta 4 3 Falcon 9 12 Rockot 0 INTELSAT 2 2020 yes H-II 3 Taurus 2 3 Falcon 1 0 SES 2.5 2020 yes EUTELSAT 2 2020 yes Long March 3 3 Cyclone 3 PSLV 6 INMARSAT 1.5 2018 yes Proton 3 Long March 2 3 Minotaur TELESAT 1 2018 no Zenit 2 Long March 4 3 Taurus SKY PERFECT JSAT 1 2020 no Ariane 5 11 GSLV 1 Pegasus WE HAVE IDENTIFIED 10 POTENTIAL PROGRAMS (SAT + LAUNCHERS) THAT WILL BEGIN BEFORE 2016. WE PLAN TO GET INTO 3+ OF THEM. 19

REGULATIONS: UPDATE Today : You break it, you own it! Launching state (and consequently satellite owner) is liable for any damage produced by a satellite, dead or alive. IADC (international committee) guidelines force EVERY satellite to be decommissioned at end-of-life TODAY ALMOST ALL THE NATIONS WITH ACCESS TO SPACE HAVE A NATIONAL LEGAL FRAMEWORK FOR SPACE DEBRIS MITIGATION OR APPLY INTERNATIONAL GUIDELINES BY CONTRACT TO COME: compulsory back-up system for decommissioning (source: IADC) 20 20

MILESTONES AND CURRENT ACTIVITIES 21 21

D-ORBIT ROADMAP 2012 2011 2013 D-Orbit D-Orbit Launch Validation in Test on ground established demonstrator qualification space 2014 2015 - 2016 Technology Letter Demonstration Contract Revenues in orbit qualification of intent 22

THE DEMONSTRATOR D-Orbit demonstrator was successfully bench tested in January 2012. 23

ELECTRONIC UNIT AND SIU QUALIFICATION D-Orbit electronic unit and SIU was successfully launch qualified in August 2013. 24

25

21 ST NOVEMBER 2013 • D-Orbit command and control unit and safe ignition units were qualified for launch and sent in space for final validation. • Launch happened at 7am from Yasni base, Russia. • Launch was successful, all satellites correctly positioned in orbit. • All satellite’s systems nominal. • Next: test and validation in orbit. 26 26

DECOMMISSIONING DEMONSTRATION D-SAT FIRST SATELLITE REMOVED IN A QUICK, SAFE AND CONTROLLED MANNER 27

24 min Decommissioning time 450 km Nominal altitude. Up to 600km 12N 65E Disposal area 0.00000001% Impact probability ISS Released by ISS into space D-SAT IN NUMBERS 28

Radio Experiment: Alert message Real time trajectory and impact location Decommissioning Device Safe and Arm Device D-Orbit Motor 29

Manoeuver Atmospheric Entry Disposal Area Ground Station B Tracking Capability 30

GOALS • USE ISS AS AN ENABLING PLATFORM FOR TESTING INNOVATIVE TECHNOLOGY AT HIGH SOCIAL AND ECONOMIC IMPACT • ACCELERATE THE ADOPTION OF THE TECHNOLOGY • CREATE WORLDWIDE AWARENESS ON SPACE SEGMENT BENEFITS AND SPACE DEBRIS THREAT • CLEAN AND SAFE ACCESS TO SPACE DELIVERING BENEFITS AND LOWERING COSTS 31

OUR RESPONSIBILITY Every profitable choice should be sustainable. Every responsibility should take care of who we care most. Clean and Safe Access to Space is our responsibility. 32

Contact person: Luca Rossettini, CEO Tel US: +1 (415) 684-3673 / +1 (805)-304-0363 Tel Europe: +39 340 760 7035 / +39 02 3671 4010 Email: luca.rossettini@deorbitaldevices.com www.deorbitaldevices.com Headquarters: Milano, Via Mazzini 2, 20123 ITALY Operating Office: ComoNext Technology Park, Via Cavour 2, 22074 Lomazzo (CO) – ITALY – Tel: +39 3671 4010 Administrative Office: Sesto Fiorentino (FI), Via Madonna del Piano 6, 50019 – ITALY - Tel: +39 055 457 4666 D-ORBIT INC . – Simi Valley, CA 93062, USA - Tel.: +1 (805) 304 9567 33 Email: info@deorbitaldevices.com

D- ORBIT’S DEVICES STANDARDS COMPLIANCE ECSS-E-ST-10-03C Testing ECSS-E-ST-40 C Safety ECSS-E-ST-10-04C Space environment ECSS-E-ST-60-13C Commercial electrical ECSS-E-ST-10-12C Radiation MIL-STD-1576 Electroexplosive ECSS-E-ST-20 C Electrical & Electronic SSP 51700 ISS Payload Safety ECSS-E-ST-20-07C Rev1 Electromagnetic MIL-STD-1546 Part, materials, procs. ECSS-E-ST-33-11C Explosive systems GSFC-STD-7000 General Environment ECSS-E-ST-40 C Software MIL-HDBK-271F Reliability Analysis EWR – 127 – 1 ECSS-E-ST-10 C Product Assurance Range Safety Reqs ECSS-E-ST-20C Rev1 Quality Assurance DoD 6055.09-STD DoD Ammunition ECSS-E-ST-30-11C Rev.1 EEE components Safety NSTS 1700.7B D-Orbit is in the process of being EN/AS 9100 certificated: Quality Management System for Aerospace Industry 34
