ECE232: Hardware Organization and Design Lecture 5: MIPs - PowerPoint PPT Presentation

ECE232: Hardware Organization and Design Lecture 5: MIPs Decision-Making Instructions Adapted from Computer Organization and Design , Patterson & Hennessy, UCB Overview Computers need to make decisions Microprocessors support


  1. ECE232: Hardware Organization and Design Lecture 5: MIPs Decision-Making Instructions Adapted from Computer Organization and Design , Patterson & Hennessy, UCB

  2. Overview  Computers need to make decisions • Microprocessors support “conditional” operations  Operations typically called branch operations  Connections with common Java and C language constructs • If, else, switch, for loops, do loops  Conditional instructions have a specific format ECE232: Decision Making Instructions 2

  3. Example: Compiling C if-then-else Example  if (i==j) f = g + h; C Code else f = g - h; bne $s3, $s4, Else Assembly add $s0, $s1, $s2 j Exit; # new: unconditional jump Else: sub $s0, $s1, $s2 Exit: New Instruction: Unconditional jump  j LABEL # goto Label ECE232: Decision Making Instructions 3

  4. Compiling Loop Statements C code:  while (save[i] == k) i += 1; • i in $s3, k in $s5, address of save in $s6 Compiled MIPS code:  Loop: sll $t1, $s3, 2 add $t1, $t1, $s6 lw $t0, 0($t1) bne $t0, $s5, Exit addi $s3, $s3, 1 j Loop Exit: … ECE232: Decision Making Instructions 4

  5. while statement while ( condition ) { statements } while_start_label : # MIPS code for the condition expression #(if condition satisfied set $t0=1) beq $t0, $zero, while_end_label # MIPS code for the statements j while_start_label while_end_label : ECE232: Decision Making Instructions 5

  6. do-while statement do { statements } while ( condition ); do_start_label : # MIPS code for the statements do_cond_label : # MIPS code for the condition expression #(if condition satisfied set $t0=1) beq $t0, $zero, do_end_label j do_start_label do_end_label : ECE232: Decision Making Instructions 6

  7. for loop for ( init ; condition ; incr ) { statements } # MIPS code for the init expression for_start_label : # MIPS code for the condition expression #(if condition satisfied set $t0=1) beq $t0, $zero, for_end_label # MIPS code for the statements # MIPS code for the incr expression j for_start_label for_end_label : ECE232: Decision Making Instructions 7

  8. Basic Blocks A basic block is a sequence of instructions with  • No embedded branches (except at end) • No branch targets (except at beginning) A compiler identifies basic  blocks for optimization An advanced processor can  accelerate execution of basic blocks ECE232: Decision Making Instructions 8

  9. More Conditional Operations Set result to 1 if a condition is true  • Otherwise, set to 0  slt rd, rs, rt • if (rs < rt) rd = 1; else rd = 0;  slti rt, rs, constant • if (rs < constant) rt = 1; else rt = 0; Use in combination with beq , bne  slt $t0, $s1, $s2 # if ($s1 < $s2) bne $t0, $zero, L # branch to L ECE232: Decision Making Instructions 9

  10. Comparisons - What about <,  , >,  ? bne, beq provide equality comparison  slt ( s et on l ess t han) provides magnitude comparison  slt $t0,$s3,$s4 # if $s3<$s4 $t0=1; # else $t0=0; Combine with bne or beq to branch:  slt $t0,$s3,$s4 # if (a<b) condition register bne $t0,$zero,Less # goto Less; Why not include a blt instruction in hardware?  • Supporting in hardware would lower performance • Assembler provides this function if desired (by generating the two instructions) ECE232: Decision Making Instructions 10

  11. switch statement switch ( expr ) { case const1 : statement1 case const2 : statement2 ... case constN : statementN default: default-statement } ECE232: Decision Making Instructions 11

  12. MIPS code for switch statement # MIPS code for $t0= expr beq $t0, const1 , switch_label_1 beq $t0, const2 , switch_label_2 ... beq $t0, constN , switch_label_N j switch_default switch_label_1 : # MIPS code to compute statement1 switch_label_2 : # MIPS code to compute statement2 ... switch_default : # MIPS code to compute default-statement switch_end_label : ECE232: Decision Making Instructions 12

  13. Switch Example switch (i) { //Assume i is in $s1 and j is in $s2; case 0: j = 3; break; case 1: j = 5; break; case 2: ; case 3: j = 11; break; case 4: j = 13; break; default: j = 17; } main: add $t0, $zero, $zero # $t0 = 0, temp. variable beq $t0, $s1, case0 # go to case0 addi $t0, $t0, 1 # $t0 = 1 beq $t0, $s1, case1 # go to case1 addi $t0, $t0, 1 # $t0 = 2 beq $t0, $s1, case2 # go to case2 addi $t0, $t0, 1 # $t0 = 3 beq $t0, $s1, case3 # go to case3 addi $t0, $t0, 1 # $t0 = 4 beq $t0, $s1, case4 # go to case4 j default # go to default case case0: addi $s2, $zero, 3 # j = 3 j finish # exit switch block ECE232: Decision Making Instructions 13

  14. Unconditional branches Unconditional branch:  j L1 jr $s5 (useful for large case statements and big jumps) ECE232: Decision Making Instructions 14

  15. Example 2 Convert to assembly:  while (save[i] == k)  Loop: sll $t1, $s3, 2 i += 1; add $t1, $t1, $s6 lw $t0, 0($t1) bne $t0, $s5, Exit i and k are in $s3 and $s5  addi $s3, $s3, 1 and j Loop base of array save[] is in Exit:  $s6 ECE232: Decision Making Instructions 15

  16. SPIM Example switch (i) { //Assume i is in $s1 and j is in $s2; case 0: j = 3; break; case 1: j = 5; break; case 2: ; case 3: j = 11; break; case 4: j = 13; break; default: j = 17; } main: add $t0, $zero, $zero # $t0 = 0, temp. variable used in switch beq $t0, $s1, case0 # go to case0 addi $t0, $t0, 1 # $t0 = 1 beq $t0, $s1, case1 # go to case1 addi $t0, $t0, 1 # $t0 = 2 beq $t0, $s1, case2 # go to case2 addi $t0, $t0, 1 # $t0 = 3 beq $t0, $s1, case3 # go to case3 addi $t0, $t0, 1 # $t0 = 4 beq $t0, $s1, case4 # go to case4 j deflt # go to default case case0: addi $s2, $zero, 3 # j = 3 j fin # exit switch block ECE232: Decision Making Instructions 16

  17. Summary  Conditional operations affect program flow based on data values  Microprocessor makes decision based on results of arithmetic and logic operation  Know the difference between branch and jump  Useful for C/Java loops, if-else, and switch statements ECE232: Decision Making Instructions 17
