1 Draft Some Rare-Event Simulation Methods for Static Network Reliability Estimation Pierre L’Ecuyer Universit´ e de Montr´ eal, Canada based on joint work with Zdravko Botev , New South Wales University, Australia Richard Simard , Universit´ e de Montr´ eal, Canada Bruno Tuffin , Inria–Rennes, France Summer School in Monte Carlo Methods for Rare Events Brown University, June 2016

2 Draft Aim Introduce and illustrate some rare-event simulation ideas that are less standard but have potential, via a simple application. ◮ Conditional Monte Carlo with auxiliary variables. ◮ Splitting when splitting does not seem to apply. ◮ Strategies for approximate zero-variance importance sampling.

3 Draft A static system reliability problem A system has m components, in state 0 (failed) or 1 (operating). System state: X = ( X 1 , . . . , X m ) t . Structure function: Φ : { 0 , 1 } m → { 0 , 1 } , assumed monotone. System is operational iff Φ( X ) = 1. Unreliability: u = P [Φ( X ) = 0].

3 Draft A static system reliability problem A system has m components, in state 0 (failed) or 1 (operating). System state: X = ( X 1 , . . . , X m ) t . Structure function: Φ : { 0 , 1 } m → { 0 , 1 } , assumed monotone. System is operational iff Φ( X ) = 1. Unreliability: u = P [Φ( X ) = 0]. If we know p ( x ) = P [ X = x ] for all x ∈ { 0 , 1 } m , in theory we can compute � u = p ( x ) . x ∈D = { X :Φ( X )=0 } But the cost of enumerating D is generally exponential in m . The X i ’s may be dependent.

4 Draft Monte Carlo (MC): Generate n i.i.d. realizations of X , say X 1 , . . . , X n , compute W i = Φ( X i ) for each i , and estimate u by ¯ W n = ( W 1 + · · · + W n ) / n ∼ Binomial ( n , u ) / n ≈ Poisson ( nu ) / n . Can also estimate Var [ ¯ W n ] and compute a confidence interval on u .

4 Draft Monte Carlo (MC): Generate n i.i.d. realizations of X , say X 1 , . . . , X n , compute W i = Φ( X i ) for each i , and estimate u by ¯ W n = ( W 1 + · · · + W n ) / n ∼ Binomial ( n , u ) / n ≈ Poisson ( nu ) / n . Can also estimate Var [ ¯ W n ] and compute a confidence interval on u . When u is very small (failure is a rare event), direct MC fails. Ex: if u = 10 − 10 , system fails once per 10 billion runs on average.

4 Draft Monte Carlo (MC): Generate n i.i.d. realizations of X , say X 1 , . . . , X n , compute W i = Φ( X i ) for each i , and estimate u by ¯ W n = ( W 1 + · · · + W n ) / n ∼ Binomial ( n , u ) / n ≈ Poisson ( nu ) / n . Can also estimate Var [ ¯ W n ] and compute a confidence interval on u . When u is very small (failure is a rare event), direct MC fails. Ex: if u = 10 − 10 , system fails once per 10 billion runs on average. Relative error � √ 1 − u MSE [ ¯ W n ] W n ] def here RE [ ¯ = = √ nu → ∞ when u → 0 . u For example, if u ≈ 10 − 10 , we need n ≈ 10 12 to have RE [ ¯ W n ] ≤ 10%. We would like bounded RE (or almost) when u → 0.

5 Draft Although our methods apply more generally, we focus here on graph reliability. Link i “works” iff X i = 1. The system is operational iff all the nodes in a given set V 0 are connected. X 11 6 9 X 6 X 10 X 13 3 X 2 X 5 5 8 X 9 1 X 3 X 8 X 12 X 1 2 4 7 X 4 X 7 Given X , Φ( X ) is easy to evaluate by graph algorithms. Challenge: How to sample X effectively.

6 Draft Conditional Monte Carlo Idea: replace an estimator X by E [ X | G ] for a σ -field G that contains def partial information on X . The CMC estimator is X e = E [ X | G ] . We have E [ X e ] = E [ E [ X | G ]] = E [ X ] and Var [ X ] = E [ Var [ X | G ] ] + Var [ E [ X | G ]] = E [ Var [ X | G ]]+ Var [ X e ] . � �� � � �� � Residual variance Var due to the when G is known variation of G (eliminated by CMC) Therefore (Rao-Blackwell theorem): Var [ X e ] = Var [ X ] − E [ Var [ X | G ]] ≤ Var [ X ] . To maximize E [ Var [ X | G ]], G should contain as little information as possible, but then computing X e may become too hard. The choice of G is a matter of compromise.

7 Draft Conditional MC with auxiliary variables [Elperin, Gertsbach, Lomonosov 1974, 1991, 1992, etc.] Special case: the X i ’s are independent with P [ X i = 0] = q i . Conceptually, suppose each link i is initially failed and gets repaired at time Y i ∼ Expon( µ i ) where µ i = − ln( q i ). Then P [ Y i > 1] = P [ X i = 0] = q i . Let Y = ( Y 1 , . . . , Y m ) and π the permutation s.t. Y π (1) < · · · < Y π ( m ) . Conditional on π , we can forget the Y i ’s, add the (non-redundant) links one by one until the graph is operational, say at step C . Data structure: forest of spanning trees. Adding a link may merge two trees.

7 Draft Conditional MC with auxiliary variables [Elperin, Gertsbach, Lomonosov 1974, 1991, 1992, etc.] Special case: the X i ’s are independent with P [ X i = 0] = q i . Conceptually, suppose each link i is initially failed and gets repaired at time Y i ∼ Expon( µ i ) where µ i = − ln( q i ). Then P [ Y i > 1] = P [ X i = 0] = q i . Let Y = ( Y 1 , . . . , Y m ) and π the permutation s.t. Y π (1) < · · · < Y π ( m ) . Conditional on π , we can forget the Y i ’s, add the (non-redundant) links one by one until the graph is operational, say at step C . Data structure: forest of spanning trees. Adding a link may merge two trees. Time to repair, conditional on π ? At step j , the time A j to next repair is exponential with rate Λ j , the sum of repair rates of all links not yet repaired. Permutation Monte Carlo (PMC) estimator of u : conditional probability that the total time for these repairs (hypoexponential sum) is larger than 1: P [ A 1 + · · · + A c > 1 | π, C = c ] . Theorem [Gertsback and Shpungin 2010]. Gives bounded RE when the q i → 0.

7 Draft Conditional MC with auxiliary variables [Elperin, Gertsbach, Lomonosov 1974, 1991, 1992, etc.] Special case: the X i ’s are independent with P [ X i = 0] = q i . Conceptually, suppose each link i is initially failed and gets repaired at time Y i ∼ Expon( µ i ) where µ i = − ln( q i ). Then P [ Y i > 1] = P [ X i = 0] = q i . Let Y = ( Y 1 , . . . , Y m ) and π the permutation s.t. Y π (1) < · · · < Y π ( m ) . Conditional on π , we can forget the Y i ’s, add the (non-redundant) links one by one until the graph is operational, say at step C . Data structure: forest of spanning trees. Adding a link may merge two trees. Time to repair, conditional on π ? At step j , the time A j to next repair is exponential with rate Λ j , the sum of repair rates of all links not yet repaired. Permutation Monte Carlo (PMC) estimator of u : conditional probability that the total time for these repairs (hypoexponential sum) is larger than 1: P [ A 1 + · · · + A c > 1 | π, C = c ] . Theorem [Gertsback and Shpungin 2010]. Gives bounded RE when the q i → 0. Improvement: turnip ; at each step, discard redundant unrepaired links.

8 Draft Hypoexponential cdf : We have c c � � Λ k e − Λ j P [ A 1 + · · · + A c > 1 | π, C = c ] = . Λ k − Λ j j =1 k =1 , k � = j This formula becomes unstable when c is large and/or the Λ j are small. The product terms are very large and have alternate signs ( − 1) j − 1 . Higham (2009) proposes a stable method for matrix exponential. More reliable, but significantly slower. For the case where the above prob is close to 1, we also have � c � c Λ k (1 − e − Λ j ) P [ A 1 + · · · + A c ≤ 1 | π, C = c ] = . Λ k − Λ j j =1 k =1 , k � = j

9 Draft A dodecahedron network B 28 27 20 18 11 25 19 30 29 10 9 4 3 1 8 5 17 12 26 21 A 16 2 13 7 6 15 14 24 22 23

10 Draft Turnip method for dodecahedron graph: n = 10 6 , V 0 = { 1 , 20 } 10 − 1 10 − 2 10 − 3 10 − 4 10 − 5 10 − 6 q i = ǫ ¯ W 2.881e-3 2.065e-6 2.006e-9 1.992e-12 1.999e-15 2.005e-18 n RE[ ¯ W n ] 0.00302 0.00421 0.00433 0.00436 0.00435 0.00434 T (sec) 15.6 15.5 15.5 15.5 15.5 15.5 We see that u ≈ 2 × 10 − 3 ǫ and RE is bounded (proved).

11 Draft Three dodecahedron graphs in parallel. 60 nodes and 90 links. dodec. 2 A dodec. 1 B dodec. 3

12 Draft Turnip for three dodecahedrons in parallel: n = 10 8 , V 0 = { 1 , 20 } 10 − 1 10 − 2 10 − 3 10 − 4 10 − 5 10 − 6 q i = ǫ ¯ W 2.39e-8 8.80e-18 8.20e-27 8.34e-36 8.07e-45 7.92e-54 n RE[ ¯ W n ] 0.0074 0.0194 0.0211 0.0210 0.0212 0.0215 T (sec) 6236 6227 6229 6546 6408 6289 We have u ≈ 2 × 10 − 9 ǫ and RE is bounded (proved). Total CPU time is about 2 hours, regardless of ǫ . However, for very large graphs (thousands of links), the turnip method fails, because the important permutations π , for which the conditional probability contributes significantly, are rare, and hitting them becomes a rare event. Bounded RE does not hold for an asymptotic regime where the size of the graph increases. Splitting will come to the rescue (later on).

13 Draft Dependent Links: A Marshall-Olkin Copula Model Goal : Define a model where the X i ’s may have positive dependence.
