DISCOVER RIM WASH SYSTEM
WHAT IS DISCOVER? It is a new and innovative “NO TOUCH” rim wash system, capable of cleaning rims by distributing the product and washing at high pressure, without using a brush.
FUNCTIONS DISCOVER can perform the following functions: • Rim product dispensing rotating in two directions • High pressure rim wash rotating in two directions • High pressure wheel arch wash rotating in two directions • Low rotating side high pressure
CHARACTERISTICS • No mechanical contact with rims • High pressure rim product dispensing with separate channels • Low rotating side high pressure • Lower product consumption • Optimum results
PRODUCT DISPENSING The pre-diluted product is drawn from the container with a pneumatic pump and then injected into the circuit; two nozzles located on the Discover dispense the product onto the rims. Product 1 nozzle Product 2 nozzle
ANTI-FREEZE PROTECTION The entire rim wash circuit is protected against freezing with a heating cable, from the disks’ hubs to the pump.
Discover Operation Machine ’s forward cycle In one pass 1st A - Rotation to dispense product A A 2nd B - Rotation to dispense product B PROGRAMMABLE PAUSE TO ALLOW PRODUCT TO REACT Front wheel 3rd A - HIGH PRESSURE rotation A 4th B - HIGH PRESSURE rotation B Time of each individual rotation can be custom set from the operator terminal. If the time is set at 0 seconds, the rotation pass is not performed. 1st A - Rotation to dispense product A 2nd B - Rotation to dispense product B PROGRAMMABLE PAUSE TO ALLOW PRODUCT TO REACT Rear wheel 3rd A - HIGH PRESSURE rotation A 4th B - HIGH PRESSURE rotation B Time of each individual rotation can be custom set from the operator terminal. If the time is set at 0 seconds, the rotation pass is not performed.
In two separate passes Machine ’s forward cycle 1st A - Rotation to dispense product A Front wheel 2nd B - Rotation to dispense product B 3rd A - Rotation to dispense product A Rear wheel 4th B - Rotation to dispense product B Machine ’s return cycle 1st A - HIGH PRESSURE rotation A Rear wheel 2nd B - HIGH PRESSURE rotation B 3rd A - HIGH PRESSURE rotation A Front wheel 4th B - HIGH PRESSURE rotation B Time of each individual rotation can be custom set from the operator terminal. If the time is set at 0 seconds, the rotation pass is not performed.
RESULTS Besides the cleaning, the big advantage of the DISCOVER system is that it performs well regardless of the rim size. Before After
DISCOVER is a system unparalleled throughout the world. It is protected by: Italian patent filed on 31/10/2012 No. PCT / EP2012 / 071626 S
