Diamond Coating for machining Diamond Coating for machining of Graphites and Composites of Graphites and Composites

A2C Advanced Carbide Coating - 53, rue Jacques Prévert 33700 Mérignac Tél. : (33) 5 57 92 17 55 • Fax : (33) 5 56 34 47 15 Our mission: A2C is a unit dedicated to diamond coating and tools and inserts manufacturing in PCD and CBN for machining Graphite, Composite, Wood and abrasive materials. Our means: 3 coating centers for tools and inserts: • Balzers : for microcrystalline coating. Capacity : ø 1 to ø 20 mm • SP3 : for nanocrystalline coating. Capacity : ø 0.2 to 20 mm • Cemecon : for DLC and TiB2 coating A park machines for the tools and inserts manufacture of polycrystalline PCD and CBN coating. A team: Technicians with an experience of over 20 years in the application of new PCD, CBN cutting materials and diamond coating. A2C answers to the needs of industry: - Coating of carbide tools and inserts - Manufacture of tools and insets in PCD, CBN and carbide - Grinding of small and large tool series in PCD, CBN, carbide and ceramics - Development of new tools

http://www.a2c-diamond-coating.com mail : jacques.gaillard@wanadoo.fr Diamond Coatings CVD and PVD 10 000 HARDNESS HV DIAMANT C6H NANOCRISTALLIN (CVD) Co m posite 8 000 A lum i n i um DIAMANT B10H P la stic MICROCRISTALLIN (CVD) G ra phite Woo d x 20 Co m posites a nd m o r e 4 000 DLC x 10 (PVD) A lum i n i um s 2 750 Woo d P la stic DIAMECO (PVD) x 3 Woo d x 2 1 750 Ca rb i d e ( un co a te d ) x 1 PERFORMANCE Use of A2C coatings Diamond Coating DLC Material PCD Diameco Nanocristalline C6H Microcristalline B10H Aluminium X X X TItane X X CFPR X X X CFPR + Aluminium X X CFPR + Titane X X Honeycomb X X Wood X X X X Graphite X X X MMC X X Renforced Graphite X X

The tools with Micro or Nanocrystalline Diamond coating allow machining of: • Graphite • Reinforced composites • CFRP GRP AFRP (Kevlar) • Composites + Aluminium • Titane • Honeycomb • Wood • Plastic materials • Abrasive materials Tools used for: • Aeronautics Industry • Automotive Industry • Machining of wood • Precision engineering A2C Advanced Carbide Coating - 53, rue Jacques Prévert F 33700 Mérignac Tél. : (33) 5 57 92 17 55 • Fax : (33) 5 56 34 47 15 - http://www.a2c-diamond-coating.com mail : jacques.gaillard@wanadoo.fr SARL capital 240 000 Euros - SIRET 423 350 248 00013 NAF 286 D - N° TVA FR 74 423 350 248
