Development Status of Transuranic-Bearing Metal Fuels Kemal O. Pasamehmetoglu AFCI Transmutation Fuels Campaign Director The 10th Actinide & Fission Product Partitioning and Transmutation Information Exchange Meeting October 8, 2008


  1. Development Status of Transuranic-Bearing Metal Fuels Kemal O. Pasamehmetoglu AFCI Transmutation Fuels Campaign Director The 10th Actinide & Fission Product Partitioning and Transmutation Information Exchange Meeting October 8, 2008 (Mito, Japan) 1

  2. Both fabrication and performance of transmutation fuels offer challenges compared to traditional fuels  Focus to date on metal and oxide fast reactor fuels – Group TRU fuels for homogeneous transmutation – Driver fuels (U,Pu, Np?) and MA targets (Am or Am-Cm)  Emphasis on fabrication and performance simultaneously  Transmutation fuels are quite different than conventional fuels  Multiple elements in the fuel Targeted U, Pu, Np, Am, Cm  Varying thermodynamic properties Testing e.g. High vapor pressure of Am  Impurities from separation process e.g. High lanthanide carryover Modeling &  High burnup requirements Simulation  High helium production during irradiation  Remote fabrication & quality control  Fuel must be qualified for a variable range of composition • Age and burnup of LWR SNF • Introduction of first tier recycle in LWR • Changes through multiple passes in FR • Variable conversion ratio for FR October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 2

  3. U.S. has considerable experience with the use of metal fuel for sodium-cooled fast reactors  The bulk of the experience comes from EBR-II and FFTF tests.  Metal fuel was the preferred option for the IFR program in the U.S. when the program was terminated.  U-Pu-Zr alloys were irradiated up to > 19% burnup. – 2- σ temperature irradiations up to 12% without breach  In the beginning of the ATW program, U.S. considered metal fuel as a strong option for transmutation applications. Mark- Campaig n Mark-I / IA Mark-III / II I A Mark-IV Mark-V / VA * II/IIC/IICS U-5Fs and Fuel alloy (wt% ) U-5Fs U-10Zr U-10Zr U-20Pu-10Z r U-10Zr 235 U Enrichment (% ) 5 2 67-78 66.9 69.6 Variabl e Slug Diameter (mm ) 3.66 3.30 4.39 4.27 4.27-4.39 Smeared density (% ) 8 5 7 5 7 5 7 5 7 5 Burn up limit (at% ) 2.6 8.9 1 0 N/A TBD Plenum to fuel 0.18 0.68-1.01 1.45 1.45 1.45 volume ratio SS304L and CW 316 and HT 9 and Cladding material SS 304 L HT 9 SS 316 CW D9 CW 316 *Conversion to the Mark-V / -VA fuel types was not started before EBR-II was terminally shut down in 1994. October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 3

  4. X501 Experiments in EBR-II (1990’s) Initial research on MA transmutation (IFR) – Discharged short of target burnup (10%) – Partial PIE completed Target composition: U-20ZPu-10Zr-2.1Am-1.3Np As fabricated composition: U-20.2Pu-9.1Zr-1.2Am-1.3Np High Am loss during fabrication Performed well to 7.9% HM burnup – Typical U-Pu-Zr fuel behavior – High helium release; typical FG release – No FCCI observed – No Am redistribution to clad inner wall October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 4

  5. AFCI Fuels Testing in ATR East Flux Trap 1.0E+14 1.0E+13 1.0E+12 1.0E+11 1.0E+10 1 6 7 2 Without CD-shroud 1.0E+9 With CD-shroud 5 3 4 1.0E+8 1.0E-10 1.0E-6 1.0E-2 1.0E+2 East Flux 1.0E-8 1.0E-4 1.0E+0 Trap Energy in MeV  4 Capsule Positions in EFT – Cd baskets in 1,2,3,4 – 6 rodlets per capsule – LHGR to 500 W/cm – PICT to 650°C – Capsule pressure to 975 psi October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 5

  6. AFC Fuel Test Series in the ATR AFC-1 AFC-2 AFC-3 AFC-4 Scoping – Scoping – Focused compositions Focused compositions Many compositions Focused compositions Test Strategy Nominal & limiting Nominal conditions Nominal conditions Nominal conditions conditions Capsule Drop-in Drop-in Instrumented lead Drop-in Type Metals Metals Metals Metals Fuel Types Nitrides Oxides Oxides Oxides Key Baseline Baseline Recycle feed Temperature control Features + MA + MA + RE Remote fabrication FY 2003 – FY 2008 – FY 2010 – FY 2011 – Time Frame FY 2008 FY 2013 + FY 2013 FY 2014 Test series in progress. Future test series. October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 6

  7. AFC-1B and AFC-1F Metallic Transmutation Fuels (Evaluation Completed) AFC-1B AFC-1F Pu-12Am-40Zr U-29Pu-4Am-2Np-30Zr Pu-10Am-10Np-40Zr U-34Pu-4Am-2Np-20Zr Pu-40Zr U-25Pu-3Am-2Np-40Zr Pu-12Am-40Zr U-29Pu-4Am-2Np-30Zr Pu-60Zr U-28Pu-7Am-30Zr U-25Pu-3Am-2Np-40Zr • AFC-1D: same compositions as AFC-1B irradiated to higher burnups (30% or greater) • Recently discharged October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 7

  8. AFC-1G and AFC-1H Experiments’ Status Inserted April 2005   AFC-1G (burnup ~30%) discharged waiting for PIE  AFC-1H (burnup 40%) to be discharged soon Rodlet AFC-1G Rodlet AFC-1H 1 Pu-10Np-40Zr 1 U-29Pu-4Am-2Np-30Zr 2 Dummy 2 U-34Pu-4Am-2Np-20Zr 3 (U 0.50 , Pu 0.25 , Am 0.15 , Np 0.10 )N 3 U-25Pu-3Am-2Np-40Zr 4 Pu-10Np-40Zr 4 U-29Pu-4Am-2Np-30Zr 5 Dummy 5 U-28Pu-7Am-30Zr 6 Dummy 6 U-25Pu-3Am-2Np-40Zr 1 1 6 7 2 6 7 2 3 5 3 5 4 4 East Flux Trap East Flux Trap Irradiation Housing Irradiation Housing October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 8

  9. AFC-2A and AFC-2B Experiments’ Status  Inserted October 2007  AFC-2A: Burnup 10 at.% (Recently discharged)  AFC-2B: Burnup objective is 25 at.% (Soon to be discharged) Rodlet AFC-2A (position 2) & 2B (position 3) 1 U-20Pu-3Am-2Np-15Zr 1 6 7 2 2 U-20Pu-3Am-2Np-1.0RE-15Zr 5 3 4 3 U-20Pu-3Am-2Np-1.5RE-15Zr 4 U-30Pu-5Am-3Np-1.5RE-20Zr East Flux Trap 5 U-30Pu-5Am-3Np-1.0RE-20Zr Irradiation Housing 6 U-30Pu-5Am-3Np-20Zr RE=6% La, 16% Pr, 25% Ce, 53% Nd October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 9

  10. FUTURIX-FTA Status—Metallic Fuels  Four FUTURIX-FTA nitride and metal fuel samples and sodium-bonded rodlets are fabricated and shipped to France for irradiation in Phenix reactor. – Nitride pellets are fabricated at LANL, sodium-bounding and pin fabrication completed at INL. – Metal fuel slugs and the sodium bounded pins are fabricated at INL.  Irradiation of metal fuels along with oxides fabricated in Europe started in May 2007  The irradiation tests will be completed in May-June 2009 and irradiated fuel samples will be shipped to the U.S. for PIE.  Pu-12Am-40Zr and U-29Pu-4Am-2Np-30Zr October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 10

  11. Advanced Casting Studies  Advanced casting system technology must – Retain volatile elements (Am) – Applicable for hot cell use – Increase melt usage – Reduce materials losses and waste production Developmental approach will be taken  – Bench-scale system (BCS) – Engineering-scale system (ECS) – Advanced Casting System (ACS) October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 11

  12. Transmutation Metal Fuels - Summary & Conclusions  Considerable characterization activities continue – Measurement of thermodynamic properties – Phase Diagrams/Phase CLAD Distribution/Microstructure – Diffusion-couple measurements  Considerable effort in looking at cladding development – High-fluence data on HT-9 (200 dpa) Fuel – Looking at advanced options (ODS) – Considering lined/coated cladding options Fe  Technical feasibility of MA-bearing metal fuels is demonstrated (>10% burnup)  Advanced modeling and simulation is being used to cover the range of compositions that are of interest  Engineering feasibility of large scale fabrication needs additional work – Casting simulations are being used to optimize the fabrication processes Zr October 8, 2008 International Exchange Meeting on P&T (Mito,Japan) 12
