2008 SW Wisconsin Stream Survey: Crow, Culvers, Harker, Martinville, Newell

Locations Grant County Grant County Iowa County

Stream Habitat

Vegetation Coverage 25 Coverage Percentage 20 15 10 5 0 Crow Culvers Harker Martinville Newell Streams

Averaged Stream Width 4.5 4 3.5 3 Width (m) 2.5 2 1.5 1 0.5 0 Crow Culvers Harker Martinville Newell Streams

Average Stream Depth 40 35 30 Depth (cm) 25 20 15 10 5 0 Crow Culvers Harker Martinville Newell Stream

Average Stream Embeddendness 8 Embeddedness (cm) 7 6 5 4 3 2 1 0 Crow Culvers Harker Martinville Newell Stream

Stream Erosion 0.8 0.7 0.6 0.5 Meters Right 0.4 Left 0.3 0.2 0.1 0 Crow Culvers Harker Martinville Newell Streams

Averaged Stream Substrate 60 fine 50 sand Percentage 40 gravel cobble 30 Lg Rock 20 Boulder 10 Bedrock 0 Crow Culvers Harker Martinville Newell Streams

Average Stream Flow 4 3.5 3 Flow m/s 2.5 2 1.5 1 0.5 0 Crow Culvers Harker Martinville Newell Streams

Overview  Riparian zones: Generally mostly grasses with few wooded low coverage areas. Ex. Martinville  Stream Width: Average between 2m and 4m  Stream Depth: Average Between 20 and 35cm  Embeddedness: Varied between 1.5 to 7cm  Erosion: Banks fairly equal, < .35m. Ex. Martinville  Substrate: Mid-sized particles. Ex. Newell  Flow: Averages < .5m/s. Ex. Crow

Stream Chemistry

Averaged Stream Temperature 25 Temperature (*C) 20 15 10 5 0 Crow Culvers Harker Martinville Newell Streams

Averaged Stream DO2 12 10 8 DO2 m/l 6 4 2 0 Crow Culvers Harker Martinville Newell Streams

Overview  Temperature: Between 15 and 20*C  DO2: Between 8 to 10m/l  pH: Variable, between 3 and 10. Perhaps equipment malfunction?

Invertebrates

Total Collected Invertebrates 1800 1600 1400 Total collected 1200 1000 800 600 400 200 0 Crow Culvers Harker Martinville Newell Streams **Note: Four Samples remain unknown due to poor condition of labels.**

Common Species Hirudo Medicinalis Diptera Chironomidae Amphipod Diptera Simuliidae Coleoptera Trichoptera Hydropsychidae

Common Species Trichoptera Psychomyiidae Gastropod Ephemeroptera Baetidae Water Mite

Overview  Invert Totals varied  Species found in each stream: Crow 8, Culvers 17, Harker 17, Martinville 11, Newell 10

Fish

Target Species 60 50 Crow 40 Culvers Number 30 Harker Martinville 20 Newell 10 0 Brown Trout Brook Trout Ozark Minnow Species

Trout Lengths Crow Harker 35 35 30 30 25 Lengths (cm) 25 Lengths (cm) 20 20 1 5 1 5 1 0 1 0 5 5 0 0 Brown Trout Brown Trout Brook Trout Martinville Culvers 35 35 30 30 25 25 Lengths (cm) Lengths (cm) 20 20 15 15 10 10 5 5 0 0 Brown Trout Brown Trout

Common Species Number Collected 35 Crow 30 25 Culvers 20 Harker 15 10 Martinville 5 0 Newell l n r b i e b e r a u i e c u l k t p n h n a h c u i C a d u C h c F S S S k e d e s e n d e e o t l o e i i r n h a m C l g t W T t m n o - o M d o e L C R Species

Overview  Brow Trout found in Crow, Culvers, Harker, Martinville  Martinville high abundance of fingerlings  Largest trout found in Crow  Brooke Trout found in Harker  Ozark Minnow found only in Newell  Each stream displayed a variety of minnows, chubs, suckers, daces, scuplins, etc.

Survey Summary  All five streams vary from one another.  Found trout of various sizes in Crow, Culvers, Harker, and Martinville.  Habitat, chemistry, invertebrate, and fish studies suggests that Crow, Culvers, Harker, and Martinville are suitable for trout habitat.  No trout found in Newell; Habitat, chemistry, and invertebrate studies are comparable to rest of streams with exception of slower stream flow and large substrate particles. Most transect variation of substrate.

Special Thanks  Kris Wright  Jennie Franks - TU Intern Assistant  Lauren Kolodzieji - Ozark Minnow Project  Dana Clark - Crow Branch Project  Trout Unlimited

Questions?
