Corporate Profile Who We Are Simcoe Geoscience Limited is a Canadian company providing ground geophysical surveys and consulting services to Mining and Engineering industries. Since its inception, Simcoe is developing clientele based on our reputation and our goal of providing “Affordable Intelligent Solutions”. Our mission, “to work with our clients and their teams in designing and implementing projects focused on achieving their goals in a safe and environmentally friendly manner”. Experience Management has a combined “50 plus” years of industry related experience in geophysical surveys and consulting services. Our experience spans over geophysical data acquisition, processing and interpretation. Simcoe’s team and consulting professionals are able to offer solutions for all geoscience challenges.

What We Offer  Ground Geophysical Surveys  Consulting Services

Our Presence  Worldwide Operations  Currently Available in  North America  South America  Middle East  Australia

Major Clients  Government Agencies  Govt. of Canada  Conservation & Parks Canada  Ministry of Transportation  Saudi Arabian Mining Company  King Abdullah University of Science and Technology (KAUST)  Public & Private Companies  Ascot Resources  Brixton Metals  Tudor Gold  Jaxon Mining  Sojourn Exploration  SNC Lavalin  Seabridge Gold  Metrolinx Toronto  Aurelian Oil & Gas PLC And many more

Technologies  Alpha IP (Wireless)  Omega MT (Broadband)  Seismic (Wireless)  Gravity & Magnetics  Electromagnetic  Borehole Logging  Ground Penetrating Radar

2D/3D IP A Wireless Approach to Mine Discovery

Alpha IP Introducing “state of the art” 2D/3D IP Wireless Distributed technology that is revolutionizing the world of Deep Mineral Exploration.  High Resolution Data at an Affordable Cost  Geometry Free Arrays  Full Waveform Recording  High Resolution Data  Saving Acquisition Time  Easily Expandable System

Alpha IP  No more wires, bulky old systems  No more hefty mob/demob costs  No more large crew, unnecessary helicopter costs  No more line cuttings, minimum environmental footprint  No more topographic or terrain restrictions  No more profile length limitations  No more “a” & “n” limitations

Alpha IP  Depth of Investigation up to 1000m  Double data density with Reverse & Forward configuration  Off end current injections for better coverage of EOP anomalies  Optimized Tx-Rx pattern to reduce data redundancy

2D Field Setup

Alpha IP Field Setup

Alpha 2DIP Data

Alpha 2DIP Data

Products

Products 609 zone 602 zone Northern Lights zone

3D Field Setup Survey Configuration Current Injections In line, Off line, diagonal Configuration Pole-Dipole, a=100m, Data Component DC Resistivity, IP Chargeability, Waveform Timeseries Recording Number of Receivers 50 (100 dipoles for one setup) Total Receiver Dipoles 400 Total Current Injections ~1300 Total Data Points ~500,000 Area Coverage 3.2 x 3.2 – Two Setups and additional 2D Profiles Depth of Investigation 500+ m Approximate Survey Days 41 Receiver Characteristics Pulse duration 1s, 2s, 4s, or 8s Channels 2 channels Input Impedance 100 MOhms Input Voltage 15V, automatic gain, input protection 1000V Resolution / Accuracy 1 µV / 0.2% GPS GPS input for coordinates and synchronization full waveform 10ms (100Hz) sampling Readings rate, resistivity, self-potential Noise Rejection power line rejection, SP linear drift correction. up to 70 days 2 channels full waveform, stored on Storage solid state memory Current Monitor Characteristics Input current +/- 25000mA (optional 50A) Resolution / Accuracy 0.1mA / 0.1% GPS GPS input for coordinates and synchronization Readings current value Channel 1 channel 90 days full waveform, stored on solid state Storage memory Transmitter Characteristics Voltage Input 125V line to neutral, 400Hz, 3phase Powered By MG 12A Motor Generator Output Voltage and 100-3200V in 10 Steps, 0.05 – 20 Amps Current

3DIP Data

Products

Slices & Surfaces 3D Model Iso-surfaces 3D Model Depth Slices

Pre & Post Project Consulting  Project Management  Project Assessment  Project Design  Technical Contract Review and QA / QC Services  Ensure Data Quality  Mitigate and Assess Budget Problems and Assess Budget Problems  Data Compilation and Reprocessing Services  Products  Standard Maps  Derivative Maps  2D & 3D Inversion Modeling  Interpretation Utilizing Multiple Data Sets

Ultra Wide Band Magnetotelluric Technology  8 Channels  Lightweight and expandable  full AMT and MT frequencies from  24 bit Data 10,000 Hz to 50,000 seconds and also  Acquire AMT/MT with one single offers a much better resolution in the set of coils dead bands

Wireless Seismic System  Complete Wireless  4.5, 10, 100 Hz Geophone  12 up to 256 channels  Active and passive recording  2D & 3D acquisition  Radio controled trigger  Data remotely transmitted to tablet  Real time QC  Sampling from 250Hz, 500Hz, 1000Hz, 2000Hz, 4000Hz, 8000Hz, 16000Hz

Wireless Seismic System
