Computer Systems Lecture 15 Pipelining and Hazards CS 230 - Spring - PowerPoint PPT Presentation

CS 230 Introduction to Computers and Computer Systems Lecture 15 Pipelining and Hazards CS 230 - Spring 2020 3-1 Pipelining CS 230 - Spring 2020 3-2 ISA Requirements for Pipelining Constant length instructions (fetch, decode)


  1. CS 230 – Introduction to Computers and Computer Systems Lecture 15 – Pipelining and Hazards CS 230 - Spring 2020 3-1

  2. Pipelining CS 230 - Spring 2020 3-2

  3. ISA Requirements for Pipelining  Constant length instructions (fetch, decode)  Few instruction formats, source fields same  register operands can be fetched while decoding  Memory operands only in load and store  one memory access per instruction  compute address during execute  no separate stage needed  MIPS has all of this CS 230 - Spring 2020 3-3

  4. Pipeline Diagram  Shows what the MIPS processor is doing for each clock cycle in the program  Used for measuring CPI and detecting stalls  Example: time program execution addi $3, $0, 0x88 IF ID EX MEM WB sub $4, $7, $17 IF ID EX MEM WB add $5, $3, $9 IF ID EX MEM WB cycle 1 cycle 2 cycle 3 cycle 4 cycle 5 cycle 6 cycle 7 CS 230 - Spring 2020 3-4

  5. Pipeline Hazards  Instructions are not completely independent  A pipeline hazard is a condition that blocks pipelined flow  data hazard : dependency between instructions  need to wait for data read/write  control hazard : dependency between instructions  control depends on previous instruction CS 230 - Spring 2020 3-5

  6. Data Hazard  Consider the following MIPS code addi $2, $0, 10 add $3, $2, $2  The add depends on the result of the addi  We say there is a data hazard between these instructions CS 230 - Spring 2020 3-6

  7. Data Hazard addi $2, $0, 10 IF ID EX MEM WB add $3, $0, $2 IF ID EX MEM WB A B  The ID stage gets the values from registers  That means at time A the add instruction got the old value in $2  At time B the WB stage of the addi has put 10 into $2  But it’s too late! The add used the old value of $2 CS 230 - Spring 2020 3-7

  8. Forwarding addi $2, $0, 10 IF ID EX MEM WB add $3, $0, $2 IF ID EX MEM WB  Have any stage where the result is ready can forward the result to the stage that needs it  Here the result is ready in the EX of addi and gets forwarded to the EX of add  We draw an arrow in our pipeline diagram to indicate forwarding  Can only forward one cycle forwards in time  Not 2 or more cycles, and not back in time CS 230 - Spring 2020 3-8

  9. Stalling lw $4, 0($5) IF ID EX MEM WB add $6, $4, $3 IF ID EX MEM WB  Forwarding it not always enough  Sometimes the data is not ready in time  An instruction may cause a stall to wait for data to be ready at a future cycle, then forward  Stalls are shown as bubbles in pipeline diagrams  indicate the loss of an instruction’s worth of time CS 230 - Spring 2020 3-9

  10. Forwarding Special Case addi $2, $0, 10 IF ID EX MEM WB sub $4, $5, $6 IF ID EX MEM WB sub $7, $8, $9 IF ID EX MEM WB add $3, $0, $2 IF ID EX MEM WB  Never forward from WB  WB happens before ID within same cycle  ID will get values from WB in same cycle without needing to forward  Corollary: two instructions with a data hazard can have at most one instruction between them  Two or more and it is not a data hazard  Stall bubbles count as a potential instruction CS 230 - Spring 2020 3-10

  11. Forwarding “Connections” Diagram CS 230 - Spring 2020 3-11

  12. Control Hazard  Conditional branches determine control flow  fetching next instruction depends on outcome  how does the IF stage know which instruction to load?  In MIPS pipeline  add hardware to ID stage to check branch early  know if taken or not taken by end of ID stage  forces one stall after every branch instruction unless we can find a way to avoid this?  CS 230 - Spring 2020 3-12

  13. Control Hazard  Example  consider the below code and assume $2 = 0 beq $2, $0, x sub $6, $7, $8 x: add $3, $4, $5  don’t know the branch is taken until the ID of the beq beq $2, $0, x IF ID EX MEM WB x: add $3, $4, $5 IF ID EX MEM WB CS 230 - Spring 2020 3-13

  14. Branch Prediction  We can sometimes avoid stalls from control hazards with branch prediction  processor guesses if branch is taken  guess wrong and wrong guess turns into a stall  guess correct and no stall at all  how to guess?  lots of methods  “backwards taken, forwards not taken” convert branch label to number of instruction to skip (branch offset)  if branch offset negative: guess branch taken  if branch offset positive: guess branch not taken   all branch instructions are control hazards CS 230 - Spring 2020 3-14

  15. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 addi $2, $0, 2 lw $3, 0($1) add $4, $2, $3 x: addi $2, $2, -1 bne $2, $0, x jr $31 CS 230 - Spring 2020 3-15

  16. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 addi $2, $0, 2 lw $3, 0($1) data hazard $1 add $4, $2, $3 data hazard $2 data hazard $3 x: addi $2, $2, -1 bne $2, $0, x control hazard data hazard $2 jr $31 CS 230 - Spring 2020 3-16

  17. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB CS 230 - Spring 2020 3-17

  18. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB CS 230 - Spring 2020 3-18

  19. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB CS 230 - Spring 2020 3-19

  20. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB CS 230 - Spring 2020 3-20

  21. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB CS 230 - Spring 2020 3-21

  22. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB CS 230 - Spring 2020 3-22

  23. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB CS 230 - Spring 2020 3-23

  24. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB jr $31 IF ID EX MEM WB CS 230 - Spring 2020 3-24

  25. Example Identify the hazards, and draw a pipeline diagram for the below MIPS code. How many cycles does it take to execute? addi $1, $0, 0xA0 IF ID EX MEM WB addi $2, $0, 2 IF ID EX MEM WB lw $3, 0($1) IF ID EX MEM WB add $4, $2, $3 IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB x: addi $2, $2, -1 IF ID EX MEM WB bne $2, $0, x IF ID EX MEM WB jr $31 IF ID EX MEM WB 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 17 cycles total CS 230 - Spring 2020 3-25
