Community Satellite Processing Package (CSPP) Polar-Orbiting Satellite Software and Products Liam Gumley, Allen Huang, Kathy Strabala, Scott Mindock, Ray Garcia, Graeme Martin, Geoff Cureton, Elisabeth Weisz, Nadia Smith, Nick Bearson, James

SLIDE 1

Liam Gumley, Allen Huang, Kathy Strabala, Scott Mindock, Ray Garcia, Graeme Martin, Geoff Cureton, Elisabeth Weisz, Nadia Smith, Nick Bearson, James Davies, Jessica Braun. CIMSS/SSEC, University of Wisconsin-Madison. NOAA Satellite Conference 2015/04/29

Community Satellite Processing Package (CSPP) Polar-Orbiting Satellite Software and Products

SLIDE 2

What is CSPP?

CSPP (Community Satellite Processing Package) is a collection of software systems for processing data from meteorological satellites. The primary goal of CSPP is to support users who

Receive satellite data via direct broadcast;
Create Level 1B and higher level products and

images in real time. Funding is supplied by JPSS and NOAA.

SLIDE 3

CSPP Software Philosophy

The CSPP software Creates useful products for the DB community, Includes up-to-date algorithms, Is pre-compiled for 64-bit Intel Linux (CentOS), Is easy to install and operate, Includes test data for verification, Runs efficiently on modest hardware, Has prompt user support.

SLIDE 4

CSPP by the numbers

Satellites supported: 7 Software packages: 10 Sensors supported: 25 Releases and updates: 29 Registered users: 913 Individual downloads: > 5000

SLIDE 5

CSPP Software (Apr 2015)

CSPP Software Product Description

1. SDR

VIIRS, CrIS, and ATMS geolocated and calibrated earth observations.

2. VIIRS EDR

VIIRS imager cloud mask, active fires, surface reflectance, vegetation indices, sea surface temperature, land surface temperature, and aerosol optical depth.

3. HSRTV

Hyperspectral infrared sounder retrievals of temperature and moisture profiles, cloud properties, total ozone, and surface properties.

4. Polar2grid

Reprojected imagery (single and multi-band) in GeoTIFF and AWIPS formats.

5. Hydra

Interactive visualization and interrogation of multispectral imagery and hyper spectral soundings.

6. MIRS

Microwave sounder retrievals of temperature and moisture profiles; surface properties; snow and ice cover; rain rate; and cloud/rain water paths.

7. CLAVR-x

Multispectral imager retrievals of cloud properties; aerosol optical depth; surface properties; ocean properties.

8. NUCAPS

Combined hyperspectral infrared sounder and microwave sounder retrievals of temperature and moisture profiles, cloud cleared radiances, and trace gases.

9. IAPP

Combined infrared sounder and microwave sounder retrievals of temperature and moisture profiles, water vapor, total ozone, and cloud properties.

10. ACSPO

Multispectral imager retrievals of sea surface temperature.

SLIDE 6

Satellite Multispectral Imager Infrared Sounder Microwave Sounder Suomi NPP VIIRS SDRs (Level 1B), Images, Visualization, Clouds, Aerosols, Land, Ocean CrIS SDRs (Level 1B) Atmospheric Profiles, Clouds, Visualization ATMS SDRs (Level 1B), Atmospheric Profiles, Precipitation, Visualization Metop-A/B AVHRR Clouds, Aerosols, Land Surface, SST, Visualization IASI, HIRS Atmospheric Profiles, Clouds, Visualization AMSU, MHS Atmospheric Profiles, Precipitation NOAA-18/19 AVHRR Clouds, Aerosols, Land Surface, SST, Visualization HIRS Atmospheric Profiles AMSU, MHS Atmospheric Profiles, Precipitation Terra MODIS Images, Visualization N/A N/A Aqua MODIS Images, Visualization AIRS Atmospheric Profiles, Clouds, Visualization AMSU Atmospheric Profiles, Precipitation, Visualization

CSPP Satellite/Sensor/Product Matrix

SLIDE 7

CSPP Registered User Locations

February, 2015

SLIDE 8

MIRS Examples

SNPP ATMS Surface Skin Temperature with Rain Rate contours and isosurface of Rain Mass Profile

Metop-B 2015/03/30 02:01 UTC SNPP 2015/03/18 11:03 UTC

Metop-B AMSU/MHS 840 hPa temperature and water vapor

SLIDE 9

CLAVR-x Examples

SNPP 2013/03/10 23:00 UTC

VIIRS False Color SST Ancillary Data Cloud Masked SST Cloud Top Temperature Cloud Water Path Rain Rate

SLIDE 10

NUCAPS Examples

SNPP 2015/04/03 19:07 UTC

Temperature Water Vapor Mixing Ratio

SLIDE 11

ACSPO Examples

2015/04/02

VIIRS SST 17:44 UTC MODIS SST 18:35 UTC AVHRR SST 18:31 UTC VIIRS SST 2015/03/18 07:40 UTC

SLIDE 12

CSPP Summary

CSPP continues to support the polar orbiting

satellite DB community with a wide range of software and products supporting Suomi NPP, Metop, NOAA, and EOS satellites.

CSPP GEO now supports geostationary satellites.
We look forward to JPSS-1 in early 2017.
