Code Analysis via Version Control History Justin Mclean Class - PowerPoint PPT Presentation

Code Analysis via Version Control History Justin Mclean Class Software Email: justin@classsoftware.com Twitter: @justinmclean Blog: http://blog.classsoftware.com Who am I? Programming for 25 years Developing and creating web


  1. Code Analysis via Version Control History Justin Mclean Class Software Email: justin@classsoftware.com Twitter: @justinmclean Blog: http://blog.classsoftware.com

  2. Who am I? • Programming for 25 years • Developing and creating web applications for 15 years • Apache Flex PMC, Incubator PMC, Apache member • Release manager for Apache Flex, FlexUnit, Tour De Flex, Squiggly • Run IoT meetup in Sydney Australia

  3. The Mess We’re In In the last 40 years we have written billions of lines of code that will keep programmers employed for trillions of man hours in the next few thousand years to clean up this mess we’ve made. Joe Armstrong

  4. Your Code as a Crime Scene

  5. You Write Code? • 40-80% of all code is maintenance • This is difficult and expensive • More so with agile methodologies and on successful systems • How to make this effective? • Primary goal is to understand existing code • All code is legacy code

  6. Detecting Issues With Code • Code reviews • Pair programming • Unit Tests • Continuous Integration • Static code analysis • Complexity metrics

  7. Scalability • What about large code bases? • How do you decide what to work on? • How to work out where the bugs are? • What bugs are important?

  8. Code Visualisation • Can you visually represent code to get a better understanding of what’s going on? • Code City
 http://www.inf.usi.ch/phd/wettel/codecity- wof.html • Make a city of each class arranged by packages in city blocks • Height is number of methods, colour coded by no of lines and area by no of terms

  9. Code City

  10. Code City Limitations • Supports only a few common languages • Shows hotspots (large buildings) but no real indication of where to possibly spend effort • Existing hotspots may be stable • Missing an important dimension

  11. Version Control History • VCS contains a lot of useful information - that we mostly ignore. Information like: • Who changed what lines when • How much and how often things change • Can aggregate information to tell us something useful?

  12. Why code Changes • Fixing bugs • Refactoring poor design • Poor understanding of the problem • Change frequency == proxy for effort • Code that changes in the past is likely to change again in the future

  13. Effort + Complexity • Change frequency / effort is not the whole story • Config files changes frequently • Overlaps in effort and complexity gives possible hotspots

  14. Code Hotspots • Hotspots are code where changes will give the most benefit • Frequent changes to complex code indicate poor quality code • Lots of study in this area and surprisingly simple complex measures (change frequency) perform just as wells more complex measures

  15. What use are Hotspots? • Take cognitive biases out of the equation • Where you bugs are likely to be • Prime areas for code reviews • Prime areas for refactoring • Targets for extra testing

  16. Code Maat • Performs various analysis on version control history • Produces simple csv text files • Supports parsing git, svn, hg VCS • Open source (GPL) • https://github.com/adamtornhill/code-maat

  17. Producing HotSpot Data • Clone git repo • Work out time period • Generate git log summary data • Look as summary • Generate change frequencies • Generate code complexity metrics • Combine change frequency + complexity

  18. Apache Flex Project • Large code base
 No files = 25000,LOC = 5 million or about 20 million including tests • Mix of many file types and languages MXML, ActionScript, Java, XML files • Two distinct phases - before and after donation

  19. Adobe Flex SDK Summary statistic,value number-of-commits,30090 number-of-entities,4672 number-of-entities-changed,34916 number-of-authors,18

  20. Apache Flex SDK Summary statistic,value number-of-commits,2911 number-of-entities,51505 number-of-entities-changed,81012 number-of-authors,55

  21. Complexity • LOC is a terrible complexity measure, but turns out it’s just as bad as most others • Fast and simple • language agnostic • CLOC • https://github.com/AlDanial/cloc

  22. Apache Flex SDK Revisions module,revisions,code build.xml,139,1481 frameworks/build.xml,57,423 mustella/jenkins.sh,48,167 mustella/build.xml,44,1988 ide/checkAllPlayerGlobals.sh,35,85 frameworks/projects/mobiletheme/defaults.css,34,1568 modules/downloads.xml,34,384 installer.xml,29,821 frameworks/projects/spark/build.xml,28,231 frameworks/projects/textLayout/build.xml,28,218 frameworks/projects/framework/src/mx/collections/ ListCollectionView.as,28,1442

  23. Hot Spot Confirmation • Build files • Mobile theme • ListCollections • DataGrid and AdvancedDataGrid • DateField

  24. Hot Spot Limitations • Just numbers - may need to normalise • Time period may be hard to get right (hotspots move) • Impacted by individual commit styles • May have false positives • Just a guide - but still a very useful one

  25. Visualise Hot Spots • Hard to understand a large amount of information • Classes are nested in packages and we have complexity and change frequency / effort • Circle packing works well. Circle size is LOC, colour by change frequency. • D3.js easy to use / can display easily • Need CSV -> JSON conversion

  26. Apache Flex SDK

  27. Apache Flex SDK

  28. Apache Flex SDK

  29. Apache Flex SDK

  30. Hotspot Analysis • Hotspots are small proportion of all code • Configuration files vs complex application logic • Can have false positive - need to confirm

  31. Hotspot Analysis • Experimental area • 3rd party modules • Compiler • Data grids • support classes

  32. Complexity (again) • LOC OK but is there something better? • Whitespace indentation! • Easy to calculate / language independent

  33. DataGrid.as complexity • CLOC shows 50/50 split between code and comments with 2800 lines of actual code. • May be good idea to remove comments? • DataGrid.as whitespace
 n,total,mean,sd,max
 5860,9244,1.58,1.21,13 • Mean is low, sd is low, but max is way too high • Real hotspot

  34. Complexity Trend rev,n,total,mean,sd f52eb16,5608,8816,1.57,1.23 0c4290c,5609,8816,1.57,1.23 63580a8,5644,8856,1.57,1.23 fa2108b,5644,8856,1.57,1.23 abc381b,5644,8856,1.57,1.23 774cdd7,5791,9061,1.56,1.22 5e6e5c3,5791,9061,1.56,1.22 4388da8,5791,9061,1.56,1.22 ec1ac28,5810,9090,1.56,1.22 22b68de,5839,9124,1.56,1.22 b1d0359,5855,9164,1.57,1.22 1bef097,5851,9158,1.57,1.22 3e752d9,5854,9165,1.57,1.22 6c53962,5857,9172,1.57,1.22 c47f9f9,5855,9169,1.57,1.22 bb600fd,5855,9169,1.57,1.22 71f8757,5853,9230,1.58,1.21 3a1769b,5860,9247,1.58,1.21 8767c20,5860,9244,1.58,1.21

  35. Temporal Coupling • File that need to change at the same time • Causes: • Copy paste duplicated code • Inadequate encapsulation • Anti-pattern sometimes referred to as shotgun surgery

  36. Detect Temporal Coupling • Results are a bit noisy - may need to filter frameworks/projects/framework/src/mx/states/AddItems.as,
 frameworks/projects/spark/src/spark/components/Group.as,
 92,7 frameworks/projects/framework/src/mx/states/AddItems.as,
 frameworks/projects/mx/src/mx/core/Container.as,
 83,6 frameworks/projects/mx/src/mx/core/Container.as,
 frameworks/projects/spark/src/spark/components/SkinnableContainer.as,
 83,6 frameworks/projects/framework/src/mx/states/AddItems.as,
 frameworks/projects/spark/src/spark/components/SkinnableContainer.as,
 83,6 frameworks/projects/mx/src/mx/core/Container.as,
 frameworks/projects/spark/src/spark/components/Group.as,
 76,7

  37. Just Words?

  38. Knowledge Map • Generate ownership of files • Multiple owners per file imply more potential bugs • Knowledge maps - who know most about which files

  39. Apache Flex SDK

  40. Apache Flex SDK

  41. What we have learnt • Lot of useful information in your version control history waiting to be found out • Technique scales easily to (very) large code bases • Keep data formats simple • Simple measures of effort and complexity are often as good as complex ones • Can find out areas in need of attention in your code base

  42. Links • Code as a crime scene
 https://pragprog.com/book/atcrime/your-code- as-a-crime-scene • Code City
 http://www.inf.usi.ch/phd/wettel/codecity.html • CLOC
 https://github.com/AlDanial/cloc • Code Maat
 https://github.com/adamtornhill/code-maat

  43. Questions? Ask now, see me after the session,
 follow me on twitter @justinmclean
 or email me at justin@classsoftware.com . Slides can be found at conference site.
