CMB and Kinetic Inductance Detectors Clarence Chang ANL & KICP - PowerPoint PPT Presentation

CMB and Kinetic Inductance Detectors Clarence Chang ANL & KICP MKIDs & Cosmology Workshop FNAL August 26-27, 2013 Outline Quick (and incomplete) overview of CMB science Key concepts for CMB technology Current &


  1. CMB and Kinetic Inductance Detectors Clarence Chang ANL & KICP MKIDs & Cosmology Workshop FNAL August 26-27, 2013

  2. Outline • Quick (and incomplete) overview of CMB science • Key concepts for CMB technology • Current & near-future CMB detectors • KIDs at mm-wavelengths • KID-based CMB experiments

  3. SPT-SZ: Massive Cluster Gallery 2344-4243 ( z =0.60) 0658-5358 ( z =0.30) (Most X-ray (Bullet) IR-Optical luminous cluster known) SZ McDonald et al 2012 5 ’ 12 ’ “Phoenix” Cluster 2106-5844 ( z =1.13) 2337-5942 ( z =0.78) (Most massive cluster known at z > 1) Foley et al 2011 3

  4. SZ Cluster Surveys: Mass vs Redshift Area Depth (uK-arcmin) N clusters (deg 2 ) Planck All-sky 45 861 SPT 2500 17 465 ACT 950 23-40 91 Notes: • For each experiment, the 150 GHz depth is given, most important band for cluster counts First SZ-discovered cluster • Planck based on ~1/2 survey, cluster counts should ~double for full survey was in 2008 (Staniszewski et • N clusters highly dependent on completeness of al) ; 5 years later there are > optical follow-up, which varies between each 1300 SZ-identified clusters! experiment

  5. CMB Science TT ����� ����� EE ����� ����� BB lens ����� ����� BB infl ����� ����� Spectra generated with WMAP7 parameters using CAMB, Lewis and Challinor

  6. CMB Science TT EE N eff BB lens BB infl Spectra generated with WMAP7 parameters using CAMB, Lewis and Challinor

  7. CMB Science TT EE N eff BB lens Σ m ν BB infl Spectra generated with WMAP7 parameters using CAMB, Lewis and Challinor

  8. CMB Science TT EE N eff BB lens Σ m ν BB infl r [0.01:0.10] Spectra generated with WMAP7 parameters using CAMB, Lewis and Challinor

  9. CMB Science

  10. CMB Science

  11. Relevant numbers • Lensing B-mode amplitude ~5 μ K-arcmin • High S/N measurement requires very deep maps with better than 3 arcmin resolution • Sample variance 1 1 X ˆ C ` = h | a lm | 2 i = | a lm | 2 � C ` ∝ p 2 ` + 1 (2 ` + 1) f sky m • Measure large areas of sky • Instruments need lots of sensitivity!

  12. BLIP: Background Limited Infrared Power 1 < n > = e h ν /kT − 1 < n 2 > = n ( n + 1) • Sensitivity of individual detectors is now limited by shot noise of the photon flux • Increasing sensitivity of an experiment requires increasing the number of detectors

  13. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 P l a n c k − 3 10 CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  14. Current technology: Transition Edge Sensor TES% P signal % T+δT% Heat%Capacity% Weak%thermal%link,% Resistance)[Ω]) G 81 % δR) Heat%Sink%(~240%mK)% δT) Temperature)[K])

  15. Current technology: TES (antenna coupled) Sky Antenna& structure& Pol&X& Polarbear Detector& SPTpol (& ACTpol) Pol&Y& Detector& BICEP2/Keck & SPIDER

  16. Focal plane arrays Polarbear SPTpol BICEP2/Keck & SPIDER

  17. Focal plane arrays 1300 bolos Polarbear SPTpol 1600 bolos BICEP2/Keck & SPIDER 2500 bolos

  18. Multiplexing (MUX) Time-domain Frequency-domain (switching) (AM radio) O (10) MUX factor

  19. Noise Equivalent Power (NEP) Henning et. al., Proc. SPIE 8452, 84523A (October 5, 2012)

  20. Noise Equivalent Power (NEP) Photon shot noise ~5e-17 W/rtHz

  21. Noise Equivalent Power (NEP) Photon shot noise ~5e-17 W/rtHz 0.5 deg/sec scanning puts 1 deg at 0.5 Hz

  22. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 P l a n c k − 3 10 CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  23. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 You P are here l a n c k − 3 10 CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  24. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 You P are here l a n c k − 3 10 We see B-modes! CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  25. We see B-modes SPT SPTpol SPTpol: Hanson et al, arXiv:1307.5830 (PRL in press)

  26. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 You P are here l a n c k − 3 10 CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  27. Superconducting microstrip • Microstrip allows for manipulation of electric field • Can move band pass “on chip”

  28. Superconducting microstrip • Microstrip allows for manipulation of electric field • Can move band pass “on chip” Yoon et al., AIP Conf. Proc. 1185, pp. 515-518

  29. Multi-chroic pixels Filter$ 150$GHz$ 90$GHz$ “X”$polariza,on$ Broadband$ Antenna$ Bolometer$ Bolometer$ “Y”$ “Y”$ polariza,on$ polariza,on$ “X”$polariza,on$ 150$GHz$ 90$GHz$ • Developing arrays of three-color pixels for SPT-3G • Increase bolo density from 2 per pixel to 6 per pixel Suzuki et al., Proc. SPIE 8452, Mm, Sub-mm, and Far-IR Detectors and Instr. for Astro. VI, 84523H (October 5, 2012)

  30. Fabrication challenge includes superconducting microstrip One&pixel&<&6&mm& Antenna& structure& Pol&X& Detector& Detector& Detector& Pol&Y& Detector& Detector& Detector& 39way&channelizer& Atmospheric,windows, Frequency,[GHz],

  31. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 You P are here l a n B-mode c k − 3 10 imaging CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  32. Stages of CMB experiment Space based experiments − 1 Stage − I − ≈ 100 detectors 10 Approximate raw experimental sensitivity ( µ K) Stage − II − ≈ 1,000 detectors Stage − III − ≈ 10,000 detectors W Stage − IV − ≈ 100,000 detectors M A P − 2 10 You P are here l a n c k − 3 10 CMB − S4 − 4 10 2000 2005 2010 2015 2020 Year

  33. Stages of CMB experiment

  34. KIDs in mm-wavelengths • NIKA (~200 detectors)/NIKA2 (5000 detectors) on IRAM • MUSIC (~2300 detectors) on CSO

  35. Photon noise limited (almost) Yates et. al., Appl. Phys. Lett. 99 , 073505 (2011) arXiv:1212.4585

  36. Photon noise limited (almost) Yates et. al., Appl. Phys. Lett. 99 , 073505 (2011) ~2e-16 W/ √ Hz arXiv:1212.4585

  37. Photon noise limited (almost) Yates et. al., Appl. Phys. Lett. 99 , 073505 (2011) ~6e-17 W/ √ Hz arXiv:1212.4585

  38. Photon noise limited (almost) Yates et. al., Appl. Phys. Lett. 99 , 073505 (2011) TLS noise arXiv:1212.4585

  39. mKIDs in CMB experiments ble through a series of access holes at the center of the base and attachment tables. Oguri et. al., Rev. Sci. Instrum. 84 , 055116 (2013) • GroundBIRD • SKIP (proposed) arXiv:1308.0235

  40. Conclusions • Currently fielded CMB arrays (TES) have O (1000) detectors • Next 3-5 years, will field arrays with O (10,000) detectors (SPT-3G, PBII/ Simons Array, BICEP3, extended ACTpol) • 5+ years will need O (100,000) detectors • KIDs nearing photon noise limit at higher frequencies • Need to/will address TLS noise at low frequencies • Challenges involve production of superconducting microstrip • Modest increase to O (100) MUX, multiple radiometers
