1 Cloud deployment of M2M applications OpenHAB, RabbitMQ and Storm use case February 19, 2014 Eclipse IoT day - Grenoble Pierre-Yves Gibello : pygibello@linagora.com Noël De Palma : noel.de_palma@imag.fr

Summary 2 ● M2M "ubilytics" big picture ● Deployment issues ● A processing chain ● Roboconf dynamic (re)configuration ● Demo scenario

M2M "ubilytics" big picture 3 Send selected sensors meausrements In elastic Cloud M2M Reporting, NoSQL Store Gateway In elastic Cloud MongoDB, Dashboard, . @ Home, Office, (history charts, ...) Cassandra, HDFS Message Broker Warehouse Message Broker (OpenHAB, IoTSys) or MaaS or PSaaS or MaaS or PSaaS Mosquitto, RabbitMQ, … Storing Mosquitto, RabbitMQ, … MapReduce Protocols : MQTT, AMQP, M2M Protocols : MQTT, AMQP, agregates STOMP, XMPP, CoAP ... Hadoop STOMP, XMPP, CoAP ... Gateway Computed @ Home, Office, prediction model Warehouse Realtime ESP Sensors data messages Storm, Samza, S4, ie energy Consumption, Predictions MQTT, AMQP, Embedded boards temperature, ... Spark Streaming, … STOMP ... Trends, ... smartphones topologies by millions ESP Monitoring Placement (static,dynamic) Deployment & (Re)Configuration (Roboconf)

Deployment issues 4 Multi-scale ● From embedded (box, sensor, card...) to cloud / IaaS ● More and more devices while IoT emerges ● Elastic & adaptative ● Add/remove components (eg. according to load patterns) ● Adapt data flow (eg. load balancing) ● Optimize (eg. co-locate) ● Dependencies to be resolved at runtime ● Location of components (eg. where to send data) ● Configuration information (eg. database credentials) ●

A processing chain 5 Example : energy consumption forecast, based on Storm. Dynamic elasticity (eg. on IaaS) Bottleneck detection Shrink when possible (lower flow) Insert additional node(s) + reconfigure Remove useless node(s) + reconfigure

Roboconf dynamic (re)configuration 6 Application model ● Graph of components (eg. VMs or software packages) with ● dependencies (export/import of configuration variables) Initial deployment description (set of instances, deployed on VMs) ● Deployment manager (DM) ● Creates VMs on IaaS when necessary ● Deploys the model (including software packages) on VMs ● Agent ● Present on each VM ● Cross-instances communication (exchange of variables import/export) ● Admin communication with DM ● Lifecycle of software deployed on the VM (setup, start, stop...) ● according to dependency resolution Asynchronous communication ● Based on RabbitMQ ●

RoboConf in details 7 MQ / JMS Roboconf Propagate Deployment Exchange / resolve model Manager imports / exports VMbeagle { alias: Beagle board; Agent Agent installer: iaas; i nstanceof VMbeagle { children: openhab; name: Beagle1; } l variables variables i l f i f e instanceof openhab { VMaws { e import / export c import / export c name: openhab1; y alias: Virtual machine; y c c l httpPort: 8080; installer: iaas; e l e } children: mqtt; } } ... instanceof VMaws { Configurable Configurable Configurable openhab { Configurable name: VM_MQTT1; installer: bash; software software software software instanceof mqtt { exports: httpPort; name: MQTT1; imports: mqtt.ip; } } + dependencies (RPMs...) + dependencies (RPMs...) } mqtt { installer: bash; exports: ip; VM (EC2...) } VM (Beagle board...) or any device or any device

Demo scenario (1) 8 Replay load and work from CSV data file of house #0 MQTT Connection Port 1883 OpenHAB House #0 MQTT Connection MQTT Connection Port 1883 Port 1883 Mosquitto VMo2 Mosquitto MQTT MQTT broker MQTT broker WebReport Node.js OpenHAB (Node RED) House #1 VM AmazonWS "VM" BeagleBone RoboConf deployment & (re)configuration

Demo scenario (2) 9 Roboconf = DM (webapp) + messaging server Client Push Roboconf application DM (5) Data analysis (1) Deploy MQTT server on new VM (1) Deploy OpenHAB + data simulation (2) No dependency MQTT = ready to start server (2) Expecting (3) Export IP address of MQTT server dependency (IP of MQTT) = not ready to start Messaging Server (4) Publish sensor data on MQTT

That's all, Folks ! 10 Any question ?
