Clean Sky/ SFWA-ITD BLADE FLIGHTLAB The flagship laminar flow project AIRBUS SAS 26 th of September 2017 SFWA/BLADE Paris Air Show ( Le Bourget) – 21st June 2017
Laminar technology Up to 8% drag reduction potential for a short range aircraft vs. a turbulent wing Up to 5% fuel burn saving on 800 NM mission Mastering laminar/turbulent transition in line with industrial requirements
Leading edge and wing contamination: Atmospheric Acoustic disturbances insects, grease, de- icing fluids, scratches, dents, erosion, dust, … and vibrations disturbances What influences the existence of a natural laminar flow on an industrial wing ? Joint & filler System Wing global Wing local Fastener head deformation integration deformation deformation deformation
21 European Partners 500 Contributors 6500 Parts 150 Flight Test Hours planned 2000 Parameters to capture Heavy Modification of A340-300 MSN001 • Replacement of Outer Wings with Laminar wings • Modification of VTP to add a Pod
Wing Architectures Port wing Starboard wing
Design Freeze (up 2014) Infrared Camera 2 Trailing Infrared Cone Tube Camera 1 Flow Cone Cameras Calibration Plate
Advanced FTI Technologies
Components Manufacturing (2015/2016) Integration
