Clean Harbors Deer Park, LLC Delta Companies Group ^ Dow Chemical Company DPO (was Rohm & Haas) Evonik Oil Additives USA, Inc.^( Voluntarily reports VOCs to DPCAC ) GEO Specialty Chemicals, Inc. Hexion Inc. Intercontinental Terminals Company LLC** Lubrizol Corporation Oxy Vinyls, LP – Deer Park PVC/CA Oxy Vinyls, LP – Deer Park VCM Shell Deer Park – Chemical Plant & Refinery TM Deer Park Services LP^ (Texas Molecular) Valvoline LLC^ Vopak Terminal Deer Park* ^ Not required to report Emissions Inventory * Not required to report TRI Form R data ** Not required to report TRI Form R but provided data 2 DPCAC 2018 Emissions Presentation

} Learn what CAC plants release to air, water and land } Help public learn about chemicals in the community } Tool for helping CAC hold plants accountable } Plants may learn from their own reports and others } Allows us to track trends; but trends are affected by changing circumstances 3 DPCAC 2018 Emissions Presentation

• Combination of estimates and measurements o Accuracy growing over the years • Measurements from Continuous Emissions Monitoring Systems (CEMS), stack and vent tests, lab analysis, other direct measurements • Estimates from calculations based on fuel consumption, mass balance, engineering calculations, throughput formulas, flow measurements, inventory loss, production data, field surveys o Fugitives often estimated by EPA’s AP-42 factors o Direct measurements may be incorporated into calculations • Changing methods to improve accuracy may result in different numbers. 4 DPCAC 2018 Emissions Presentation

• Changing number of plants in CAC • Actual long term changes in emissions o Adding units or closing them o Investing in pollution prevention • Making a different mix of products; e.g. more or less volatile • Production/customer demand -- up or down • Maintenance and related shutdowns and startups • Upsets, leaks, spills • Changing calculation methods 5 DPCAC 2018 Emissions Presentation

Sources include… } Industry ◦ Chemical ◦ Petroleum refining ◦ Electric generation } Transportation TCEQ Emission TC ons ◦ Cars and trucks Inventory (EI) In I) ◦ Marine ◦ Aviation and EPA Toxics EP trains Releas Re ase ◦ Off-road vehicles In Inventory (construction) (T (TRI) } Other All Air All Air ◦ Small Businesses Po Pollut utant nts ◦ Home } Biogenic Sources ◦ Vegetation, fires } Plus pollen, etc. Not to scale 6 DPCAC 2018 Emissions Presentation

Air Emissions Inventory Toxics Release Inventory q Federal requirement (EPA) q State requirement (TCEQ) q Criteria pollutants q Selected toxic chemicals q Public right-to-know q Air contaminants only q Almost all contaminants q Contaminants released to air, (even small quantities) water, land, & offsite transfers q Chemicals from list of >650 that q Basis for setting fees meet threshold quantities Both Reports q Include point source and fugitive emissions q Include permitted, upset and maintenance emissions q Are based on direct measurements, engineering estimates, and factors q Exempt small facilities 7 DPCAC 2018 Emissions Presentation

Thresholds are specified amounts of chemicals used during the calendar year that trigger reporting requirements. • Manufactures or Imports – 25,000 pounds • Processes – 25,000 pounds • Otherwise Uses – 10,000 pounds • 21 chemicals and chemical categories are classified as persistent, bioaccumulative, toxics and have lower reporting thresholds 100 pounds o 10 pounds o 0.1 grams o 8 DPCAC 2018 Emissions Presentation

CO CO NO NOx Gas Meter Gas Meter VOC VOC 13 Fugitive Sources 13 Fugitive Sources SO SOx Water Heater Point Source 9 DPCAC 2018 Emissions Presentation

DPCAC 2018 Emissions Presentation

Criteria Pollutants Include: •Nitrogen Oxides (NOx) {ozone precursor} •Volatile Organic Compounds (VOCs) {ozone precursor} •Sulfur Oxides (SOx) •Carbon Monoxide (CO) •Total Suspended Particulate (TSP) 11 DPCAC 2018 Emissions Presentation

18,000,000 16,000,000 CO 14,000,000 TSP 12,000,000 SOx 10,000,000 VOC 8,000,000 NOx 6,000,000 4,000,000 2,000,000 0 2014 2015 2016 2017 2018 2014 à 2018: 0.73% Reduction in Total Criteria Pollutant Emissions 2017 à 2018: 1.5% Reduction in Total Criteria Pollutant Emissions 12 DPCAC 2018 Emissions Presentation

Criteria Pollutant 2014 2015 2016 2017 2018 NOx 4,580,101 4,339,505 4,479,795 4,103,439 4,203,552 VOC 4,103,343 4,607,467 4,027,869 4,333,191 3,989,903 SOx 3,094,531 3,342,563 3,104,196 3,581,865 3,517,790 TSP 960,659 886,709 920,013 950,945 871,450 CO 3,004,180 2,973,998 2,552,704 2,889,157 3,045,842 Total 15,742,815 16,150,242 15,084,576 15,858,597 15,628,536 Decrease from 2017 to 2018 caused by: NOx emissions up 100k lbs • VOC emissions down 343k lbs • SOx emissions down 64k lbs • TSP emissions down 79k lbs • CO emissions up 157k lbs • Note: “k” equals 1,000 13 DPCAC 2018 Emissions Presentation

2016 2017 2018 Company 7,819,282 8,085,395 7,978,768 Shell Deer Park 4,874,697 4,378,015 4,798,506 The Dow Chemical Company 555,423 575,620 698,546 Intercontinental Terminals Company LLC 741,079 801,409 687,732 Vopak Terminal Deer Park 777,479 751,835 654,000 The Lubrizol Corporation 251,902 256,300 251,322 Hexion (formerly Momentive) 235,565 291,114 184,111 Clean Harbors 130,935 132,087 132,156 Oxy Vinyls, LP DP VCM 120,015 115,601 112,885 Oxy Vinyls, LP - Deer Park PVC/Caustic Plant 50,280 34,122 28,820 GEO Specialty Chemicals, Inc. 24,600 25,500 25,500 EVONIK Oil Additives USA, Inc. NR NR NR TM Deer Park Services Limited Partnership NR NR NR Delta Companies Group NR NR NR Valvoline Deer Park 15,084,576 15,867,489 15,628,536 Total Note: Companies highlighted in yellow reported data for 2018. 14 DPCAC 2018 Emissions Presentation

Shell • VOC emissions decreased 20% (495k lbs) due to stable operations (Hurricane Harvey a factor in 2017) Dow • VOC emissions increased 21% (95k lbs) due to increase in flare gas sent to flare • CO emissions increased 28% (127k lbs) due to increase in flare gas sent to flare • NOx emissions decreased 10% (62k lbs) from use of generator Vopak • VOCs decreased 17% (97k lbs) due to changes in types/quantities of chemicals stored on site. 15 DPCAC 2018 Emissions Presentation

Oxy Vinyls PVC • NOx decreased 20% (7.6k lbs) due to the change in AP-42 factors used to calculate the emission and were updated in a permit amendment approved by TCEQ. • VOCs decreased 19% (9.9k lbs) from reduction in LDAR plant fugitives • CO increased 124% (9.9k lbs) due to the change in AP-42 factors used to calculate the emission and were updated in a permit amendment approved by TCEQ. ITC • VOCs increased 18% (62k lbs) due to normal changes in terminal storage scenarios and operational activity • CO increased 29% (56k lbs) due to normal changes in terminal storage scenarios and operational activity 16 DPCAC 2018 Emissions Presentation

Lubrizol • VOC decreased 12% (49k lbs) due to increased reliability of process units and use of boiler • CO decreased 19% (33k lbs) due to decreased to use of boiler and heaters in one of the process units Hexion • NOx (12%-3k lbs) and CO (10%-2.1k lbs) decreased due to flare shutdown during unit turnaround OxyVinyls VCM VOCs decreased 23% (6.6k lbs) due to Cooling Tower GC – upgrade which resulted in more accurate VOC readings. Reduction also due to ethylene emission event in 2017. 17 DPCAC 2018 Emissions Presentation

2016 2017 2018 Company 3,373,748 2,990,496 3,223,004 Shell Deer Park 609,568 617,733 555,272 The Dow Chemical Company 149,560 210,640 152,167 Clean Harbors 157,251 104,265 94,204 The Lubrizol Corporation 68,009 60,169 65,250 Oxy Vinyls, LP DP VCM 38,858 41,022 44,626 Intercontinental Terminals Company LLC 38,313 37,039 29,532 Oxy Vinyls, LP - Deer Park PVC/Caustic Plant 26,367 25,559 24,040 Vopak Terminal Deer Park 15,848 14,016 13,258 GEO Specialty Chemicals, Inc. 2,273 2,500 2,200 Hexion (formerly Momentive) NR NR NR Delta Companies Group NR NR NR EVONIK Oil Additives USA, Inc. NR NR NR TM Deer Park Services Limited Partnership NR NR NR Valvoline Deer Park 4,479,795 4,103,439 4,203,552 Total 18 DPCAC 2018 Emissions Presentation

5,000,000 4,500,000 4,000,000 3,500,000 3,000,000 2,500,000 2,000,000 1,500,000 1,000,000 500,000 0 2014 2015 2016 2017 2018 2014 à 2018 : 8.5% Reduction in NOx Emissions 2017 à 2018 : 2.4% Increase in NOx Emissions 19 DPCAC 2018 Emissions Presentation

NOx emissions have decreased 84% since 1997. 20 DPCAC 2018 Emissions Presentation
