conference & convention enabling the next generation of networks & services Challenges of New Significant Seabed User & Market Technologies Rod Seville HA i Limited
conference & convention enabling the next generation of networks & services A New Century – A New Offshore Technology Industry Arrives European governments agree that 20% of national energy generation should be produced from all renewable energy sources ! The result: New technologies generating energy from Wind, Tidal/Current & Wave motion are evolving / being deployed in the offshore marine environment to meet this commitment.
conference & convention enabling the next generation of networks & services Development areas will be located: Near shore & along coast lines Between islands & islands / mainland Further Offshore Probable impacts to telecommunications systems could/will be in the following areas: Cable Routings System Costs Cable Landing Approaches Cable Crossings Cable Maintenance Activities Decommissioning
conference & convention enabling the next generation of networks & services Sources of Offshore Renewable Energy Floating Wind Fixed Wind Wave / Tidal Current Wave / Tidal Water Column Current
conference & convention enabling the next generation of networks & services
conference & convention enabling the next generation of networks & services Offshore Renewable Technology Factors Technologies = Evolving, Wind the most advanced More Power = Larger seabed footprint Locations = Various – d epending upon the energy source Network Connectivity = All directly to shore Future Connectivity = Networked Offshore & becoming complex.
conference & convention enabling the next generation of networks & services Current Offshore Technology Parameters Installation Distance water depth Offshore ≤ ↑ 100km Wind - Static tower 50m 120m – 700m - Floating tower variable ≥ ↑ 20km Wave 50m ≤ Tidal / Current 50m variable
conference & convention enabling the next generation of networks & services Projected number of Wind turbines to be installed in UK waters up to 2020 Courtesy of BVG associates
conference & convention enabling the next generation of networks & services What does this really mean for the UK in Wind development? • Investment of c £100 billion up to 2020 • Installation of up to 6000+ wind turbines • Creation of 30+ Gigawatts of power by 2020 from offshore wind alone • 28,500 km of sea area allocated for development up to 2020
conference & convention enabling the next generation of networks & services Annual & Cumulative UK & European Wind Construction up to 2020 Courtesy of BVG associates
conference & convention enabling the next generation of networks & services And Europe? Comparable Investment c £100 billion • • Installation of up to 5500 wind turbines (ex.UK) • Creation of 20+ Gigawatts of power by 2020 from offshore wind alone • c.19,000 km of Sea area allocated for development up to 2020
conference & convention enabling the next generation of networks & services European Wind Developments to 2020 Courtesy of EWEA & Le Tene Maps
conference & convention enabling the next generation of networks & services Alternative Technologies • Wave, Tidal/Current are currently 2-5 years behind wind technology but are developing rapidly • Whilst Wind technology is moving further offshore, Wave, Current/Tidal technologies will likely remain relatively close to shore or on shallow continental shelves
conference & convention enabling the next generation of networks & services Future Network Evolution ?
conference & convention enabling the next generation of networks & services European Super-Grid Concept Configuration Courtesy of Mainstream RP
conference & convention enabling the next generation of networks & services Supernode Concept 2 x 500MW 2 x 500MW 2.4GW 2.4GW 2.4GW 400kV ± 320kV Converter Station ± 320kV 2.4GW 2 x 500MW 2 x 500MW Courtesy of Mainstream RP
conference & convention enabling the next generation of networks & services Areas of potential impact Telecom cable systems will/could be affected by Offshore Energy in several areas : • Cable Routing • Cable Landings • Cable Crossings • Cable Maintenance Methodologies / Procedures • System Decommissioning
conference & convention enabling the next generation of networks & services Considerations for the Industry Development & Innovation • Cable Corridors? - To suit the industry • Retain OOS routes?- Retain Shore End Landings as priorities • Collaboration? - Joint developments of cable routes? • Offshore Hubs? - Multiple system Hubs to Shore links (high fibre unrepeatered systems?) • Energy Tapping? - Longer System Lengths • Diversification? - Energy fibre to diversify/enhance systems? Drivers • Costs &/or issues of access/re-routing cables? • Benefits of collaboration on network diversification? • Decommissioning Costs?
conference & convention enabling the next generation of networks & services Courtesy of IET media & information
conference & convention enabling the next generation of networks & services Thank You Rod Seville HAi Limited Rod.Seville@hai-ltd.com Tel. +44-1277-375180 Mobile. +44-7768-157308
