Cardinality Estimation Done Right: Index-Based Join Sampling Viktor - PowerPoint PPT Presentation

Cardinality Estimation Done Right: Index-Based Join Sampling Viktor Leis, Bernhard Radke, Andrey Gubichev, Alfons Kemper, Thomas Neumann Technische Universitt Mnchen Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right:


  1. Cardinality Estimation Done Right: Index-Based Join Sampling Viktor Leis, Bernhard Radke, Andrey Gubichev, Alfons Kemper, Thomas Neumann Technische Universität München Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  2. Join Ordering ◮ finding a good join order is arguably the most important problem in query optimization ◮ the costs of different join orders often vary by orders of magnitude ◮ to distinguish good plans from bad ones, the cost of plans must be estimated using cardinality estimates for intermediate results ◮ example: to find the optimal join order for A ⊲ ⊳ A . id = B . aid B ⊲ ⊳ B . cid = C . id C , one needs estimates for A ⊲ ⊳ B and B ⊲ ⊳ C Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  3. ← → The State of the (Industrial) Art in Cardinality Estimation ◮ in virtually all systems estimation is based on: 1. histograms and unique value counts 2. strong assumptions: uniformity, independence, inclusion ◮ results with real-world data are terrible (Join Order Benchmark [Leis et al., VLDB 2016]): Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  4. The State of the (Industrial) Art in Cardinality Estimation ◮ in virtually all systems estimation is based on: 1. histograms and unique value counts 2. strong assumptions: uniformity, independence, inclusion ◮ results with real-world data are terrible (Join Order Benchmark [Leis et al., VLDB 2016]): PostgreSQL ← underest. [log scale] overest. → 1e4 1e2 1 1e2 1e4 1e6 1e8 0 1 2 3 4 5 6 number of joins Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  5. The State of the (Industrial) Art in Cardinality Estimation ◮ in virtually all systems estimation is based on: 1. histograms and unique value counts 2. strong assumptions: uniformity, independence, inclusion ◮ results with real-world data are terrible (Join Order Benchmark [Leis et al., VLDB 2016]): PostgreSQL PostgreSQL normalized plan cost [log scale] ← underest. [log scale] overest. → 1e4 30 1e2 1 10 1e2 1e4 3 1e6 1e8 1 0 1 2 3 4 5 6 0% 25% 50% 75%100% number of joins percentile Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  6. Sampling to the Rescue? ◮ sampling, which does not rely on strong assumptions, is a highly promising alternative ◮ some systems (e.g., HyPer) use sampling to estimate base table selections: ◮ keep random samples for each table (e.g., 10,000 rows) and execute selection on sample ◮ produces accurate estimates for arbitrary predicates (correlations etc. are not a problem) ◮ How to use sampling for joins, which are the main source of errors? Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  7. Using Samples for Joins We could pretend that samples are base tables and compute the join result ◮ would allows use to estimate the result size ◮ could become expensive, too (unlikely, but possible) ◮ usually, joining samples will produce small/empty results ◮ need a mechanism to sample the real join result ◮ but we cannot sample everything ◮ number of join candidates is exponential Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  8. Related (Sampling-Based) Work ◮ CS2 [Yu et al., SIGMOD 2013] ◮ pre-materialize correlated samples to avoid joining independent samples ◮ works well for star queries, but it is unknown how to apply this idea automatically for arbitrary queries ◮ ROX [Kader et al., SIGMOD 2009] ◮ greedy heuristics that uses sampling through indexes to make more informed decisions ◮ does not enumerate all join orders ◮ Sampling-Based Re-Optimization [Wu et al., SIGMOD 2016] ◮ get plan from traditional optimizer ◮ repeat until plan does not change: execute plan using 5% samples of each table ◮ high overhead (large samples), avoids some bad plans but often misses optimal plan (no systematic exploration) ◮ sampling-based approaches proposed so far have weaknesses that preclude their use in industrial-strength systems Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  9. Index-based Join Sampling: Main Ideas 1. use existing index structures and fixed-size samples (1000) to get samples for larger intermediate results 2. systematically explore intermediate results in a bottom-up fashion (2-way joins, 3-way joins, . . . ) 3. inject cardinalities computed in step 2 and run exhaustive join ordering algorithm (e.g., dynamic programming) Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  10. 1. Cheap Sampling Using Indexes ◮ given a sample S obtain a sample for S ⊲ ⊳ S . id = A . id A using an existing index on A . id : 1. count the number of join partners for each tuple in S 2. draw tuples at random to obtain desired number of results S sample of T count per tuple ( cpt ) sum : 15 6 1 3 5 S A B (not materialized) Sout sample of sid : {2,4,8,13} 2 4 8 13 T B A chosen : 0 chosen : 0 chosen : 2 chosen : 3 o ff set : 2 o ff set : 4 o ff set : 1 o ff set : 3 ◮ makes each sampling step cheap by avoiding “exploding” intermediate result sizes ◮ O ( | S | ) or O ( | S | log | A | ), | S | ≤ 1000 Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  11. 2. Systematic Bottom-Up Exploration ◮ generate samples for base tables ◮ join using existing indexes obtaining results for all 2-way joins, only then proceed to 3-way joins ◮ avoids “fleeing to ignorace” of the optimizer ◮ we need only one estimate per equivalence class ◮ stop early if sampling budget (e.g., 100K lookups) runs out ◮ budget is a parameter that determines how much time is spent in the additional sampling phase Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  12. 3. Join Ordering ◮ inject cardinalities from step 2 into traditional optimizer ◮ fall back to traditional estimation if a result could not be estimated using sampling (due to missing indexes, a too small budget, or very high selectivities) ◮ run traditional (typically exhaustive) join enumeration algorithm, which now has much more accurate information ◮ execute resulting plan Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  13. Does Sampling Improve Estimation? PostgreSQL index-based (10K) index-based (100K) index-based (no budget) 1e4 ← underestimation [log scale] overest. → 1e2 1 1e2 1e4 95th percentile 1e6 75th percentile median 25th percentile 1e8 5th percentile 0 1 2 3 4 5 6 0 1 2 3 4 5 6 0 1 2 3 4 5 6 0 1 2 3 4 5 6 number of joins Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  14. How Expensive is Sampling? sampling-based re-optimization index-based sampling (100K) index-based sampling (10K) index-based sampling (no budget) sampling time [ms] [log scale] 1000 100 10 4 8 12 16 number of joins Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  15. Does Sampling Improve Plan Quality? PostgreSQL normalized plan cost [log scale] 30 sampling-based re-opt. index-based samp. (10K) 10 index-based samp. (100K) index-based samp. (no budget) 3 1 0.3 0% 25% 50% 75% 100% percentile Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling

  16. Summary ◮ index-based join sampling is an effective approach for cardinality estimation in main-memory database systems ◮ considerably improves estimation and plan quality ◮ low and configurable overhead ◮ easy to integrate into existing systems ◮ also possible as an optional phase (e.g., triggered by the user) for hard, long-running queries Leis, Radke, Gubichev, Kemper, Neumann Cardinality Estimation Done Right: Index-Based Join Sampling
