CAL-MUM CENTRAL SCHOOL DISTRICT MAY 22, 2018 Agenda Project Scope Highlights Cost Estimate Financing Pre-Ref Schedule Questions Project Scope Elementary School Roof replacement of nearly 7500 SQ/Ft Replacement of PA


  1. CAL-MUM CENTRAL SCHOOL DISTRICT MAY 22, 2018

  2. Agenda • Project Scope Highlights • Cost Estimate • Financing • Pre-Ref Schedule • Questions

  3. Project Scope Elementary School • Roof replacement of nearly 7500 SQ/Ft • Replacement of PA system • Renovation of the Elementary School Gymnasium including bleacher replacement, gym floor painting and refinishing.

  4. ES Roof Replacement

  5. Project Scope Middle/High School • Renovation to MS/HS Auditorium—Sound, lighting and rigging systems • Roof replacement of nearly 10,000 SQ/Ft • Install in-wall flashing down the music corridor • Replacement of septic system pumps, controls and wiring • Enhance high school parking lot (72 spaces)

  6. MS/HS Roof Replacement

  7. HS Parking Lot

  8. Project Scope Hamilton Field Student/Athlete Sports Complex • Replace track surface • Replace turf fabric • Install new shock pad • Increase positive drainage • Install new soccer safety netting • Install pole vault concrete pads • Replacement of windows in press box

  9. ▪ 2006: Design and Installation ▪ 2006-2018: ▪ Ongoing maintenance operations – testing & extending the life of the field ▪ Utilization exceeds expectations ▪ Drainage issues persist throughout the years – 8 flooding events in 2017 ▪ 2017/18: Re-investigate drainage, Schematic Design, SED Meeting ▪ 2019: Re-construction with first game on new turf in September

  10. Gmax ~ Impact & Energy Absorption Force = Mass * Acceleration Gmax = Ratio of Deceleration to Gravity Gmax for Safe Play < 165

  11. Rainfall Events 2016-2018 3.00 2.50 2.00 Inches of Rain 1.50 1.00 0.50 0.00

  12. • 95% Compacted Subgrade • Non-Woven Geosynthetic Fabric • J-Drains • ~¾” Drainage Stone • ~¼” Leveling Stone • Shock Pad (Optional) • Turf Carpet • Infill – Rubber & Sand

  13. Investigation Existing System ▪ Reviewed Previous Appel ▪ Synthetic Turf directly on stone Osborne Design (1.5” finishing & 4.5” base) ▪ Obtained Submittal Data ▪ 0.5% cross slope ▪ 3 – Infiltration Tests ▪ Flat Panel Underdrain in Herringbone Pattern ▪ Sieve Analysis ▪ Perimeter Drainage discharge to Drywells

  14. ▪ Infiltration rates tested at 27 in/hr to 36 in/hr ▪ As witnessed in field – results did not appear reliable due to water ponding at surface ▪ Visually – Material was very fine throughout section with significant migration of fines down to the flat panel drains – roughly ½” around flat panel drain. ▪ Sieve Analysis Results – The Culprit

  15. Gradation Comparisons of Stone 120 100 80 % of Material Passing Sieve 60 40 20 0 3/8" #4 #40 #200 Base Stone Finishing Stone Analyzed

  16. ▪ Safety ▪ Stewardship ▪ Playability & Durability ▪ Drainage

  17. University of Tennessee Center for Athletic Field Safety - Natural Turf Grass Test Results ASTM F 355-2016 MISSILE E COMPARISON TO ARTIFICIAL TURF SYSTEMS 1400 1300 2” Turf- 65/35 Sand/Rubber over 1200 PowerBase YSR 2” Turf- 65/35 Natural Turf Grass 1100 Sand/Rubber over Range Brock SP14 1000 2” Turf- 65/35 Sand/Rubber over 900 Proplay 23D 2” Turf- 65/35 800 Sand/Rubber over HEAD 25mm E-Layer 700 INJURY 2” Turf- 65/35 CRITERION Sand/Rubber over 600 Versatile 500 2” Turf- 65/35 Sand/Rubber over Viconic (10mm) 400 2.5” Turf with “Elite” 300 infill spec over Stone 200 HIC 1000 (16% Risk severe head injury ) 100 HIC 700 (5% Risk severe head injury ) 0 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0 2.1 2.2 2.3 2.4 2.5 2.6 2.7 Drop Height in Meters

  18. ▪ Player Safety Considerations ▪ Safety Testing Options ▪ Crumb Rubber Recycling

  19. ▪ Future Carpet Replacement ▪ Aidability ▪ Value SED requires 15 life cycle to qualify for replacement & receive full aid. Full Aidability = 82% State Aid 13 Years since installation, so 86% (13/15) through cycle Pro-Rated = 70% State Aid

  20. ▪ Improvements in Filament and Backing systems ▪ Slit-Film vs. Multi-Film Systems – Consider Frequency of Use ▪ Increasing the Cross-Slope ▪ Improves Drainage, but… ▪ Can negatively impact playability

  21. ▪ Lateral Drainage Improvements ▪ Specially Design Shockpads with Drainage Slots – similar capabilities as flat panel drains ▪ Regrade Field to increase slope ▪ Additional 3” of free -draining stone ▪ Perimeter Drainage Improvements ▪ New Stone trench drain down to perimeter pipe or ▪ Parallel flat drain with direct connections

  22. Additional Capacity For Each Side of Field --Shockpad adds 600 GPM --Drainage Stone adds 1400 GPM Rainfall Events 2016-2018 --Total Additional Capacity: 2000 GPM 3.00 --Current Capacity estimated as 770 GPM 2.50 2.00 Inches of Rain 1.50 1.00 0.50 Next Steps 0.00 --Refine Drainage Calculations (currently conservative) --Confirm Existing Perimeter Piping --Contact Additional Existing Installations

  23. Cost Estimate

  24. Financing

  25. Pre-Ref Schedule

  26. Questions?
