By: Feliciti Fredsti Mentors: Alysha Reinard and Doug Biesecker Goal Terminology Solar Flares Active Regions Sunspots Classifications Compactness Penumbra Zurich Parameters Helicity


  1. By: Feliciti Fredsti Mentors: Alysha Reinard and Doug Biesecker

  2. • Goal • Terminology – Solar Flares – Active Regions Sunspots – Classifications • Compactness – – Penumbra – Zurich • Parameters – Helicity – NHGV – Number of Spots Longitudinal Extent – – Area – Distance • What I Did • Cool plots, Results, and Analysis Conclusion •

  3. My goal is to help improve the way flares are forecasted. – Space weather events can destroy or interrupt important technology, harm astronauts, and misdirect homing pigeons.

  4. http://lwsde.gsfc.nasa.gov/LWS_Space_Weather/SpaceWeatherOverview.html

  5. • A sudden release of energy stored in twisted magnetic fields. • Solar flares are classified according to their x-ray peak wavelength. – X-cl clas ass s flares are big. – M-clas ass s flares are medium-sized. – C-class lass flares es are small. Flare e Class Peak (W/m 2 ) ) Pneumo umonic nic Class between ween 1 and 8 Angst gstroms oms Xtreme X I ≥ 10 -4 Mediocre M 10 -5 ≤ I < 10 -4 Cheesy C 10 -6 ≤ I < 10 -5 Baby B I < 10 -6 http://www.noaanews.noaa.gov/stories2010/20100119_solarflare.html

  6. http://www.swpc.noaa.gov/NOAAscales/

  7. • A part of the solar atmosphere where you can observe: • sunspots • faculae • flares • Active regions are the result of enhanced Magnetic gradient field of magnetic fields. sunspot • Will use interchangeably http://www.aip.de/image_archive/Sun.Sunspots.html with “sunspot.”

  8. • An area seen as a dark spots on the photosphere of the Sun. • Concentrations of magnetic flux. • Appear dark because they are cooler than the surrounding photosphere. • Larger and darker sunspots sometimes are surrounded (completely or partially) by penumbrae. The dark centers are umbrae. • Classification • The Modified Zurich Sunspot Classification System • Devised by McIntosh • White-light characteristics of a sunspot group. • A 3-letter designation: Zpc http://www.astrosociety.org/education/publications/tnl/68/solar.html

  9. • c: • x: a single spot • o: open • i: intermediate • c: compact http://www.petermeadows.com/html/glossary.html

  10. • p: • x: no penumbra • r: rudimentary • s: small (<2.5 degrees north- south diameter), symmetric • a: small, asymmetric • h: large (>2.5 degrees north- south diameter), symmetric • k: large, asymmetric http://www.petermeadows.com/html/glossary.html

  11. • Z: A: – – E: • small single sunspot or elongated • very small group of spots • bipolar sunspot group • same magnetic polarity • penumbra on both ends. no penumbra • • 10° < penumbra – B: longitudinal extent < 15° • bipolar F: – • no penumbra • elongated C: – • bipolar sunspot group • elongated • penumbra on both ends • bipolar sunspot group 15°.< penumbra • • one sunspot must have a longitudinal extent penumbra – H: • penumbra longitudinal • uni-polar sunspot group extent < 5° with penumbra • – D: elongated • • bipolar sunspot group • penumbra on both ends of the group • 5° < Penumbra longitudinal extent < 10° http://solarwww.mtk.nao.ac.jp/en/gallery.html

  12. • Helicity – The amount of twist in the plasma flow below the surface of the Sun. – NOT magnetic helicity – IS hydrodynamic helicity http://www.nordita.org/~branden b/highlights/recent.html http://www.absoluteastronomy.com /topics/Gradient • Normalized Helicity Gradient Variance (NHGV) – A parameter designed to capture the large, shrinking spread of helicity values, the overall range of helicity values, and the depth variation of the helicity.

  13. • Number of Spots • Area of Sunspot Group o A M =sunspot area in millionths of the sun’s visible hemisphere A S = measured sunspot area (square millimeters or o inches) R=radius of solar drawing o B=heliographic latitude of sunspot group (degrees) o L=heliographic longitude of sunspot group (degrees) o L 0 =heliographic longitude of the center of the disk o (degrees) Distance Longitudinal Extent • • Subroutine that I wrote o Co-latitudes (90-latitude) o Degrees to radians o Spherical geometry o Angle times solar radius to get arc o distance between sunspots http://www.ne.jp/asahi/stellar/scenes/moon_e/sun2001.htm

  14. • Pieced together a IDL programs • Wrote an IDL program to – measure distance between two active regions and – restrict the location of the sunspot to the center of the disk to avoid uncertainties • Organized lots of data • Made lots of plots and histograms • Looked for patterns with respect to NHGV values in the plots and histograms

  15. Histog ogram am Comp mpact actne ness ss 180 160 140 ncy ness Frequenc 120 100 No Flares actnes C-class 80 Compac M-class 60 X-class 40 20 0 X O I C Compac actnes ness Class

  16. c, no flare, 0.98 i, no flare, 1.02 c, x-class, 1.24 i, x-class, 1.13

  17. Histog ogram am Penumbr mbra 180 160 140 120 ncy a Frequenc No Flares 100 C-class Penumbra M-class 80 X-class 60 40 20 0 X R S A H K Penumbra a Class

  18. k, no flare, 1.04 h, no flare, 1.08 k, x-class, 1.17 h, x-class, 1.15

  19. Penumbra h, no flare, 1.08 h, x-class, 1.15

  20. Histog ogram am Zurich 120 100 80 h Frequency No Flares C-class 60 Zurich M-class X-class 40 20 0 A B C D E F H Zurich h Class

  21. d, no flare, 1 e, no flare, 1.03 d, x-class, 1.13 e, x-class, 1.2

  22. Compactness Penumbra Zurich Standard Deviation shows how much variation there is from the average. http://www.syque.com/improvemen t/Standard%20Deviation.htm

  23. NHGV 1.20 1.15 1.10 1.05 No 1.00 C 0.95 M X 0.90 0.85 0.80 X C I O X S A H K R A B C D E F H Compac actnes ness Penumbra a Zurich Distance tance 1,000,000 900,000 800,000 700,000 No km km 600,000 C 500,000 M 400,000 X 300,000 200,000 X C I O X S A H K R A B C D E F H Compac actnes ness Penumbra a Zurich

  24. When n Comp mpact actness ess = C, Penumbra mbra class ss % 100% 90% 80% 70% R 60% K 50% H 40% A 30% S 20% 10% X 0% No C M X Flare Class When n Comp mpact actness ess = C, Zurich h class ss% 100% 90% 80% 70% H 60% F 50% E 40% D 30% C 20% B 10% A 0% No C M X Flare Class

  25. When n Penubmbra mbra = K, Comp mpactne ctness ss class ss % 100% 90% 80% 70% 60% O 50% I 40% C 30% X 20% 10% 0% No C M X Flare Class When n Penumbr mbra a = K, Zurich h class s % 100% 90% 80% 70% H 60% F 50% E 40% D 30% C 20% B 10% A 0% No C M X Flare Class

  26. When n Zurich h = E, Comp mpact actne ness ss class ss% 100% 90% 80% 70% 60% O 50% I 40% C 30% X 20% 10% 0% No C M X Flare Class When n Zurich h = E, Penubra a class% s% 100% 90% 80% 70% 60% R 50% K 40% H 30% A 20% S 10% X 0% No C M X Flare class

  27. • The more compact the sunspot group is, the higher the probability of producing an x-class flare. • Asymmetric penumbra sunspots are more likely to flare in the x-class than symmetric penumbra sunspots. • Elongated bipolar sunspot groups with penumbra at both ends are more likely to flare in the x-class than single spots, those without penumbra, and uni-polar sunspots. • Increasing compactness and complexity of a sunspot increases NHGV • Work-in-progress.

  28. • http://ve4xm.caltech.edu/Bellan_plasma_page/laborato.htm 3 Aug. 2010 • http://www.petermeadows.com/html/area.html 3 Aug. 2010 • http://solar-center.stanford.edu/solar-images/magnetograms.html 3 Aug. 2010 • http://spaceweather.com/glossary/filaments.html 3 Aug. 2010 • http://solarmonitor.org/ 3 Aug. 2010 • http://spaceweather.com/glossary/flareclasses.html 2 Aug. 2010 • http://www.swpc.noaa.gov/info/glossary.html 2 Aug. 2010 • http://www.swpc.noaa.gov/info/glossary.html 2 Aug. 2010 http://www.nso.edu/staff/apevtsov/www/gallery.html 2 Aug. 2010 • http://solar.physics.montana.edu/magara/Research/Research_sig.html 2 Aug. 2010 • http://euromet.meteo.fr/resources/ukmeteocal/verification/www/english/msg/ver_categ • _forec_ex/uos3/uos3_ko1.htm 30 July 2010 • http://www.cawcr.gov.au/projects/verification/ 30 July 2010 • Reinard, A., J. Henthorn, R. Komm , and F. Hill. “Evidence that Temporal Changes in Solar Subsurface Helicity Precede Active Region Flaring.” The Astrophysical Journal Letters 20 Feb. 2010: L121-L125. Print.
