Basic Gearbox and Coupling

TORK is the leading manufacturer of Mechanical Power Transmission equipments in China and would be the world

TORK Brief SHANGHAI TORK DRIVE EQUIPMENT CO.,LTD is one of a enterprise who engaging in research, manufacture and sales of R helical gearbox,K helical bevel gearbox,F parallel shaft gearbox ,S helical-worm gearbox,X cycloidal gearbox,H,B high power gearbx and planetary gearbox and customized gearbox.TORK company's production base covers an workshop area of 45000M2 with advanced and complete inspection equipments. the company owns domestic and oversea advanced processing center, all kinds of digital control machines and high precision gear grinding machines; owns whole Gear Error Measure Instrument, Gear Jumpiness Measure Instrument, Gear Worm double Measure Instrument and other advanced instruments. Recently years, TORK company has devoted to research, development and digital design of domestic and oversea transmission equipment, it supplied excellent design scheme for of all kinds of transmission industry. TORK products are widely applied in many fields, such as environment protection, metallurgy, mine, storage logistics, beer, drink, lifting transportation, baccy light industry, solid parking, rubber and plastic and etc. Meanwhile, TORK products also are exported to Europe,America,Asia- southeast,Middle east,Australia.etc and other countries and area .. 2015 - Partners

TORK equipments for gearbox 3D measuring equipment Torque test machine Gear inspection machine Heat treatment machine CNC Hobbing machine NILES Gear grinding machine

TORK workshops

Development of Gear Units Essential smaller surfaces Essential smaller weights Bevel gear reducers with a nominal torque of approx. 23 000 Nm: 1954 to Present

Spur Gearing •Low Load Carrying capability •Parallel offset shafts. •Noise •Usually Open gears •Easy to produce •Usually from Cast Material •Wear & Lubrication problems •Efficiency – less than 95% per stage.

Spur Gearing - Applications

Helical Gearing •Good Load Carrying capability •Parallel offset shafts. •Low Noise •Usually Enclosed gears •Usually from Heat Treatable Material •Good wear resistance. •Efficiency up to 99% per stage. •Axial thrust taken by bearings. •Max Ratio 5 : 1 per stage

Helical Gearing - Applications

Typical design of TORK gear units output shaft 16MnCr 5 or C60 bearing cover housing GG 25 shaft seals gears 20CrNi2MoA antifriction bearings Pinion Shafts 20CrNi2MoA

Double Helical Gearing •Good Load Carrying capability •Parallel offset shafts. •Sometimes fabricated gear •Usually from Heat Treatable Material •Minimizes axial thrust •Difficult to accurately produce. •Efficiency up to 99% per stage. •Max Ratio 5 : 1 per stage

Bevel Gearing •Good Load Carrying capability •Turns the motion thru 90 deg. •Low Noise •Usually Enclosed gears •Usually from Heat Treatable Material •Good wear resistance. •Efficiency up to 98% per stage. •Max. Ratio 5 : 1

Bevel Helical Gearing •Good Load Carrying capability •Turns the motion thru 90 deg. •Low Noise •Usually Enclosed gears •Usually from Heat Treatable Material •Good wear resistance. •Efficiency up to 98% for the bevel and 99% per stage for the helical gears.

Bevel Helical Gearing - Applications

Planetary Gearing •Good Load Carrying capability •Input/output shafts in line. •Ratios of up to 6 : 1 in each stage •Compact size for high torques. •Enclosed gears •Good wear resistance. •Efficiency up to 97% per stage. •Used in combination with other types of gearing particularly for final stage.

Planetary Gearing - Applications

Worm Gearing •Good Load Carrying capability •Input/output shafts at right angles. •Ratios of up to 60 : 1 in each stage •Compact size for high ratios. •Un economic for high torques. •Low Noise. •Efficiency up to 90% per stage. •Used in combination with other types of gearing.

Worm Gearing - Applications

Power Split Gearing •Good Load Carrying capability •Compact size for high torques, since the expensive final gear is driven by 2 or more pinions. •Enclosed gears •Good wear resistance. •Efficiency up to 97% per stage. •Competitive Pricing

Power Split Gearing - Applications Cement Factory – Kiln Drive Sugar Mill – Final Drive

Hydraulic Drives •Variable speed capabilities •Power pack can be located away from the drive. •Suitable for a large variation of torques •Compact size. •Relies on quality of oil. •Lends itself to computer control. •Poor efficiency. Approx.70 to 80%. •Ease of mounting

Hydraulic Drives - Applications Sugar Mill – Pressure Feeder Drives Sugar Mill – Main Drive

Cycloidal Drive • Compact Drive - particularly for high ratios •Ratios up to 87:1 in 1 stage •Not available for high powers •Not available in right-angle design •Requires special excentric bearing •Efficiency up to 92% per stage

Cyclo Drive - Applications

What Ever Your Size, We Have It !

Hydraulic Drives

What is Gear box…? What is the Purpose of Gearbox..?

What are the products of TORK drive R Helical X cycloidal K Helical Bevel F Parallel shaft B Helical bevel H parallel shaft P planetary

Others and customized gearbox

 For Complete Choosing Gearmotor and Specification ,  we will see :  Gear Motor Configurator

H,B high power gearbox basic feature Housing material : Grey cast Iron HT250(GG-20) or Fabricated steel splite housing for all sizes of H1SH& ≥ size13 of other types Housing hardness : HBS 190-240; Gear material : 20GrNi2MoA(18CrNiMo7-6) Alloy steel. Surface hardness of gears : 60-63 HRC Gear core hardness : 33-40 HRC Input / Output shaft material : 42CrMo alloy steel; Input / Output shaft hardness : HRC25-30; Heat treatment : Tempering, Carburizing, Quenching. etc.; : Accuracy of Grinding ≤ DIN6 or ≥ AGMA11 Machining precision of gears Pressur angle :20 ° Helical angle varies between : 10 ° -13 ° Noise : 65 db to 80 db : 35 ° C to 45 ° C Temp. rise Efficiency : 92%~96% (Depends on the transmission stage) ; : 45 ° C Max. Temp. rise (Oil) Bearing : ZWZ---Make, China

H,B type Designations

H Helical gear unit ,Type H2SH

TORK Mechanical drives Indonesia B Helical Bevel gear unit ,Type B3SH

H Helical gear unit ,Type B3SH

TORQUE TORQUE is the most important factor in Mechanical Power Transmission TORQUE has relationship between input POWER,input SPEED,RATIO M2=9550*P1*i/n1 M2=torque(N.m) P1=input power(kw) n1=input speed(rpm) i=gearbox ratio

Absorbed Power vs Rated Power  You can put any size of motor on a drive BUT it will only produce the power required by a machine.  With a S1 motor – it is designed to produce TWICE the RATED POWER when it starts and can maintain that POWER for a period of 2 minutes.  Our Gear units also have this additional safety - Already built in  Motors are also designed to cope with SHOCK LOADS – up to 5 times in any one hour period.  Our Gear units also have this additional safety - Already built in

TORK Mechanical Drives in the Sugar Industry TORQUE REQUIRED/ABSORBED BY MILL  Power required by mill for 4000 TCD with 13.5% Fiber Content = 365.20 kW  Mill Speed required to mill 4000 TCD = 4 rpm  Motor speed 991 rpm(Nominal) = 6 pole  Torque (Nm) = Power (kW) x 9550 / n (rpm)  Torque Nm = 365.20 x 9550 / 4 = 871.915 Nm SERVICE FACTOR (Sf) Therefore the SERVICE FACTOR 2 = 871.915 x 2 = 1.743.830 Nm Therefore the SERVICE FACTOR 1,7 = 871.915 x 1,7 = 1.482.255 Nm (based on AGMA standard)

TORK Mechanical Drives in the Sugar Industry Additional Assurance TORK have additional Taper Roller Bearings to take the THRUST LOADS from the tail bar.  Larger output shaft diameters mean larger bearings.  Input and Output bearings are protected from abrasion by bagase dust by the use of grease filled labyrinth seals.  One of the competitors housing is fabricated steel – flexible and less shock/vibration absorbsion than a casting from GG 25.

TORK Mechanical Drives in the Sugar Industry Thrust Bearings and Solid Square Output Shaft (Safety & Protected)

Testing and Warranty  Each TORK gearbox will be commissioning for 4 hours after assembly, make sure no noise and every parts work well during these time.  Each TORK product is guaranteed against defects in design, manufacturing, material and labor during 12 months, counted from starting date, or 18 months counted from the date of shipment, whichever comes earlier.  If product has quality problem within guarantee .TORK promising to offer repair parts, technical supports or change product at charge free.
