March 2, 2014 Monte Jade's RFID Seminar Atlanta, USA
1. TSA worldwide RFID Trial History 2. ASTREC research effort in RFID 3. Inflight RFID 4. Current Airport RFID Deployments 5. Atlanta International Airport Activity with IATA RFID Committee 6. Full self-services check-in with automated bag drop process
TSA worldwide RFID Trial History During the 1999 - 2006, a number of trials have been conducted between airports, airlines and manufacturers. The main results are summarized in the following table.
TSA worldwide RFID Trial History
TSA worldwide RFID Trial History
TSA worldwide RFID Trial History RFID Inlay Inserted into current paper baggage tag stock used by ANA Very thin, flexible read/write passive inlay containing antenna circuit and a silicon chip where data is stored 256 bits of available memory
ASTREC Research Effort in RFID ASTREC stands for "Advanced Airport Systems Technology Research Consortium" The purpose of ASTREC is to promote the use of RFID technology in an airport environ- -ment and establish a technology base for the advanced airport system such as baggage handling, in a further diverse and advanced information-based society
ASTREC Research Effort in RFID
ASTREC Research Effort in RFID
ASTREC Research Effort in RFID
ASTREC Research Effort in RFID
What is Inflight RFID RFID Inflight services included 1. Catering Equipment: All rotatable equipment used for catering including trolleys, boxes, ovens, etc 2. Trolley: Container on wheels (trolley, cart, etc.) 3. Box: Container carried by hand (carrier, canister, stowage unit, etc.) FAA AC 20-162 on board RFID standard (Inflight) UHF RFID reader
Inflight RFID Why Inflight RFID Main challenges the Airline facing today 1. Airline do not know precisely how many trolleys and boxes they actually have and where 2. Airline still receive catering equipment inventory counts by fax from kitchens 3. Study show when trolleys and boxes go missing that usually are a. Privately used by stakeholder b. Re-used by another airline with identity change c. Even sold on e-Bay 4. IATA estimates a total of 900,000 trolleys and 1,800,000 boxes at Industry level representing an investment of around US $ 1 billion
Inflight RFID Inflight RFID Technology Selection IATA has performed in 2007 various tests on several RFID technologies: UHF, LF and HF. The UHF passive solution has shown the best performances, particularly with the RFID tag directly mounted on the trolley metal with a read at more than 2 meters of distance. The trolley can be also moved rapidly. A draft Recommended Practice has been produced by the end of 2007 Use of an RFID Tag (UHF passive, 96 bits Class1-gen2). This Recommended Practice is reviewed with airlines and caterers at the end of 2008.
Inflight RFID Technology Trail (UHF) RFID tags already mounted on 1,100 trolleys 1. Washing / Drying at max 80 degrees Celsius Warm tags immediately after leaving the washing machine (80 degrees) Cold tags 30 minutes after washing (20 degrees) 2. Trolley was put in a freezer for at least a half hour at minus 18 degrees Celsius This was repeated 5 times in the morning, 5 times in the afternoon, for 2 days. (5+5)x2=20 times. RFID Class-1 Gen 2 tags mounted on trolleys
Inflight RFID Technology Trail (UHF) Siemens Inflight RFID Reader & Antennas
Current Airport RFID Deployments In 2007, A&D China, Siemens and SLC China IL engineers discussed and researched for a RFID solution for the Wuhan Tianhe Airport BHS. In the end, the conclusion was to design to a RFID tunnel, using hardware and software from Siemens A&D (Siemens Automation and Drives ). Requirements RFID Read Rate: Minimum successful read rate: 98% Conveyor Speed: Up to 3m/s speed of RFID conveyor, RFID reading without stop of conveyor RFID Reader: Interface: 10/100BaseT Ethernet or IEEE 802.11g RFID frequency: between 850Mhz and 950Mhz Supported standard: ISO-15691; ISO-18000-6-C; ISO-15692 Reusable RFID Tag: Wuhan Airport implements an island solution, the tag cannot be read at other airports additional barcode label must be use Re-usable RFID tag saves approx. 250,000 USD per year
Current Airport RFID Deployments
Current Airport RFID Deployments
Current Airport RFID Deployments
Atlanta International Airport Activity with IATA RFID Committee HJAIA 2009 activity with IATA RFID Committee In 2009 IATA form a task team with-in 1740c Baggage Work Group to start a Global RFID Baggage Tag Purchasing Project that hope to consolidate most of global RFID Bag tag purchase and provide aviation industry the maximum price guaranty. Project approach and methodologies are: Phase 1 – Define the technical benchmark Phase 2 – Global supplies selection process
Atlanta International Airport Activity with IATA RFID Committee Baggage tags tested Label Converter Inlay Manufacturer Model # Phase I Bartsch Smartrac SMT L-155 George Schmitt Alien Technology ALN-9640 George Schmitt Avery Dennison AD-833 George Schmitt IER FF95-8 George Schmitt UPM Raflatac Short dipole IER IER FF95-8 Print-O-Tape Avery Dennison AD-833 Print-O-Tape UPM Raflatac Short dipole Security Label Alien Technology ALN-9640 Security Label Avery Dennison AD-833
Atlanta International Airport Activity with IATA RFID Committee
Atlanta International Airport Activity with IATA RFID Committee
Atlanta International Airport Activity with IATA RFID Committee Interrogation Tag under Reader test Test distance 1,3,5,7 and 17 feet Distance Testing
Atlanta International Airport Activity with IATA RFID Committee After summarizing test data for Phase I and II we can conclude the following: Alien ALN-9640, Avery AD-833 and UPM Short Dipole are the top performers IER FF95-8 and Smartrac SMT L-155 exhibited lower overall performance The IER FF95-8 showed some inconsistency in Phase 1 testing
Atlanta International Airport Activity with IATA RFID Committee IATA Global RFID Vendor Evaluation George Schmitt Print-o-Tape Security Label IER
Atlanta International Airport Activity with IATA RFID Committee INLAY CHIP VENDOR No from from from from from from > 50,000,000 QUALITY purchasing 1,000,000 to 5,000,000 to 10,000,000 to 20,000,000 to 30,000,000 to 40,000,000 to volume 5,000,000 10,000,000 20,000,000 30,000,000 40,000,000 50,000,000 commitment UPM Short Dipole Monza 3 - 96 bits Print-o-tape 4.0000 0.1480 0.1380 0.1290 0.1280 0.1270 0.1245 0.1204 Pass UPM Short Dipole Monza 3 - 96 bits Security Label 0.1470 0.1435 0.1393 0.1358 Pass UPM Short Dipole NXP 512 bits Print-o-tape 4.0000 0.1658 0.1558 0.1468 0.1458 0.1448 0.1423 0.1382 Pass UPM Short Dipole Monza 3 - 96 bits George Schmitt 0.1725 0.1553 0.1553 0.1552 0.1552 0.1552 0.1552 Pass AD-833 Monza 3 - 96 bits Print-o-tape 4.0000 0.1580 0.1480 0.1390 0.1380 0.1370 0.1365 0.1299 Pass AD-833 96 bits George Schmitt 0.1892 0.1888 0.1887 0.1823 0.1760 0.1760 0.1760 Pass ALN-9640 Higgs 3 - 96 bits IER 0.1650 0.1650 0.1500 0.1380 0.1280 0.1260 0.1260 0.1260 Pass ALN-9640 Higgs 3 - 96 bits George Schmitt 0.1591 0.1588 0.1587 0.1587 0.1587 0.1587 0.1587 Pass IER FFL95 NXP IER 0.1580 0.1580 0.1430 0.1330 0.1230 0.1200 0.1200 0.1200 Disqualified
Atlanta International Airport Activity with IATA RFID Committee
Atlanta International Airport Activity with IATA RFID Committee IATA RFP winners are: George Schmitt Print-o-Tape IER
Atlanta International Airport Activity with IATA RFID Committee IATA 1740c Standard Rewrite Work Group Atlanta International Airport Las Vegas International Airport Amsterdam Schiphol International Airport International Air Transport Association (IATA) Air Transport Association of America, Inc. (ATA) Transportation Security Administration (TSA) AIRFRANCE / KLM George Schmitt Avery Dennison Lyngsoe systems Vanguard ID Systems
Full self-services check-in with automated bag drop process
Full self-services check-in with automated bag drop process
Full self-services check-in with automated bag drop process
Q & A
