Arabian Sea Tropical Cyclones, 1881-2014: A spatio-temporal analysis in support of natural hazard risk appraisal in Oman Suad Al-Manji

Introduction • Tropical cyclones and storms coming from the Arabian Sea are common in Oman (Evan and Camargo, 2011a; Byju and Kumar, 2011). • In the Arabian Sea region, the majority of tropical cyclones form near the Laccadive Islands (~11 ° N, 73 ° E) in two seasons: the pre-monsoon and the post- monsoon (Galvin 2008a).

Introduction • Guno (2007), Cyclone Guno, the first super cyclone (category 5) recorded in the Arabian Sea in a century (Evan and Camargo, 2011a). • The most intense recent events to impact Oman were in the 2015 North Indian Ocean season (Ashobaa and the extreme cyclonic storms Chapala and Megh), 2018 (Sagar and Mekunu).

Introduction • The study presents a spatiotemporal analysis of cyclones tracks in the Arabian Sea region, drawing on observations from 1880 – 2014. • The analysis aims to identify high-frequency seasons, the cyclone direction in each season, and the linear direction trend. • The results are intended for use in identifying the more exposed areas around the Arabian Sea and particularly in Oman, and to support disaster risk appraisal and management.

Data and Methods • A spatial (GIS) database of tropical cyclones was created based on tracks obtained from the Indian Metrological Department Atlas for the period 1881-1999 (IMD, 1979; IMD 1999 ) and the IMD e-Atlas for storm and depression tracks over the North Indian Ocean for 1891-2014 (IMD, 2014). • The tracks show tropical system intensity (category) with data organised based on the temporal (seasonal and monthly) distribution of cyclone tracks and their point of origin. • Tracks that made landfall in Oman were extracted from the total tracks for dedicated analysis

• Two methods were used in the spatio-temporal analysis. • KDE , LDM • The KDE and LDM analyses thus show the location- frequency (density) of the Arabian Sea tropical cyclones (1881-2014) and their mean tracks, and how these factors vary over time, by cyclone intensity, and in particular for those cyclones which pose the greatest risk to Oman, those making landfall.

Arabian Sea tropical cyclones frequency Table 1 . Distribution of tropical systems in the Arabian Sea, 1881-2014 Landfall country Frequency % India 61 27.4 Oman 41 18.4 Pakistan 10 4.5 Somalia 6 2.7 Yemen (Socotra islands) 5 2.2 Terminates at Sea 99 44.4 Arabian Sea 93 41.7 Gulf of Aden 6 2.7 Total 222 100

Table 2. Monthly distribution of tropical events making landfall in Oman, 1881-2014 Total June May Mar Aug Nov Apr Jan Feb Sep Dec Oct Jul % 1880-1894 0 0 0 0 1 2 0 0 0 0 0 0 3 7 1895-1909 0 0 0 0 2 1 0 0 0 1 0 0 4 10 1910-1924 0 0 0 0 3 0 0 0 0 1 0 0 4 10 1925-1939 0 0 0 0 1 0 0 0 1 0 0 0 2 5 1940-1954 0 0 0 0 0 1 0 0 1 1 0 0 3 7 1955-1969 0 0 0 0 3 0 1 0 1 2 1 1 9 21 1970-1984 0 0 0 0 1 2 1 2 1 0 0 1 8 19 1985-1999 0 0 0 0 0 1 0 0 1 1 0 1 4 10 2000-2014 0 0 0 0 2 2 0 0 0 1 0 0 5 12 Total 0 0 0 0 13 9 2 2 5 7 1 3 42 100 % 0 0 0 0 31 21 5 5 12 17 2 7 100

25 20 15 10 5 0 1880-1894 1895-1909 1910-1924 1925-1939 1940-1954 1955-1969 1970-1984 1985-1999 2000-2014

Arabian Sea storm track Arabian Sea tracks classification. analysis Monthly distribution of Arabian Sea cyclone tracks, 1881-2014: (a) pre-monsoon, (b) post-monsoon, (c) pre-monsoon (with landfall in Oman) (d) post-monsoon (with landfall in Oman).

Spatio-temporal distribution of Arabian Sea storm Arabian Sea cyclone tracks track analysis KDE of Arabian Sea tracks 1881-2014: (a) all, (b) all pre-monsoon, (c) all post-monsoon, (d) all those making landfall in Oman, (e) pre-monsoon making Oman landfall, (f) post- monsoon making Oman landfall.

Spatio-temporal distribution of Arabian Sea storm Arabian Sea cyclone tracks track analysis KDE of Arabian Sea tracks 1881-2014: (a) all-May, (b) all-June, (c) all-Oct, (d) all-Nov, (e) all those making landfall in Oman in May, (f) making Oman landfall in June, (g) making Oman landfall in Oct, (h) making Oman landfall in Sept.

Spatio-temporal distribution of Arabian Sea storm track analysis Arabian Sea cyclone tracks Linear direction mean (LDM) of Arabian Sea cyclone tracks: (a) all tracks, (b) tracks making landfall in Oman, and (c) tracks making landfall in Oman by pre- and post- monsoon month.

Average sea surface temperature Arabian Sea storm track (ºC) of the Arabian Sea, 1880-2014 analysis Average sea surface temperature (ºC) of the Arabian Sea, 1880-2014

Discussion and conclusions • The analysis shows how cyclone tracks vary seasonally and by pre and post-monsoon month. • Cyclones tend to travel to the north of the Arabian Sea, revealed by the high density all tracks KDE in the northeast Arabian Sea and the LDM analysis that shows cyclones travel to the northwest.

• In the pre-monsoon, a high density of tracks is found in the northeast Arabian Sea, and the LDM moves to the north; in the post-monsoon, a high density of tracks occurs in the southeast Arabian Sea, with the LDM moving to the west.

• Turning to the cyclones that made landfall in Oman, we find that in the pre-monsoon, cyclones tend to originate in the south of the region in May and move northward in June. • tropical storm Ashobaa developed in June 2015 strike Oman in the northern region near Ras-Al Had. • tropical cyclone Chapala and tropical cyclone Megh that formed in the Arabian Sea in November 2015 both took a direction to the southwest Arabian Sea toward Yemen’s Socotra islands 240 km off the Horn of Africa

• These results reveal a series of general and broadly predictable spatio-temporal patterns. • the general patterns are useful in informing natural hazard risk assessment and management in the region, including Oman which has suffered extensive damage in the past due to tropical cyclones.

• The results could, for example, assist with more targeted cyclone preparation and deployment of emergency response resources, based upon areas most at risk to cyclones overall (strategic planning), and to specific storm events when these are first identified (tactical planning). For example, knowing that cyclones that develop in June are more likely to make landfall in the northern part of Oman is valuable emergency planning intelligence.

References • Al-Habsi, M., Gunawardhana, L. and Al-Rawas, G. (2015) Trend Analysis of Climate Variability in Salalah, Oman', International Journal of Students Research in Technology and Management, 2(5), 168-171. • Al-Qurashi, A., McIntyre, N., Wheater, H., & Unkrich, C. (2008). Application of the Kineros2 rainfall – runoff model to an arid catchment in Oman. Journal of Hydrology, 355(1-4), 91-105. ‏ • Byju, P., & Kumar, S. P. (2011). Physical and biological response of the Arabian Sea to tropical cyclone Phyan and its implications. Marine environmental research, 71(5), 325-330. ‏ • Evan, A. T., & Camargo, S. J. (2011a). A climatology of Arabian Sea cyclonic storms. Journal of Climate, 24(1), 140-158. • Evan, A. T., Kossin, J. P., & Ramanathan, V. (2011b). Arabian Sea tropical cyclones intensified by emissions of black carbon and other aerosols. Nature, 479(7371), 94. ‏ • Galvin, J. (2008a) The weather and climate of the tropics: Part 7 – Tropical revolving storms, Weather, 63(11), 327-333. • Galvin, J. (2008b) The weather and climate of the tropics: Part 6 – Monsoons, Weather, 63(5), 129-137. • IMD (1979) Tracks of storms and depressions in the Bay of Bengal and the Arabian Sea 1877- 1970, http://www.imdchennai.gov.in/cyclone_eatlas.htm [accessed June 2014].

• IMD (1999) Tracks of storms and depressions in the Bay of Bengal and the Arabian Sea 1971- 1995, http://www.imdchennai.gov.in/cyclone_eatlas.htm. [Accessed June 2014]. • IMD (2014) Tracks of storms and depressions in the Bay of Bengal and the Arabian Sea 1971- 1995,http://www.imdchennai.gov.in/cyclone_eatlas.htm. [Accessed June 2014]. • Membery, D. (1998) Famous for 15 minutes: An investigation into the causes and effects of the tropical storm that struck southern Arabia in June 1996, Weather, 53(4), 102-110. • Membery, D. (2001) Monsoon tropical cyclones: Part 1, Weather, 56(12), 431-438. • Membery, D. (2002) Monsoon tropical cyclones: Part 2, Weather, 57(7), 246-255. • Mitchell, A. (2005) The Esri guide to GIS analysis, volume 2: Spatial measurements and statistics, 1st edn. Redlands, CA: Esri Press. • Momani, N. M., & Fadil, A. S. (2010). Changing public policy due to Saudi City of Jeddah flood disaster. Journal of Social Sciences, 6(3), 424-428. ‏ • Murakami, H., Vecchi, G. A., & Underwood, S. (2017). Increasing frequency of extremely severe cyclonic storms over the Arabian Sea. Nature Climate Change, 7(12), 885. ‏ • Qasim, S. (1982) Oceanography of the northern Arabian Sea, Deep Sea Research Part A. Oceanographic Research Papers, 29(9), 1041-1068. • Shetye, S., Gouveia, A. and Shenoi, S. (1994) Circulation and water masses of the Arabian Sea, Proc. Indian Acad. Sci.(Earth Planet. Sci.), 103(2), 107-123. • Thadathil, P. and Gosh, A. K. (1992) Surface layer temperature inversion in the Arabian Sea during winter, Journal of Oceanography, 48(3), 293-304.
