Aqua-Culture A demonstration of the ubiquitous role of water as - PowerPoint PPT Presentation

Aqua-Culture A demonstration of the ubiquitous role of water as both a productive and destructive force Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet) Goals Resiliency and Stormwater Management Soften shoreline


  1. Aqua-Culture

  2. A demonstration of the ubiquitous role of water as both a productive and destructive force

  3. Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet)

  4. Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet) Attenuate wave action (at height of 5 feet above high tide)

  5. Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet) Attenuate wave action (at height of 5 feet above high tide) Improve stormwater management (capture 364,502.425 gals water)

  6. Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet) Attenuate wave action (at height of 5 feet above high tide) Improve stormwater management (capture 364,502.425 gals water) Improve water quality (1 acre of oyster reef and 1 acre of seaweed)

  7. Goals Resiliency and Stormwater Management Soften shoreline (4,955 feet) Attenuate wave action (at height of 5 feet above high tide) Improve stormwater management (capture 364,502.425 gals water) Improve water quality (1 acre of oyster reef and 1 acre of seaweed) Protect against inundation (with berm 25 feet high)

  8. Goals Education and Recreational Resources Honor existing user experience

  9. Goals Education and Recreational Resources Honor existing user experience Engage a wider demographic

  10. Goals Education and Recreational Resources Honor existing user experience Engage a wider demographic Retain active industrial uses

  11. Goals Education and Recreational Resources Honor existing user experience Engage a wider demographic Retain active industrial uses Highlight past and present and future uses

  12. Goals Education and Recreational Resources Honor existing user experience Engage a wider demographic Retain active industrial uses Highlight past and present and future uses Use habitat restoration as a vehicle for education

  13. New York/New Jersey Harbor Estuary & Neighborhood Context Aquaculture Site Photo Credit: US Army Corps of Engineers

  14. Capture

  15. Filter

  16. Resilience

  17. Production

  18. Access?

  19. Floating Wetlands Berm

  20. Photo Credits Left to right: 1.http://www.earthtimes.org/energy/seaweed-sustainable-biofuel/1771/ 2.https://www.dnrm.qld.gov.au/mining/safety-and-health/alerts-bulletins-search- tool/alerts-bulletins-search/alerts-bulletins/mines-safety/trucks-tipping-over-the-edge?SQ_DESIGN_NAME=print-fact-sheet 3. http://c8.alamy.com/comp/AB7MK4/cape-cod-sand- dunes-massuchusetts-usa-united-states-beaches-beach-AB7MK4.jpg 4.https://www.dnrm.qld.gov.au/mining/safety-and-health/alerts-bulletins-search-tool/alerts-bulletins-search/alerts- bulletins/mines-safety/trucks-tipping-over-the-edge?SQ_DESIGN_NAME=print-fact-sheet 5.http://www.clemson. edu/extension/horticulture/nursery/remediation_technology/floating_wetlands/float_type.html 6. http://www.bayrestoration.org/wp-content/uploads/2014/12/oyster-reef.jpg

  21. Oyster Reef One adult oyster can filter 20-50 gallons of water a day. Ranges for a healthy oyster reef are between 400-1000 oysters per square meter. At 400 oysters per square meter our acre of oyster reef will filter 32,376,000-80,940,000 gallons of water a day.

  22. Seaweed Farm ◦ Creates habitat for marine life ◦ Filters water (nitrogen and phosphorus mainly) ◦ Acts as a carbon sink (helps counteract ocean acidification) ◦ Serves as an educational resource for visitors ◦ Fast growing resource: Can grow 9-12 feet in 3 months (about 18% per day) ◦ Nutritious to eat and great for compost (some tastes like bacon!) Photo Credit: greehttp://www.earthtimes.org/energy/seaweed-sustainable- Photo Credit: tainable-biofuel/1771/nwave.org biofuel/1771/nwave.org

  23. Photo Credits: Left to Right: 1. http://www.apartmenttherapy.com/green-inspiration-giant-rain-b-148724 2. http://brooklynbrewery.com/blog/dinner-party/dinner-party-prep-get-to-know-brooklyn-grange/ 3. http://www. roofingmagazine.com/green-blue-making-roof-systems-sustainable-urban-environments/ 4. http://graham. umich.edu/media/images/bioswales2.jpg

  24. Existing Infrastructure

  25. Existing Stormwater Flow Total Site Area = 556,150 Sq/Ft 1.2 in rainfall= 414,331 gal on site 3 in rainfall = 1,052,591 gal on site

  26. Proposed Interventions

  27. Stormwater with Interventions 3 in rainfall = 23,840 gal captured by 3 in rainfall = 148,550 gal captured secondary blue roof by blue roof 1.2 in rainfall = 9,536 gal captured by 1.2 in rainfall = 51,419 gal captured secondary blue roof by blue roof Green roof: 156,730 gal capacity

  28. Area Draining into Swales (not captured by roof systems): 350,580 Sq/Ft Gallons Draining towards Swales: 1.2” Rain Event: 261,182 Gallons 3” Rain Event: 652,955.25 Gallons Swale Retention Space: 350,580 Sq/Ft Swale Retention Capacity: 55,383 Gallons During 1.2” Rain Event: Swales can retain about 20% During a 3” Rain Event: Swales can retain about 8%

  29. Photo Credits Left to right: 1. http://www.thecourier.com.au/story/2882820/tree-dying-after-being- poisoned/ 2. http://www.militarytownadvisor.com/blog/2014/1/27/148/five-free-kid-friendly-activities-near- naval-base-kitsap/ 3. http://1.bp.blogspot.com/- DKXgNKBzfNk/Tex0hGRACbI/AAAAAAAAAAM/ogXppizGoag/s1600/036.JPG 4. http://www.fondriest. com/environmental/water-quality/test-kits.htm 5. http://www.newtowncreekalliance.org/living-dock/ 6. http: //www.randyspierandseawall.com/services.html

  30. Field Station: Detail Water Testing and Observation Log Stations Fish Cleaning Stations

  31. Field Station: Detail Water Testing and Observation Log Stations Fish Cleaning Stations Interactive Signs that draw the eye out…

  32. Field Station: Detail Water Testing and Observation Log Stations Fish Cleaning Stations Interactive Signs that draw the eye out… And down

  33. Thank you
