Anthropometry Anthropometry - anthropo- man - -metria measuring Anthropometry: measurement and use of human dimensions 2 Concepts Populations (of individuals from whom data is obtained / for whom it is

  1. Anthropometry

  2. Anthropometry ἀνθρωπο- anthropo- man -μετρία -metria measuring Anthropometry: measurement and use of human dimensions 2

  3. Concepts Populations (of individuals from whom data is obtained / for whom ● it is intended) General – By age – By gender – By occupation – By other criteria – Samples ● Stratified – Random – Exhaustive/complete – Anthropometric Data ● Data Tabulation ● – Percentile – Distribution Parameters – Exhaustive Lists 3

  4. Stature, Male Source: Penn State Open Design Lab ANSUR online calculator for the1988 Anthropometric Survey of US Army Personnel, 4 http://www.openlab.psu.edu/tools/calculators/AnsurDimensionSelect.php

  5. Stature, Male Percentile 1 2.5 5 10 25 50 75 90 95 97.5 99 mm 1609 1627 1649 1671 1710 1756 1801 1843 1868 1884 1909 in 63.3 64.1 64.9 65.8 67.3 69.1 70.9 72.6 73.5 74.2 75.2 Source: Penn State Open Design Lab ANSUR online calculator for the1988 Anthropometric Survey of US Army Personnel, 5 http://www.openlab.psu.edu/tools/calculators/AnsurDimensionSelect.php

  6. Body Dimensions ● Static (Structural) – Body at rest ● Dynamic (Functional) – Body moving 6

  7. Human Dimensions (1) 7

  8. Human Dimensions (2) 8

  9. Human Dimensions (3) 9

  10. Human Dimensions (4) 10

  11. Text Anthropometric Data 11

  12. Sanders & McCormick Anthropometric Data 12

  13. Penn State Open Design Lab ANSUR online calculator for the1988 Anthropometric Survey of US Army Personnel http://www.openlab.psu.edu/tools/calculators/AnsurDimensionSelect.php 13

  14. University of Michigan Anthropometric Data Website http://mreed.umtri.umich.edu/mreed/downloads.html 14

  15. Other Static Dimensions ● Chest Depth ● Head Length ● Interpupillary Distance ● Eye Height ● Hand Thickness ● Hand Length ● Foot Breadth 15

  16. Dynamic Dimensions: Types of Movement ● Flexion - Bending ● Extension - Extending, straightening ● Adduction - Movement toward midline ● Abduction - Movement away from midline ● Lateral rotation - Rotation outward ● Medial rotation - Rotation inward ● Pronation - Rotation downward ● Supination - Rotation upward 16

  17. Right Hand Grasping Reach Envelope (1) 17

  18. Right Hand Grasping Reach Envelope (2) 18

  19. 19

  20. Other Dynamic/Functional Dimensions ● Prone length, height ● Squatting height ● Overhead reach ● Thumb-tip reach ● Standing forward reach ● Standing lateral reach 20

  21. Right Hand Static Force 21

  22. 22

  23. Other Muscle Power Data ● Prone position data ● Thumb / finger ● Leg, foot ● etc 23

  24. Use of Anthropometric Data ● Determine relevant dimension / parameter ● Define user population ● Select range of users to be accommodated/excluded ● Extract data from appropriate source ● Apply correction factors (for clothing, personal equipment) ● Apply dimension to design 24

  25. Designing for Clearance (Let the large person fit.) Design for the Large Person Design for the Large Person 25

  26. Designing for Reach (Let the small person reach.) Design for the Small Person 26

  27. Design for Adjustability (Let them both fit and reach.) ● Adjust – Work place – Worker position – Workpiece – Tool (e.g., adjustable handles) 27

  28. Other Design Design for the Average Person 28

  29. Design Principles ● Design for the large person (clearance) ● Design for the small person (reach) ● Design for the average person (other) ● Designing for adjustability 29

  30. Cockpit Dimensions Derivable From Anthropometric Data (Woodson et al, 1992) 30
