Analog to Digital Conversion and Pulse Width Modulation ECE Senior - PowerPoint PPT Presentation

Analog to Digital Conversion and Pulse Width Modulation ECE Senior Design 28 February 2017 Analog to Digital Conversion 2 n -1 111 = 110 2 101 10-bit Conversion and V ref = 5V Digital Value 100 011 5 5


  1. Analog to Digital Conversion and Pulse Width Modulation ECE Senior Design 28 February 2017

  2. Analog to Digital Conversion 2 n -1 111 𝑀𝑇𝑐 = πΊπ‘‡π‘Š 110 2 π‘œ 101 10-bit Conversion and V ref = 5V Digital Value 100 011 5 5 010 𝑀𝑇𝑐 = 2 10 = 1024 = 4.9π‘›π‘Š/𝑐𝑗𝑒 001 000 0 V DD /2 n V DD Analog Voltage

  3. PIC 16F18324 A/D Converter β€’ 10-bit Converter β€’ 11 External Channels Available β€’ External V REF+ and V REF- Available β€’ Auto Conversion Trigger

  4. 10-bit A/D Result Format

  5. ADC Clock Selection 5𝑣𝑇

  6. ANSELA: PORTA Analog Select

  7. ADCON0

  8. ADCON1

  9. Pulse Width Modulation (PWM) 1 Cycle 50% Vdd Voltage Effective Voltage 50% Duty Cycle Voltage = Vdd*0.50 0 Time

  10. PWM 20% Duty Cycle 1 Cycle 20% Vdd Voltage Effective Voltage 20% Duty Cycle Voltage = Vdd*0.20 0 Time

  11. PWM 80% Duty Cycle 1 Cycle 80% Vdd Effective Voltage 80% Duty Cycle Voltage Voltage = Vdd*0.80 0 Time

  12. PWM Sine Generation

  13. CCP & PWM β€’ 2 CCP Modules β€’ 2 PWM Modules β€’ Timer 2 Sets Freq

  14. Dedicated PWM Module PWM Output on PPS Registers: β€’ TMR2 β€’ PR2 β€’ PWMxCON β€’ PWMxDCH β€’ PWMxDCL

  15. PWMxCON

  16. T2CON

  17. Peripheral Pin Select Inputs: Outputs: Each Peripheral Has A PPS Register Each I/O Pin Has A PPS Register XXX – Specifies the Peripheral Rxy – Specifies the Pin

  18. RxyPPS Output Select
