Agenda  Overview of Mobile Industrial Robots  Future Steps for Mobile Industrial Robots  Products  Safety & Certifications  Case Studies  Questions and Comments

Overview  MIR is a leading manufacturer of collaborative mobile robots  MiR develops, manufactures and sells mobile robots for the professional market  The purpose of the MiR robots is to automate in-house transportation  The present markets are:  Industry  Healthcare

Market Demands Flexibility User-friendly Price & ROI Ownership (saves on Quality external and expensive support)

The History of MiR  First construction idea was made of LEGO bricks start 2011.  The ”Alfa-version” was developed by the founder and co-owner Niels Jul Jacobsen in April 2012.  Mobile Industrial Robots was established in May 2013  Thomas Visti entered the company as co-owner and holds the position as CEO from October 2014.

The Company Today  We have installed robots in the manufacturing industry and healthcare sector.  We have established partners all over the world.  75 employees – 25 recruited in 2018.  Winner of several international awards.  Selected “Successful Robotics Startup” case by the Business Innovation Observatory – part of the European Commission.

Born Global Odense Dortmund New York Barcelona San Diego Shanghai Singapore 2015 - Odense 2016 - New York 2017 - Shanghai, Dortmund, Barcelona, Singapore 2018 - San Diego

Distributors 126 distributors in 39 countries

References

Future Steps for Mobile Industrial Robots

Growth 2015-2018 (K) Turnover EUR (K) € 30.000 27.000 € 25.000 € 20.000 € 15.000 10.000 € 10.000 € 5.000 3.400 670 € - 2015 2016 2017 2018

Products

Tech Specs  Payload: 100 kg – 220 lbs.  Towing capacity (with MiRHook 200): 300 kg – 660 lbs.  Precision: +/-50 mm - +/- 2” of position +/- 10 mm - +/- 0.4” to docking marker  Max speed forwards: 1.5 m/s – 5.4 ft./s  Max speed backwards: 0.3 m/s – 1 ft/s  Battery run time: 10 hours or 20 km – 12.5 mi  Weight: 62.5 kg – 138 lbs.  Battery charging: 0-80%: 2 hours  Communication: Wi-Fi, Bluetooth, Ethernet and PLC  Safety: Complies with EN1525 safety regulations, SICK safety lasers, PLd cat. 3  CE certified: Yes

Tech Specs  Payload: 200 kg – 440 lbs.  Towing capacity (with MiRHook 200): 500 kg – 1102 lbs.  Precision: +/-50 mm - +/- 2” from reference point +/- 10 mm - +/- 0.4” to docking marker  Max speed forwards: 1.1 m/s – 3.6 ft./s  Max speed backwards: 0.3 m/s – 1ft/s  Battery run time: 10 hours or 15 km – 12.5 mi  Weight: 62.5 kg – 138 lbs.  Battery charging: 0-80%: 2 hours  Communication: Wi-Fi, Bluetooth, Ethernet and PLC  Safety: Complies with EN1525 safety regulations, SICK safety lasers, PLd cat. 3  ESD approved: Yes  CE certified: Yes  Clean Room certified: Yes

 Includes a VL Marker for accurate docking  Laser guided into position

 Automated in-house transport solutions  Automatic pick-up and drop-off of carts  Towing Capacity of MiRHook 100: 300 kg – 661 lbs.  Towing Capacity of MiRHook 200: 500 kg – 1100 lbs .

 Fleet Management for optimized robot traffic  Handles up to 100 robots  Automatic prioritization and selection of the robot best suited for a job, based on position and availability  Planning of the use of different top modules  Text message or e-mail notifications if obstacles prevent the robots from completing planned jobs

Benefits of MiR Robots Collaborative and Autonomous; Increase productivity: Can work 24/7 Maneuver safely around people and and finds the fastest route to the obstacles, even in very dynamic destination environments Support changing business needs: Redeploy workers from pushing a Redeploy easily to different processes cart to higher-value activities or facility layouts Fast ROI: Do not require any Very user-friendly: Easy to control via a expensive installation and pay simple robot interface that requires no themselves off in less than a year prior programming experience Fast and simple implementation: It Extremely flexible: Can be redeployed only takes about a day before the for different tasks with various top robots are up and running modules

AMR vs. AGV AMR – Autonomous (collaborative) Mobile Robot AGV – Automated Guided Vehicle AMR MR AGV GV Trackless, autonomous navigation Requires ”tracks” – e.g. magnetic stripes in the floor or wires Travels safely around people and obstacles Stops at any obstacle without possibility to change route Easy to expand/change work area Expensive and time consuming to expand/change work area Navigates dynamically using a map, allowing it to plan it’s own path Restricted to fixed routes

An Open Interface Customize your own top module Conveyor bands Shelf lift A World of Opportunities ERP Integration Robot arms Hook for towing carts Safety units Your solution Click on the icons for application videos

MiR Academy Free online training tool for distributors and end-users. Divided in different modules that takes maximum 20 minutes each to complete Link for MiR Academy: https://mir.talentlms.com/index Enables distributors and end-users to have the ownership of the robots

Safety & Certifications

Safety and Navigation MiR Safety System  Two laser scanners ensure 360° visual projection around the robot – 8 meters ahead  The lasers scanners are Category Three, Perfomance Level D safety systems Extra navigation  3D Camera detect obstacles 2 meters ahead 1.8 m and from 5 cm to 80 cm up  Top camera detects obstacles up to 1.40 meters height.  3D Camera enables a smooth navigation, 0.8 m where the robot is able to navigate around obstacles without stopping 2 m

Sensory Input Accelerometer and Gyroscope 4 Ultrasonic Sensors Dual Channel Encoders on each Wheel  Speed measurement  Feedback to laser scanners Planning Algorithm 3D Camera 2 SICK S300 Scanners  Enables navigation around obstacles  360 ° visual protection around the robot

Mechanical and Technical Components Light: Sound: Customized lighting colors and patterns Used for communicating actions to people  Beep  Horn  MP3/WAV files

CE Certified Signed Declaration of Conformity (CE Certification) delivered with each robot

ESD Certified MiR200 is ESD certified

Case studies

Case Studies At Honeywell Analytics three MiR100 robots now do Two MiR100 robots have automated the Argon Medical uses a MiR200 robot for moving the internal transportation tasks and have freed up 6 monotonous tasks of moving parts from surgical needles from production in clean rooms fulltime employees for more valuable tasks. Watch production to warehouse at Flex. Watch video to warehouse. Watch video video

Case Studies A fleet of four MiR100 robots is part of a fully Two MiR100 robots have improved logistics and The Hospital of Southern Jutland uses a fleet of MIR automated production at Kamstrup, where the efficiency and are helping Magna-Power compete in a robots for transporting blood samples and cancer MiR robots connects production lines and robotic global market. Watch video. medicine. Watch video. cells. Watch video.

Questions and Comments
