ADDRESS TRANSLATION AND TLB Mahdi Nazm Bojnordi Assistant Professor School of Computing University of Utah CS/ECE 6810: Computer Architecture Overview Announcement Homework 3 submission deadline: Nov. 11 th This lecture Virtual


  1. ADDRESS TRANSLATION AND TLB Mahdi Nazm Bojnordi Assistant Professor School of Computing University of Utah CS/ECE 6810: Computer Architecture

  2. Overview ¨ Announcement ¤ Homework 3 submission deadline: Nov. 11 th ¨ This lecture ¤ Virtual memory ¤ Page tables and address translation ¤ Translation look-aside buffer (TLB)

  3. Recall: Memory Hierarchy ¨ Lower levels provide greater capacity longer time ¤ Does the program fit in main memory? ¤ What if running multiple programs? Capacity: 8MB Cache Time: ~20 ns Greater Main Capacity: 8GB Capacity Memory Time: ~250 ns Capacity: 500GB Secondary Time: ~10 ms Memory

  4. Virtual Memory ¨ Use the main memory as a “cache” for secondary memory ¤ Placement policy? Main Memory for(i=0; i<100;++i) { a[i]++; } Disk

  5. Virtual Memory ¨ Use the main memory as a “cache” for secondary memory ¤ Placement policy? ¨ Allow efficient and safe sharing the physical main memory among multiple programs ¤ Replacement policy? Main Memory for(i=0; i<100;++i) { for(i=0; i<200;++i) { a[i]++; a[i]=a[i]+i; } } Disk

  6. Virtual Memory Systems ¨ Provides illusion of very large memory ¤ Address space of each program larger than the physical main memory ¨ Memory management unit (MMU) App ¤ Between main and secondary mem. Virtual Address Space ¤ Address translation n Virtual address space used by the program n Physical address space is provided by the physical main memory Secondary Memory

  7. Virtual Memory Systems ¨ Provides illusion of very large memory ¤ Address space of each program larger than the physical main memory ¨ Memory management unit (MMU) App ¤ Between main and secondary mem. Virtual Address Space ¤ Address translation n Virtual address space used by the Translation program Main Memory n Physical address space is provided by the physical main memory Secondary Memory

  8. Virtual Address ¨ Every virtual address is translated to a physical address with the help of hardware ¨ Data granularity Virtual Address Physical Memory 31 0 0 Physical Address 29 0 1G

  9. Virtual Address ¨ Every virtual address is translated to a physical address with the help of hardware ¨ Data granularity Virtual Address Physical Memory 31 0 0 Page Frame 0 Page Physical Address 29 0 Frame 1 Page Frame 2 … Page Frame N-1 1G

  10. Virtual Address ¨ Every virtual address is translated to a physical address with the help of hardware ¨ Data granularity Virtual Address Physical Memory 31 0 0 offset Page Frame 0 Page Physical Address 29 0 Frame 1 offset Page Frame 2 … Page Frame N-1 1G

  11. Virtual Address ¨ Every virtual address is translated to a physical address with the help of hardware ¨ Data granularity Virtual Address Physical Memory 31 0 0 Virtual Page No offset Page Frame 0 Page Physical Address 29 0 Frame 1 Page frame No offset Page Frame 2 Translator … Page Frame N-1 1G

  12. Virtual Address ¨ Every virtual address is translated to a physical address with the help of hardware ¨ Data granularity Virtual Address Physical Memory 31 0 0 Virtual Page No offset Page Frame 0 Page Physical Address 29 0 Frame 1 Page frame No offset Page Frame 2 … What is the table size? Page Frame N-1 Page Table 1G

  13. Address Translation Issues ¨ Where to store the table? ¤ Too big for on-chip cache ¤ Should be maintained in the main memory

  14. Address Translation Issues ¨ Where to store the table? ¤ Too big for on-chip cache ¤ Should be maintained in the main memory ¨ What to do on a page table miss (page fault)? ¤ No valid frame assigned to the virtual page ¤ OS copies the page from disk to page frame

  15. Address Translation Issues ¨ Where to store the table? ¤ Too big for on-chip cache ¤ Should be maintained in the main memory ¨ What to do on a page table miss (page fault)? ¤ No valid frame assigned to the virtual page ¤ OS copies the page from disk to page frame ¨ What is the cost of address translation? ¤ Additional accesses to main memory per every access ¤ Optimizations?

  16. Address Translation Cost ¨ Page walk: look up the physical address in the page table ¤ How many pages to store the page table? Virtual Address 20 12 base à Page frame No 12 Physical Address Page Table

  17. Multi-Level Page Table ¨ The virtual (logical) address space is broken down into multiple pages ¤ Example: 4KB pages Virtual Address 10 10 12 base à Page frame No 12 Physical Address

  18. Translation Lookaside Buffer ¨ Exploit locality to reduce address translation time ¤ Keep the translation in a buffer for future references Virtual Address Physical Memory Virtual Page No offset Page Frame 0 Page Frame 1 Page frame No offset Page Frame 2 Physical Address … Page Frame N-1 Page Table

  19. Translation Lookaside Buffer ¨ Exploit locality to reduce address translation time ¤ Keep the translation in a buffer for future references 0 Virtual 1 TLB Address Physical Memory 0 Virtual Page No offset Page 1 Frame 0 Page Frame 1 Page frame No offset Page Frame 2 Physical Address … Page Frame N-1 Page Table

  20. Translation Lookaside Buffer ¨ Just like any other cache, the TLB can be organized as fully associative, set associative, or direct ¨ TLB access is typically faster than cache access ¤ Because TLBs are much smaller than caches ¤ TLBs are typically not more than 128 to 256 entries even on high-end machines V Virtual Page # Physical Page # Dirty Status

  21. CAM Based TLB ¨ Content addressable memory (CAM) ¤ Unlike RAM, data in address out CAM: Search Operation RAM: Read Operation Data in Address in Decoder address match Data out

  22. CAM Based TLB ¨ Content addressable memory (CAM) ¤ Unlike RAM, data in address out ¨ CAM based TLB What if multiple rows match? ¤ Both CAM and RAM are used Virtual Page No RAM CAM Physical Page No Dirty Status

  23. TLB in Memory Hierarchy ¨ On a TLB miss, is the page loaded in memory? ¤ Yes: takes 10’s cycles to update the TLB ¤ No: page fault n Takes 1,000,000’s cycles to load the page and update TLB hit PA VA miss Processor TLB Main Cache Core Lookup Memory hit Data

  24. TLB in Memory Hierarchy ¨ On a TLB miss, is the page loaded in memory? ¤ Yes: takes 10’s cycles to update the TLB ¤ No: page fault n Takes 1,000,000’s cycles to load the page and update TLB hit PA VA miss Processor TLB Main Cache Core Lookup Memory miss hit Translaltion Data

  25. TLB in Memory Hierarchy ¨ On a TLB miss, is the page loaded in memory? ¤ Yes: takes 10’s cycles to update the TLB ¤ No: page fault n Takes 1,000,000’s cycles to load the page and update TLB Physically indexed, physically tagged: TLB on critical path! hit PA VA miss Processor TLB Main Cache Core Lookup Memory miss hit Translaltion Data

  26. Physically Indexed Caches ¨ Problem: increased critical path due to sequential access to TLB and cache Virtual Page No Page Offset TLB Physical Frame Page Offset

  27. Physically Indexed Caches ¨ Problem: increased critical path due to sequential access to TLB and cache Virtual Page No Page Offset TLB Physical Frame Page Offset Tag Index Byte Tag Array Data Array = Data Block hit/miss*

  28. Physically Indexed Caches ¨ Problem: increased critical path due to sequential access to TLB and cache Virtual Page No Page Offset Observation: lower address TLB bits (page offset) are not translated Physical Frame Page Offset Tag Index Byte Tag Array Data Array = Data Block hit/miss*

  29. Virtually Indexed Caches ¨ Idea: Index into cache in parallel with page number translation in TLB Virtual Page No Page Offset Index Byte TLB Tag Array Data Array Tag Data Block = hit/miss*

  30. Virtually Indexed Caches ¨ Idea: Index into cache in parallel with page number translation in TLB what if the page offset is not Virtual Page No Page Offset equal to index+byte? Index Byte TLB Tag Array Data Array Tag Data Block = hit/miss*
