Adding Factors and Interactions Danielle Quinn PhD Candidate, - PowerPoint PPT Presentation

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Adding Factors and Interactions Danielle Quinn PhD Candidate, Memorial University

Regression Modeling in R: Case Studies Identifying additional factors pr_fac(poisson_glm, dragonflies$season, xlabel = "season", modeltype = "poisson")

Regression Modeling in R: Case Studies Factors and interactions Multiple predictor variables (factors) may in�uence the response variable Interaction : the e�ect of one predictor may depend on the level of the other predictor variable

Regression Modeling in R: Case Studies Adding a factor # Poisson GLM poisson_glm <- glm(abundance ~ stream_flow, data = dragonflies, family = "poisson") # Poisson GLM with an interaction added poisson_glm_factor <- glm(abundance ~ stream_flow * season, data = dragonflies, family = "poisson")

Regression Modeling in R: Case Studies Generating predicted values # Create pred_df data frame pred_df <- expand.grid(stream_flow = seq(from = 1, to = 5, length = 10), season = c("summer", "autumn")) # Add predictions to pred_df pred_df$predicted <- predict(poisson_glm_factor, pred_df, type = "response" pred_df stream_flow season predicted 1.00 summer 75.61 1.44 summer 60.98 1.89 summer 49.17 ... ... ... ... ... ... ... ... ... 1.00 autumn 64.88 1.44 autumn 51.21 1.89 autumn 40.41

Regression Modeling in R: Case Studies Visualizing predicted values ggplot(dragonflies) + geom_point(aes(x = stream_flow, y = abundance)) + geom_line(aes(x = stream_flow, y = predicted, col = season), data = pred_

Regression Modeling in R: Case Studies Model diagnostics: residuals diag <- data.frame(residuals = resid(poisson_glm_factor), fitted = fitted(poisson_glm_factor)) ggplot(diag) + geom_point(aes(x = fitted, y = residuals))

Regression Modeling in R: Case Studies Model diagnostics: dispersion dispersion(poisson_glm_factor, modeltype = "poisson") 20.65

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Time to practice!

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Adding an o�set to the model Danielle Quinn PhD Candidate, Memorial University

Regression Modeling in R: Case Studies Reviewing the data head(dragonflies, n = 1) abundance feeding_events area stream_flow time season 1 16 69 3.671 1.288379 day summer

Regression Modeling in R: Case Studies Dealing with unequal sampling e�ort # Birds per square meter # Birds per square meter 15 / 1 44 / 3 15 14.67

Regression Modeling in R: Case Studies Adding an o�set # Create column containing natural log of area dragonflies$logarea <- log(dragonflies$area) head(dragonflies) abundance feeding_events area stream_flow time season logarea 1 16 69 3.671 1.2883787 day summer 1.300464 2 32 153 4.574 1.2787605 night autumn 1.520388 3 88 408 5.100 0.5956905 day summer 1.629241 4 140 691 3.188 1.4999930 day summer 1.159394 5 62 355 3.830 1.1653945 day summer 1.342865 6 143 678 3.826 1.4268238 day summer 1.341820 # Add offset to the model poisson_glm_offset <- glm(abundance ~ stream_flow * season + offset(logarea data = dragonflies, family = "poisson")

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Try it out!

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Negative Binomial models and model selection Danielle Quinn PhD Candidate, Memorial University

Regression Modeling in R: Case Studies Negative Binomial GLMs Have an extra parameter, theta , which relaxes the assumptions of equality between the mean and the variance This improves upon the Poisson GLM by addressing the issue of overdispersion Use the same link function as Poisson GLMs

Regression Modeling in R: Case Studies Negative Binomial GLMs in R library(MASS) neg_binom_glm <- glm.nb(abundance ~ stream_flow * season + offset(logarea), data = dragonflies)

Regression Modeling in R: Case Studies Dropping terms # Use drop1 to test influence of each term drop1(neg_binom_glm, test = "Chisq") Single term deletions Model: abundance ~ stream_flow * season + offset(logarea) Df Deviance AIC LRT Pr(>Chi) <none> 159.93 1361.1 stream_flow:season 1 160.10 1359.3 0.16363 0.6858 # Remove the interaction from the model neg_binom_glm_small <- glm.nb(abundance ~ stream_flow + season + offset(log data = dragonflies)

Regression Modeling in R: Case Studies Dropping (more?) terms drop1(neg_binom_glm_small, test = "Chisq") Single term deletions Model: abundance ~ stream_flow + season + offset(logarea) Df Deviance AIC LRT Pr(>Chi) <none> 160.04 1359.3 stream_flow 1 351.37 1548.6 191.323 <2e-16 *** season 1 161.48 1358.7 1.434 0.0485 * ---- Signif. codes: 0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1

Regression Modeling in R: Case Studies Model diagnostics: residuals neg_binom_glm neg_binom_glm_small

Regression Modeling in R: Case Studies Model diagnostics: dispersion dispersion(neg_binom_glm, dispersion(neg_binom_glm_small, modeltype = "nb") modeltype = "nb") 1.11 1.10

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Apply your �rst Negative Binomial GLM!

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Model selection and visualization Danielle Quinn PhD Candidate, Memorial University

Regression Modeling in R: Case Studies How complex should it get? "Remember that all models are wrong; the practical question is how wrong do they have to be to not be useful." George Box Larger model : All terms included ( neg_binom_glm ) Smaller model : Interaction e�ect removed ( neg_binom_glm_small )

Regression Modeling in R: Case Studies Model selection: what we know so far Do both models make sense? Is there heterogeneity in the residuals? Is there overdispersion?

Regression Modeling in R: Case Studies Model selection: Akaike Information Criterion (AIC) Used for nested models only AIC(neg_binom_glm, neg_binom_glm_small) df AIC neg_binom_glm 5 1363.135 neg_binom_glm_small 4 1361.299 Lower values indicate be�er �t A di�erence of three or more indicates a model is a be�er �t than the other When all else is similar, the less complex model is usually a good choice.

Regression Modeling in R: Case Studies Generating predicted values # Create data frame pred_df pred_df <- expand.grid(stream_flow = seq(from = 1, to = 5, length = 10), season = c("summer", "autumn"), logarea = mean(dragonflies$logarea)) # Add predicted values to pred_df pred_df$predicted <- predict(neg_binom_glm_small, pred_df, type = "response head(pred_df) stream_flow season logarea predicted 1 1.000000 summer 1.73009 126.37291 2 1.444444 summer 1.73009 85.21510 3 1.888889 summer 1.73009 57.46179 4 2.333333 summer 1.73009 38.74732 5 2.777778 summer 1.73009 26.12789 6 3.222222 summer 1.73009 17.61842

Regression Modeling in R: Case Studies Visualizing the model ggplot(dragonflies) + geom_point(aes(x = stream_flow, y = abundance)) + geom_line(aes(x = stream_flow, y = predicted, col = season), data = pred_

Regression Modeling in R: Case Studies

Regression Modeling in R: Case Studies Generating standard errors # Extract fitted values raw_fit <- predict(neg_binom_glm_small, pred_df, type = "link") # Extract standard errors raw_se <- predict(neg_binom_glm_small, pred_df, type = "link", se.fit = TRUE)$se # Calculate upper and lower standard errors and add to pred_df pred_df$lower <- exp(raw_fit - 1.96 * raw_se) pred_df$upper <- exp(raw_fit + 1.96 * raw_se) head(pred_df) stream_flow season logarea predicted upper lower 1 1.000000 summer 1.73009 126.37291 153.46921 104.06068 2 1.444444 summer 1.73009 85.21510 101.30002 71.68422 3 1.888889 summer 1.73009 57.46179 67.56242 48.87121 4 2.333333 summer 1.73009 38.74732 45.62704 32.90494 5 2.777778 summer 1.73009 26.12789 31.19052 21.88699 6 3.222222 summer 1.73009 17.61842 21.52939 14.41790

Regression Modeling in R: Case Studies Visualizing the standard error ggplot(dragonflies) + geom_point(aes(x = stream_flow, y = abundance)) + geom_line(aes(x = stream_flow, y = predicted, col = season), data = pred_ geom_line(aes(x = stream_flow, y = upper, col = season), linetype = "dash data = pred_df) + geom_line(aes(x = stream_flow, y = lower, col = season), linetype = "dash data = pred_df)

Regression Modeling in R: Case Studies

Regression Modeling in R: Case Studies REGRESSION MODELING IN R : CASE STUDIES Time to practice!
