A Cloud Benchmark Suite Combining Micro and Application Benchmarks Joel Scheuner, Philipp Leitner Joel Scheuner � scheuner@chalmers.se � joe4dev � @joe4dev

Context: Public Infrastructure-as-a-Service Clouds IaaS PaaS SaaS Applications Applications Applications User-Managed Data Data Data Runtime Runtime Runtime Middleware Middleware Middleware OS OS OS Virtualization Virtualization Virtualization Servers Servers Servers Storage Storage Storage Networking Networking Networking Provider-Managed Infrastructure-as-a-Service (IaaS) Platform-as-a-Service (PaaS) Software-as-a-Service (SaaS)

Motivation: Capacity Planning in IaaS Clouds What cloud provider should I choose? https://www.cloudorado.com 2018-04-10 QUDOS@ICPE'18 3

Motivation: Capacity Planning in IaaS Clouds What cloud service (i.e., instance type) should I choose? 120 t2.nano Number of Instance Type 0.05-1 vCPU 100 0.5 GB RAM $0.006/h 80 60 x1e.32xlarge 40 128 vCPUs 3904 GB RAM 20 $26.688 hourly 0 6 7 8 9 0 1 2 3 4 5 6 7 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 2 2 2 2 2 2 2 2 2 2 2 2 2018-04-10 QUDOS@ICPE'18 4

Topic: Performance Benchmarking in the Cloud “The instance type itself is a very major tunable parameter” � @brendangregg re:Invent’17 https://youtu.be/89fYOo1V2pA?t=5m4s 2018-04-10 QUDOS@ICPE'18 5

Background Application Micro Benchmarks Benchmarks Memory CPU I/O Overall performance Network (e.g., response time) Generic Specific Artificial Real-World Resource- Resource- specific heterogeneous 2018-04-10 QUDOS@ICPE'18 6

Related Work Micro Benchmarking / Application Kernels Iosup et. al. Performance analysis of cloud computing services for many-tasks scientific computing. Ostermann et. al. A performance analysis of EC2 cloud computing services for scientific computing. Application Benchmarking Ferdman et. al. Clearing the clouds: a study of emerging scale-out workloads on modern hardware. Cooper et. al. Benchmarking Cloud Serving Systems with YCSB. Repeatability of Cloud Experiments A) Single Trial B C A B) Multiple Consecutive Trials (MCT) Abedi and Brecht. Conducting Repeatable Experiments A A A B B B C C C C) Multiple Interleaved Trials (MIT) in Highly Variable Cloud Computing Environments. A B C A B C A B C D) Randomized Multiple Interleaved Trials (RMIT) @ICPE’17 A A A B B C C B C 2018-04-10 QUDOS@ICPE'18 7

Problem: Isolation, Reproducibility of Execution Application Micro Benchmarks Benchmarks Memory CPU I/O Overall performance Network (e.g., response time) Generic Specific Artificial Real-World Resource-specific Resource- heterogeneous 2018-04-10 QUDOS@ICPE'18 8

How can we systematically combine and execute Question: micro and application benchmarks? Application Micro Benchmarks Benchmarks Memory CPU I/O Overall performance Network (e.g., response time) Generic Specific Artificial Real-World Resource-specific Resource- heterogeneous 2018-04-10 QUDOS@ICPE'18 9

Idea Application Micro Benchmarks Benchmarks Memory CPU I/O Overall performance Network (e.g., response time) Generic Specific Artificial Real-World Systematically Resource-specific Resource- Execute heterogeneous Together 2018-04-10 QUDOS@ICPE'18 10

Execution Methodology D) Randomized Multiple Interleaved Trials (RMIT) B A C C B A A C B 30 benchmark scenarios 3 trials ~2-3h runtime 2018-04-10 QUDOS@ICPE'18 11

Benchmark Manager Cloud WorkBench (CWB) Tool for scheduling cloud experiments � sealuzh/cloud-workbench CloudCom 2014 “Cloud Work Bench – Infrastructure-as-Code Based Cloud Benchmarking” Scheuner, Leitner, Cito, and Gall Demo@WWW 2015 Scheuner, Cito, Leitner, and Gall 2018-04-10 QUDOS@ICPE'18 12

Architecture Overview 2018-04-10 QUDOS@ICPE'18 13

Micro Micro Benchmarks Benchmarks Broad resource coverage and specific resource testing Memory CPU I/O Network I/O CPU • [file I/O] sysbench/fileio-1m-seq-write • sysbench/cpu-single-thread • [file I/O] sysbench/fileio-4k-rand-read • sysbench/cpu-multi-thread • [disk I/O] fio/4k-seq-write • stressng/cpu-callfunc • [disk I/O] fio/8k-rand-read • stressng/cpu-double • stressng/cpu-euler Network • stressng/cpu-ftt • iperf/single-thread-bandwidth • stressng/cpu-fibonacci • iperf/multi-thread-bandwidth • stressng/cpu-int64 • stressng/network-epoll • stressng/cpu-loop • stressng/network-icmp • stressng/cpu-matrixprod Software (OS) • stressng/network-sockfd • sysbench/mutex • stressng/network-udp Memory • sysbench/thread-lock-1 • sysbench/memory-4k-block-size • sysbench/thread-lock-128 • sysbench/memory-1m-block-size 2018-04-10 QUDOS@ICPE'18 14

Micro Micro Benchmarks: Examples Benchmarks File I/O: 4k random read Bandwidth 1) Prepare Memory CPU I/O Network I/O Network Server 2) Run 3) Extract Result 4) Cleanup 3.5793 MiB/sec Client Result 972 Mbits/sec 2018-04-10 QUDOS@ICPE'18 15

Application Benchmarks Application Benchmarks Overall performance (e.g., response time) Molecular Dynamics WordPress Benchmark (WPBench) Simulation (MDSim) 100 Number of Concurrent Threads 80 60 40 20 0 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 Elapsed Time [min] Multiple short blogging session scenarios (read, search, comment) 2018-04-10 QUDOS@ICPE'18 16

Performance Data Set * Instance Type vCPU ECU RAM [GiB] Virtualization Network Performance eu + us m1.small 1 1 1.7 PV Low m1.medium 1 2 3.75 PV Moderate m3.medium 1 3 3.75 PV /HVM Moderate eu + us m1.large 2 4 7.5 PV Moderate m3.large 2 6.5 7.5 HVM Moderate eu m4.large 2 6.5 8.0 HVM Moderate c3.large 2 7 3.75 HVM Moderate c4.large 2 8 3.75 HVM Moderate c3.xlarge 4 14 7.5 HVM Moderate c4.xlarge 4 16 7.5 HVM High c1.xlarge 8 20 7 PV High * ECU := Elastic Compute Unit (i.e., Amazon’s metric for CPU performance) >240 Virtual Machines (VMs) à 3 Iterations à ~750 VM hours >60’000 Measurements (258 per instance) 2018-04-10 QUDOS@ICPE'18 17

WPBench Response Time Cost Frontier Cost/Performance is a trade-off but there exist unfavorable instance types WPBench Scenario Read Response Time (ms) Instance Type c1.xlarge -80% performance c3.large -35% cost 2000 c3.xlarge c4.large c4.xlarge m1.large m1.medium 1000 m1.small +40% performance m3.large - 40% cost m3.medium (hvm) m3.medium (pv) m4.large Cost-Optimal Instance Types Frontier 0 0.2 0.4 0.6 Instance Cost (USD/h) 2018-04-10 QUDOS@ICPE'18 18

Intra-Cloud Network Bandwidth over Time Almost perfect stability in comparison to previous results 2017 2014 Instance Type m1.small m3.large 600 m3.medium (hvm) Network Bandwidth (Mbits/sec) 500 P. Leitner, J. Cito. Patterns in the Chaos - A Study of Performance Variation and Predictability in Public IaaS Clouds. TOIT 2016 400 300 2017 − 04 − 04 2017 − 04 − 06 2017 − 04 − 08 2017 − 04 − 10 2017 − 04 − 12 2017 − 04 − 14 2017 − 04 − 16 Time 2018-04-10 QUDOS@ICPE'18 19

Disk Utilization during I/O Benchmark The newer virtualization type hvm is more I/O efficient than pv Instance Type c1.xlarge c3.large FIO 8k Random Read Disk Utilization (%) c3.xlarge 95 c4.large c4.xlarge m1.large m1.medium m1.small m3.large m3.medium (hvm) m3.medium (pv) 90 m4.large Virtualization Type hvm pv 98.5 98.7 98.9 99.1 FIO 4k Sequential Write Disk Utilization (%) 2018-04-10 QUDOS@ICPE'18 20

Future Work Benchmark Benchmark Data Pre- Data Design Execution Processing Analysis � � 50 40 Relative Standard Deviation (RSD) [%] 30 � � � � � � 20 � � � � � � � � � � � � � 10 � � � � � � � � � � � � � � � � � � � � 6.83 � � � � � � 5 � � � � � � 4.41 � 4.3 � � � � � � 3.32 � � � � � � � 3.16 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 0 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � m1.small (eu) m1.small (us) m3.medium (eu) m3.medium (us) m3.large (eu) Configuration [Instance Type (Region)] Under Submission Accepted QUDOS@ICPE 2018 “A Cloud Benchmark Suite “Estimating Cloud Application Performance Combining Micro and Applications Benchmarks” Based on Micro Benchmark Profiling” Scheuner and Leitner Scheuner and Leitner 2018-04-10 QUDOS@ICPE'18 21

Conclusions Selecting an optimal instance type can save up to 40% costs while increasing up to 40% performance Support trend towards more predictable performance (AWS EC2) The newer virtualization type (hvm) improves I/O utilization rates up to 10% (vs pv) � scheuner@chalmers.se 2018-04-10 QUDOS@ICPE'18 22
