1 GLOMEX Glomex is one of the leading companies in the manufacturing of antennas and entertainment systems for nautical sector. Born in 1984 with the ambition to improve the reliability of the maritime telecommunications and to offer its

  1. 1

  2. GLOMEX Glomex is one of the leading companies in the manufacturing of antennas and entertainment systems for nautical sector. Born in 1984 with the ambition to improve the reliability of the maritime telecommunications and to offer its customers quality products, efficiency, investments in technology and human resources, service and style. 28/05/2015 2 2

  3. GLOMEX VISION Understand the requirements of yachtsmen Glomex works to produce the best products for ensuring a radio contact with the mainland and the reception of the satellite TV and DVBT TV signal in any environmental condition. In a few words: with Glomex, you are never alone on the water 28/05/2015 3 3

  4. GLOMEX MISSION Glomex, the best in marine antennas This, in brief, is the mission of a company that, for 30 years , has been pursuing a single goal: providing high quality marine antennas with an excellent value for money, that pass any resistance test (UV-ray exposure, environmental test, mechanical, electric and electronic strain) 28/05/2015 4 4

  5. GLOMEX STRATEGY Serving yachtsmen and enterprises During the years Glomex has increased its antennas range opening new divisions and entering in new sectors, for reflecting the ever-changing needs of the market. 28/05/2015 5 5

  6. ABOUT GLOMEX During the first years, the production focused on the marine industry, with VHF and DVBT TV antennas produced entirely in Italy. 28/05/2015 6 6

  7. ABOUT GLOMEX Today Glomex is a company based in Ravenna (Italy) that manufactures marine antennas and mount/bracket in its factory located at the renewed headquarter and in other facilities in Italy and abroad. 28/05/2015 7 7

  8. GLOMEX PARTNERHIPS Thanks to the success of its products Glomex is a strong reality that has consolidated commercial partnerships all over the world, with own distributors and with the largest shipyards 28/05/2015 8 8

  9. GLOMEX DISTRIBUTORS 28/05/2015 Proprerty of Glomex Srl, reproduction forbidden 9 9

  10. SATELLITE TV ANTENNAS In 2004, Glomex launched a new course by entering the market of satellite technology and designing its first satellite antennas for marine industry. The company faced the risks and uncertainties of a new development area, counting on its belief in research and development, and on the scrupulous testing carried out on all products. 28/05/2015 10 10

  11. MARINE SATELLITE TV ANTENNAS Satellite TV antennas with the new High Performance Dish for the European market. This range includes: V9331 V8001 V9100 – V9104 V9801 – V9804 V9000 V8100 33cm (13”) 39cm (15”) V9104SKEW V9804SKEW 39cm (15”) 47cm (18”) 47cm (18”) 60cm (24”)

  12. RIVER SATELLITE TV ANTENNAS Glomex developed also two satellite TV antennas for river boats These antennas are also ideal for the canals along the city R500 R9804 58x32cm (23x13”) 60cm (24”)

  13. SATELLITE TV ANTENNAS

  14. FOOTPRINT satellite coverage area 60 cm dish MARS V9801 / V9804 / V9804SKEW 47 cm dish RHEA V8100 – SATURN V9100 / V9104 / V9104SKEW 39 cm dish PANDORA V8001 –VENUS V9000 33 cm dish URANIA 2 V9331 58x32 cm dish DANUBE 2 R500

  15. FOOTPRINT satellite coverage area 60 cm dish MARS V9801 / V9804 / V9804SKEW 47 cm dish RHEA V8100 – SATURN V9100 / V9104 / V9104SKEW 39 cm dish PANDORA V8001 – VENUS V9000

  16. FOOTPRINT satellite coverage area 60 cm dish MARS V9801 / V9804 / V9804SKEW 47 cm dish RHEA V8100 – SATURN V9100 / V9104 / V9104SKEW 39 cm dish PANDORA V8001– VENUS V9000

  17. THE TEST LAB Glomex Test Lab, the laboratory boat, is used to provide high quality marine antennas ; on this boat, Glomex technicians tests all our products in order to guarantee the quality without Compromise. 28/05/2015 17 17

  18. MAIN FEATURES 1) High performance Dish – HPD Glomex antennas are equipped with the high-performance parabolic dishes, designed to optimize signals and to compensate quality loss due to the multiplication of satellites in the Earth’s orbit and to transmissions on the same frequencies.

  19. MAIN FEATURES 2) New silent tracking The applied technology allows improving the on-board comfort, especially when the boat rides at anchor, when any audible noise coming from the TV SAT antenna is perceived as a disturbance by the crew. Now we have one of the most silent antennas on the market, if not the most silent one.

  20. MAIN FEATURES 3) Automatic skew We have designed an automatic adjustment system of the skew angle, with no intervention by the user, according to the longitude of the boat and to the desired satellite. It is available for purchase as an optional system for Saturn 4 and Mars 4

  21. AUTOMATIC SKEW The geostationary satellites are located on the orbit close to the equator and are aligned with the terrestrial axis. Therefore, according to any geographical position corresponding to the equator line, all satellites appear as shifted to the East or to the West of their own South, as if they were tilted. In this case the polarizations of such satellites are no more horizontal or vertical according to their own position, but tilted. Therefore, if the frequency converter (LNB) does not turn the same number of degrees of inclination of the satellite, the polarizations will result in misalignment. The Skew option is a compensation system acting physically on the LNB and acknowledging the geographic position by changing automatically the inclination. In this way the polarization is optimized and the best possible signal quality is achieved.

  22. MAIN FEATURES 4) The new LNB We have decided to invest a lot in developing an LNB with specific characteristics for the mobile market. In particular, the relationship signal/noise has been improved thanks to particularly expensive professional components.

  23. MAIN FEATURES SKEW

  24. MAIN FEATURES Glomex satellite TV antennas are compatible with digital satellite trasmission standard DVB It’s a special check used in order to ensure that the antenna is tracking the right satellite, as the small separation angle between one satellite and another could generate problems in satellite tracking.

  25. MAIN FEATURES Glomex satellite Tv antennas with one output (Urania2, Pandora, Rhea, Venus, Saturn 1, Mars 1 and Danube) are equipped with a single coaxial rotating joint, with 2 SMB connectors for high quality radio frequency, allowing the antenna to turn infinetly on the azimuth axis.

  26. MAIN FEATURES Glomex satellite TV antennas with multi- output (Saturn 4, Mars 4 and Rhine) are equipped with a coaxial rotating joint allowing the antenna to transmit 4 polarization (VL, VH, HL, HH), no coaxial cable wrapping is needed.

  27. MAIN FEATURES All Glomex antennas are equipped with MEMS electronic gyroscopes, developed by Murata, a leader in this sector. Gyroscopes allow to counterbalance the movements of the boat, thus obtaining the fastest and most precise rolling and pitching compensation available today on the market.

  28. MAIN FEATURES Glomex antennas make work easier for installers. Glomex antennas with one output need only one cable to work and to connect to the TV set.

  29. MAIN FEATURES Glomex satellite antennas do not need to be connect to external tools such as GPS or compass to find the satellite. So installations are simplified without loosing signal acquisition speed.

  30. MAIN FEATURES • • High performance Dish Glomex antennas are equipped with the new high-performance parabolic dishes, designed to optimize signals and to compensate quality loss due to the multiplication of satellites in the Earth’s orbit and to transmissions on the same frequencies. Silent Tracking Operation The new noise reduction system based on new electronics and a new software for keeping the satellite signal, which improves on-board comfort.

  31. MAIN FEATURES SKEW The skew option is an automatic compensating system that, acting physically on the LNB, it automatically changes its inclination optimizing the polarization in order to obtain the best quality of the signal. The exact position of the boat is detected by a GPS receiver placed inside the antenna. The new recognition system of satellites SSI (Sync satellite identification) allows to speed up the search for the satellite because the antenna stops only on the selected satellite, checking it through the recognition of the NIT. It’s currently used in the R9804 and R8500 river antennas.

  32. MAIN FEATURES Glomex introduced inside of the antennas a new set of cables for high flexibility and resistant to low temperatures (-30 ° C).

  33. RADOME Radome protects antennas by weather conditions. Radome is distinguished from other structures for the material used in the construction that allows a minimum attenuation of electromagnetic signals.

  34. RADOME The radome used in the Glomex antennas is made by UV-resistant thermoplastic material with low attenuation factor, about 0.1dBuV per mm of thickness. This thermoplastic material has a reduced capacity to retain water droplets, which creates attenuation to the satellite signal when deposited on the radome.
