02291: System Integration Introduction to UML Hubert Baumeister - PowerPoint PPT Presentation

02291: System Integration Introduction to UML Hubert Baumeister huba@dtu.dk DTU Compute Technical University of Denmark Spring 2020 What is the UML? Unified Modelling Language (UML) What is the UML? Unified Modelling Language (UML)


  1. 02291: System Integration Introduction to UML Hubert Baumeister huba@dtu.dk DTU Compute Technical University of Denmark Spring 2020

  2. What is the UML? ◮ Unified Modelling Language (UML)

  3. What is the UML? ◮ Unified Modelling Language (UML) ◮ Family of graphical notations for describing aspects of (object-oriented) software ◮ ”A picture is more than a thousand words”

  4. What is the UML? ◮ Unified Modelling Language (UML) ◮ Family of graphical notations for describing aspects of (object-oriented) software ◮ ”A picture is more than a thousand words” ◮ Based on a metamodel

  5. What is the UML? ◮ Unified Modelling Language (UML) ◮ Family of graphical notations for describing aspects of (object-oriented) software ◮ ”A picture is more than a thousand words” ◮ Based on a metamodel ◮ Not a development process

  6. What is the UML? ◮ Unified Modelling Language (UML) ◮ Family of graphical notations for describing aspects of (object-oriented) software ◮ ”A picture is more than a thousand words” ◮ Based on a metamodel ◮ Not a development process ◮ UML is an open standard and an ISO standard ◮ managed by the Object Management Group ( www.omg.org )

  7. What is the UML? ◮ Unified Modelling Language (UML) ◮ Family of graphical notations for describing aspects of (object-oriented) software ◮ ”A picture is more than a thousand words” ◮ Based on a metamodel ◮ Not a development process ◮ UML is an open standard and an ISO standard ◮ managed by the Object Management Group ( www.omg.org ) ◮ Web resources ◮ http://www.uml.org

  8. UML ’s history ◮ 1980s ◮ Objects became main stream ◮ OO methods and graphical notations ◮ Grady Booch, Peter Coad, Ivar Jacobson, Jim Odell, Jim Rumbaugh, Sally Shlaer and Steve Mellor, Rebecca Wirfs-Brock, . . . ◮ 1990s ◮ Grady Booch, Ivar Jacobson and Jim Rumbaugh at Rational ◮ First version of the UML (UML 0.8) ◮ 1996 ◮ The Object Management Group (OMG) ◮ Driven by tool vendors! ◮ Tool interoperability! ◮ 2005 ◮ UML 2.0 ISO standard

  9. Notations and Metamodels ◮ UML consists of ◮ a set of graphical notations ◮ and a single metamodel

  10. Example of a class diagram <<interface>> LibraryInterface {inv: overdue iff dueDate <> null and today > dueDate} scanLibraryCard() checkOut scanBook() checkIn ... {pre: bor.canBorrow() post: dueDate = Date.today + 3 weeks and bor.books->containing(self) } Library Book overdue scan library card() dueDate check out * scan book() register() check in deregister() ... checkout() checkin() user 0..5 * Borrower canBorrow() {body: books->size <= 5 and books->forAll(b | not(b.overdue))}

  11. Metamodel Excerpt Classifier {subsets namespace, subsets {ordered, subsets ownedMember, redefinitionContext} subsets redefinableElement} + class + nestedClassifier Class Classifier 0..1 * {subsets featuringClassifier, {ordered, subsets feature, subsets redefinitionContext, subsets redefinableElement, subsets namespace} subsets ownedMember} + class + ownedOperation Operation 0..1 * {ordered, readOnly, Relationship Classifier {redefines general} subsets relatedElement} {subsets relationship} + /endType + association <<interface>> + /superClass * Type Association LibraryInterface {inv: overdue iff dueDate <> null and today > dueDate} * + class 1..* * + isDerived : Boolean = false scanLibraryCard() checkOut 0..1 0..1 scanBook() {subsets classifier} checkIn 0..1 + class + owningAssociation + association ... {pre: bor.canBorrow() 0..1 + association {subsets classifier, subsets namespace} {subsets memberNamespace} {subsets association, post: dueDate = Date.today + 3 weeks and {subsets owningAssociation} subsets featuringClassifier, bor.books->containing(self) } StructuralFeature subsets namespace, subsets redefinitionContext} Library Book {ordered, subsets member} overdue scan library card() 2..* + memberEnd dueDate {ordered, subsets attribute, {subsets ownedEnd} check out * * Property scan book() register() subsets ownedMember} + navigableOwnedEnd check in deregister() + ownedAttribute + isDerived : Boolean = false + isReadOnly : Boolean = false {redefines isReadOnly} ... checkout() + isDerivedUnion : Boolean = false checkin() * * + /default : String [0..1] user + aggregation : AggregationKind = none + ownedEnd 0..5 + /isComposite : Boolean * * {ordered, subsets memberEnd, subsets feature, + isID : Boolean = false Borrower subsets ownedMember, subsets redefinableElement} + redefinedProperty canBorrow() {body: books->size <= 5 and {subsets redefinedElement} books->forAll(b | not(b.overdue))} + subsettedProperty {subsets redefinableElement} * + property * * 0..1 0..1 + owningProperty + /opposite 0..1 {subsets owner} «enumeration» AggregationKind {subsets ownedElement} + defaultValue none shared ValueSpecification composite 0..1

  12. Metamodel ◮ Abstract syntax of UML diagrams

  13. Metamodel ◮ Abstract syntax of UML diagrams ◮ Describes the concepts of UML elements ◮ e.g. class, association, . . .

  14. Metamodel ◮ Abstract syntax of UML diagrams ◮ Describes the concepts of UML elements ◮ e.g. class, association, . . . ◮ concepts are mapped to notations ◮ e.g. the concept of a class is mapped to rectangle with subcompartments

  15. Metamodel ◮ Abstract syntax of UML diagrams ◮ Describes the concepts of UML elements ◮ e.g. class, association, . . . ◮ concepts are mapped to notations ◮ e.g. the concept of a class is mapped to rectangle with subcompartments ◮ Metamodel written in MOF (Meta-Object Facility) ◮ Basically UML class diagrams → MOF can be used to defined ones own modelling language → Course Software Engineering II (02162)

  16. Metamodel ◮ Abstract syntax of UML diagrams ◮ Describes the concepts of UML elements ◮ e.g. class, association, . . . ◮ concepts are mapped to notations ◮ e.g. the concept of a class is mapped to rectangle with subcompartments ◮ Metamodel written in MOF (Meta-Object Facility) ◮ Basically UML class diagrams → MOF can be used to defined ones own modelling language → Course Software Engineering II (02162) ◮ The metamodel is important for model exchange ◮ XMI (XML Metadata Interchange)

  17. The meaning of UML ◮ The abstract syntax / concepts: OK → metamodel

  18. The meaning of UML ◮ The abstract syntax / concepts: OK → metamodel ◮ The meaning of the concepts: not well-defined ◮ Meaning of class ? ◮ Execution of activity diagrams and state machines

  19. The meaning of UML ◮ The abstract syntax / concepts: OK → metamodel ◮ The meaning of the concepts: not well-defined ◮ Meaning of class ? ◮ Execution of activity diagrams and state machines ◮ Semantic variation points ◮ Left open in the standard ◮ Tool vendors choose meaning

  20. Ways of using the UML ◮ Sketch ◮ Informal use → Use of whiteboards, simple graphic editors

  21. Ways of using the UML ◮ Sketch ◮ Informal use → Use of whiteboards, simple graphic editors ◮ Blueprint ◮ Forward Engineering: e.g. create class stubs → Use of CASE tools

  22. Ways of using the UML ◮ Sketch ◮ Informal use → Use of whiteboards, simple graphic editors ◮ Blueprint ◮ Forward Engineering: e.g. create class stubs → Use of CASE tools ◮ Programming language ◮ Executable UML ◮ Problems ◮ How to describe the behaviour? → Use of CASE tools

  23. UML is not enough ◮ UML is a general purpose modelling language ◮ UML can be extended ◮ lightweight (UML profile) ◮ heavy weight → Use the modelling language best suited for your purpose

  24. UML Diagrams (I) ◮ Structure Diagrams ◮ Class Diagram ◮ Class, features, and relationships ◮ Object Diagram ◮ Example configuration of instances ◮ Package Diagram ◮ Hierarchical structure for models ◮ Component Diagram ◮ Structure and connections of components ◮ Deployment Diagram ◮ Deployment of artifacts to nodes ◮ Composite Structure Diagram ◮ Runtime decomposition of a class

  25. UML Diagrams (II) ◮ Behaviour Diagrams ◮ Use-Case Diagram ◮ How users interact with a system ◮ Activity Diagram ◮ Procedural and parallel behaviour ◮ State Machine Diagram ◮ How events change an object over its life ◮ Interaction Diagram ◮ Sequence Diagram : Interaction between objects; emphasis on sequence ◮ Communication Diagram (formerly called collaboration diagram ): Interaction between objects; emphasis on links ◮ Interaction Overview Diagram: Mix of sequence and activity diagram ◮ Timing Diagram: Interaction between objects; emphasis on timing

  26. Focus of the course One car, many models (abstractions)

  27. Focus of the course One system, many models (abstractions) Different Views on the system ◮ Functionality: Use Case diagram, state machines, activity diagram, . . . ◮ Structure: Component diagram, Class diagram ◮ Validation: Interaction diagram

  28. Library Example: Detail of Use case borrow book Use case diagram Use case borrow book LibrarySystem Basic course of events: borrow book 1. User scans his library card 2. User selects check out return book 3. User scans the book User search for book 4. System confirms loan

  29. Implementation: Component Diagram LibrarySystem LibraryInterface <<interface>> LibraryInterface scanLibraryCard() checkOut scanBook() checkIn ...

  30. Implementation: Class Diagram
