X3DOM Getting declarative (X)3D into HTML WebGL Camp2 Johannes - PowerPoint PPT Presentation

Nov 15, 2022 •135 likes •421 views

X3DOM Getting declarative (X)3D into HTML WebGL Camp2 Johannes Behr & Yvonne Jung Fraunhofer IGD johannes.behr@igd.fraunhofer.de X3DOM Project X3DOM (pronounced X-Freedom) is an experimental open source framework and runtime to support

  1. X3DOM Getting declarative (X)3D into HTML WebGL Camp2 Johannes Behr & Yvonne Jung Fraunhofer IGD johannes.behr@igd.fraunhofer.de

  2. X3DOM Project X3DOM (pronounced X-Freedom) is an experimental open source framework and runtime to support the ongoing discussion in the Web3D and W3C communities how an integration of HTML5 and declarative 3D content could look like. Ok fine. But how relates this to WebGL?

  3. Declarative (X)3D in HTML Completes todays graphics technologies 2D 3D (Final HTML5 spec) (No W3C spec yet) Declarative Scenegraph Part of HTML-document DOM Integration CSS/ Events Could be impl. on Imperative Procedural API Drawing context <canvas>

  4. Declarative (X)3D in HTML Powerful abstraction for Web-apps Efficiency : Scene interaction, picking, culling and rendering can be implemented in native code. Utilizes all (battery) resources as efficient as possible. Concepts : Provides HTML/DOM concepts for application developer. Does not force HTML Developer to deal with GLSL and 4x4 matrices. Adaptability : Declarative material abstraction allows shading adoption per client hardware (shader, raytracer, …) Flexibility : Dynamic scene-partitioning supports client and server based rendering Metadata : How to index and search “content” in WebGL-Apps?

  5. Declarative (X)3D in HTML Embed a live scenegraph in the DOM <!DOCTYPE html > <html > <body> <h1>Hello X3DOM World</h1> <x3d xmlns=‘…’ profile=‘HTML’ > <scene> <shape> <box></box> </shape> </scene> </x3d> </body> </html>

  6. History of declarative (X)3D in HTML X3D: ISO Standard since 2004; Plugin integration model HTML5 Specification: http://www.w3.org/TR/html5/no.html#declarative-3d-scenes 13.2 Declarative 3D scenes Embedding 3D imagery into XHTML documents is the domain of X3D, or technologies based on X3D that are namespace aware. 2007 : First experiment by Philip Taylor, W3C: http://philip.html5.org X3D in DOM, no DOM manipulation (Canvas3D for rendering) 2009 : x3dom by Fraunhofer IGD, Based on code of Taylor: www.x3dom.org Full DOM integration. Native , X3D-Plugin or WebGL for rendering W3C TPAC 2009 in Santa Clara, USA http://web3d.org/x3d/presentations/X3D+HTML5.W3cTpac-20091106.pdf 2010 : HTML/X3D InterestGroup / Web3D consortium Develops HTML/X3D integration model based on x3dom W3C TPAC 2010 in Lyon, France 2011 : W3C “Declarative 3D” Incubator Group Should produce real world requirements for “Declarative 3D” in HTML

  7. X3D Standard State of the current integration model Pro: ISO Standard developed by non-profit Web3D Consortium Specification includes abstract IDL and JavaScript-binding 10 year W3C member and contributor Event and runtime model build for the Web Con: Plugin integration model Simple Shape/Material assign mechanism . No cascading Material system Full Standard is to complex , Some concepts duplicate W3C techniques Fraunhofer IGD / Autor / Abteilung

  8. HTML/DOM Profile Reduce X3D to 3D visualization component for HTML5 General Goal : Utilizes HTML/JS/CSS for scripting and interaction Reduced complexity and implementation effort “ HTML ”-Profile (Extends X3D “Interchange”): Full runtime with anim., navigation and asynchronous data fetching No X3D-Script, Proto, High-Level Sensors Declarative and explicit shader material

  9. Implementation JS-Layer: Supports native , X3D/SAI- Plugin or WebGL

  10. x3dom.org/x3dom/release/x3dom.js JavaScript-based layer <!DOCTYPE html > <html > <head> <link rel="stylesheet" type="text/css" href="x3dom.css” > <script type="text/javascript" src="x3dom.js"></script> </head> <body> <h1>HTML5 Hello World</h1> <x3d xmlns=”…” profile=‘…’ backend=‘…’ > <scene> … </scene> </x3d> </body> </html>

  11. HTML Profile (X3D subset) Basic scene-graph nodes as DOM elements group , transform , lod , switch , billboard inline (loads additional parts asynchronously ) viewpoint (standard perspective camera) Single and Multi-index Geometry types with support for vertex properties pointLight , spotLight and directionalLight appearance with flexible shader-selection technique for explicit and parametric shader (e.g. CommonSurfaceShader proposal) text sound (spatialized emitter) background (skybox background) follower and interpolator for animation Standard navigation ( Walk, Fly, Examine, …) Direct support for HTML5 media elements texture : <img>, <video> and <canvas> sound : <audio>

  12. DOM Manipulation Node appending and removal HTML/X3D code: … <group id=‘root’></group> . … HTML-Script to add nodes: trans = document.createElement('Transform'); trans.setAttribute(‘translation’, ‘1 2 3’ ); document.getElementById(‘root’).appendChild(trans); HTML-Script to remove nodes: document.getElementById(‘root’).removeChild(trans);

  13. Application show-case Facebook Friendgraph in 3D

  14. DOM Manipulation Field updates with setAttribute() or SAI-Field interfaces HTML/X3D code: … <material id=‘mat’></material> … <coordinate id=‘coord’ point=‘5.6 3 87, 8.8 8.4 3.2, …’ ></coordinate> . … Generic HTML-Script with setAttribute() : also useful for libs like jQuery document.getElementByid(‘mat’).setAttribute(‘diffuseColor’,’red’); HTML-Script using SAI-Field interface: X3D JS-binding for more efficiency var saiField = document.getElementById(‘coord).getField(‘point’); saiField[4711].x = 0.815;

  15. Application show-case Application specific navigation: Carousel menu )

  16. HTML Events User Interaction through DOM Events Supports interaction with standard HTML-Events. Supports ancient (Netscape2) and addEventListener() interfaces. <x3d xmlns=”…"> <Scene> <Shape> <Appearance> <Material id=‘mat’ diffuseColor=‘red’ /> </Appearance> <Box onclick=“document.getElementById(‘mat’).diffuseColor=‘green’” /> </Shape> </Scene> </x3d>

  17. Application show-case Application specific navigation: Carousel menu )

  18. HTML Events 3DPickEvent extends DOM Level 3 MouseEvent interface 3DPickEvent : MouseEvent { readonly attribute float worldX ; // 3d world coordinates readonly attribute float worldY ; readonly attribute float worldZ ; readonly attribute float localX ; // element local 3d coordinates readonly attribute float localY ; readonly attribute float localZ ; readonly attribute float normalX ; // surface normal readonly attribute float normalY ; readonly attribute float normalZ ; readonly attribute float colorRed ; // surface color (with alpha) readonly attribute float colorGreen ; readonly attribute float colorBlue ; readonly attribute float colorAlpha ; readonly attribute float texCoordS ; // surface texture coordinates readonly attribute float texCoordT ; readonly attribute float texCoordR ; object getMeshPickData (in DOMString vertexProperty); };

  19. Application show-case CAE: Data visualization for Volkswagen, IFX )

  20. HTML Events Additional 3D Events extend Dom Level 3 UIEvent Inspired by the X3D-Sensors Environment Sensors // Visibility of sub-trees interface 3DVisibilityEvent : UIEvent { ...; } // Object-Camera Transformation sensor interface 3DProximityEvent : UIEvent { … ; } // Object-Transformation Interface 3DTransformEvent : Event { … ; }

  21. Application show-case Thematic data on climate change in cities )

  22. DOM Manipulation CSS 3D Transforms CSS 3D Transforms Module Level 3; W3C Draft Utilized to transform and update <transform> nodes <style type="text/css"> #trans { -webkit-animation: spin 8s infinite linear; } @-webkit-keyframes spin { from { -webkit-transform: rotateY(0); } to { -webkit-transform: rotateY(-360deg); } } </style> … <transform id="trans" > <transform style="-webkit-transform: rotateY(45deg);"> …

  23. Application show-case Geometry and animation export )

  24. HTML Events Events from the X3D subsystem <x3d xmlns="http://www.web3d.org/specifications/x3d-3.0.xsd"> <Viewpoint id=‘cam01’ /> <Viewpoint id=‘cam02’ /> <Scene> <Shape><Box size="4 4 4" /></Shape> </Scene> </x3d> <script type="text/javascript"> var cam = document.getElementsById(‘cam01’); cam.addEventListener(”active", function() { alert(”Viewpoint 01 is active!"); }, false); </script>

  25. Show-cases and Third-party application Developed during the last 12 month, (TPAC 2009 – 2010)

  26. Project Status Current release1.1: October 22nd, 2010 Unified HTML/XHTML encoding (with and without namespace) HTML5 <canvas>, <img> and <video> as texture element supported Better support for CSS 3D Transforms multiple lights and support for Spot-, Point- and DirectionalLight Fog Support for large meshes Improved normal generation Follower component Next Release 2.0: January, 2011 (After WebGL 1.0 spec release) Internal Shader composition framework -> CommonSurfaceShader Complete set of HTML Events on X3D-element CSS support for X3D element Better Navigation handler, Support for all standard navigation types Automatic camera path animation

  27. X3DOM Thanks! Thanks! Questions? Questions? www.x3dom.org
